Features Q.E.D. programming for quick
enrollment of devices.
VISTA-20PRV4 8/97 (See Instructions N7526V4)
VISTA-20
Principal changes between the VISTA-20SE and
the former VISTA-20 are indicated by margin lines.
2-PARTITIONED

SECURITY SYSTEM

PROGRAMMING
®
Previous Menu
SE
FORM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20SE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADEMCO 20SE

Summary of Contents for ADEMCO 20SE

  • Page 1: Security System

    Features Q.E.D. programming for quick enrollment of devices. VISTA-20PRV4 8/97 (See Instructions N7526V4) VISTA-20 SECURITY SYSTEM PROGRAMMING ® Principal changes between the VISTA-20SE and the former VISTA-20 are indicated by margin lines. Previous Menu 2-PARTITIONED FORM...
  • Page 2 Local programming requires the use of a 2-line Alpha keypad connected to partition 1 keypad terminals on the control. NOTE: For UL installations, the system may be configured as a single partition only. Field Function SYSTEM SETUP (*20–*29) * 20 INSTALLER CODE * 21 QUICK ARM ENABLE...
  • Page 3 * 36 ENTRY DELAY 2 (zone type 02) * 37 AUDIBLE EXIT WARNING * 38 CONFIRMATION OF ARMING DING * 39 POWER UP IN PREVIOUS STATE DIALER PROGRAMMING (*40–*53) In fields * 40, * 41, * 42, enter up to the number of digits shown. Do not fill unused spaces. Enter 0–9; #+11 for '*'; #+12 for '#';...
  • Page 4 * 49 SPLIT/DUAL REPORTING ** A 10-digit code is sent to the pager consisting of a 4-digit subscriber number, a 3-digit event code, and a 3-digit user or zone number. See Installation Instructions for an explanation of the 10-digit code. * Ca n o n l y b e u s e d i f p r i ma r y r e p o r t i n g f o r ma t i s A d e mc o Co n t a c t I D.
  • Page 5 EXPANSION ZONES: Assign zone numbers (Zn) 10–17 to 4219/4229 Auxiliary Wired Loops A–H, if used. RF zones can use zone numbers (Zn) 10–31 ZONE DESCRIPTION 4219/4229 Loop A 1st Exp'n Zone or RF Zones RF Zones RF Zones EXPLANATION OF ZONE ASSIGNMENT TABLE HEADINGS Zn = ZONE No.
  • Page 6 TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES ( 59Ð 76, & 89): With a 3+1 or 4+1 Standard Format: Enter a code in the first box: 1–9, 0, B, C, D, E, or F. Enter "#+10" for 0, "#+11" for B, "#+12"...
  • Page 7 Applicable only if Relays and/or Powerline Carrier Devicess are to be used. 80 OUTPUT DEVICES – This is an interactive menu mode. Fill in the required data on the worksheet on below and follow the programming procedure in the installation manual as you enter the data during the displays and prompts that appear in sequence.
  • Page 8 ZONE LISTS FOR OUTPUT DEVICES – below and follow the procedure in the installation manual as you enter the data during the displays and prompts that appear in sequence. Note: Record desired zone numbers below. More or fewer boxes than shown may be needed, since any list may include any or all of system's zone numbers.
