Section 6 Parts List - Icom IC-M2A Service Manual

SECTION 6 PARTS LIST

[VR UNIT]
REF ORDER
NO. NO.
R500 7210003130 VARIABLE
EP500 0910055331 PCB
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130007610 S.IC
IC50 1120002830 S.IC
IC170 1110003200 S.IC
IC190 1190000350 S.IC
IC200 1110003780 S.IC
IC220 1110005350 S.IC
IC260 1140003830 S.IC
IC280 1110001810 S.IC
IC340 1130010390 S.IC
IC341 1130009110 S.IC
IC360 1140010410 S.IC
Q20 1590000430 S.TRANSISTOR DTC144EUA T106
Q21 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q22 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q23 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q24 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q25 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q50 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q51 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q52 1590002160 S.TRANSISTOR XP6401-(TX)
Q53 1560001020 S.FET
Q54 1560001050 S.FET
Q90 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q150 1580000660 S.FET
Q151 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q220 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q221 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q222 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q223 1590000430 S.TRANSISTOR DTC144EUA T106
Q224 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q225 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q230 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q231 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q240 1590001770 S.TRANSISTOR XP1213 (TX)
Q250 1590002530 S.TRANSISTOR UN911H (TX)
Q280 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q350 1590000660 S.TRANSISTOR DTC144TU T106
D1 1720000670 S.VARICAP
D20 1790001260 S.DIODE
D21 1790000620 S.DIODE
D22 1720000780 S.VARICAP
D23 1720000780 S.VARICAP
D50 1790000620 S.DIODE
D51 1790000620 S.DIODE
D52 1790000580 S.DIODE
D80 1790001210 S.DIODE
D90 1790000580 S.DIODE
D91 1790001210 S.DIODE
D92 1790000620 S.DIODE
D93 1790000660 S.DIODE
D130 1790000620 S.DIODE
D350 1750000130 S.DIODE
FI150 2010002570 XTAL
FI151 2010002570 XTAL
FI170 2020001270 CERAMIC
DESCRIPTION
TP76N97N-13F-10KA-2497
B 5715A
DESCRIPTION
µPD3140GS-E1 (DS8)
NJM2125F-TE1
TA31136FN (EL)
M62363FP-650C
NJM2902V-TE1
NJM2870F05-TE1
TC4W66F (TE12L)
TA7368F (TP1)
HN58X2416TI
S-80942ANMP-DD6-T2
HD6433844RA60H (FX-2497A)
2SK2973 (MTS101P)
2SK2974
3SK272-(TX)
HVU17TRF
MA2S077-(TX)
MA77 (TX)
HVU350B TRF
HVU350B TRF
MA77 (TX)
MA77 (TX)
1SV307 (TPH3)
1SS375-TL
1SV307 (TPH3)
1SS375-TL
MA77 (TX)
MA728 (TX)
MA77 (TX)
DA204U T106
FL-346 (21.700 MHz)
FL-346 (21.700 MHz)
CFWLB450KE2A-B0 (CFWM450E)
[MAIN UNIT]
REF ORDER
NO. NO.
X1 6050011350 S.XTAL
X170 6070000190 S.DISCRIMINATOR CDBCB450KCAY24-R0
X360 6050010290 S.XTAL
L1 6200008070 S.COIL
L20 6200007000 S.COIL
L21 6200003090 S.COIL
L22 6200008190 S.COIL
L23 6200006980 S.COIL
L24 6200006980 S.COIL
L25 6200006980 S.COIL
L49 6200005740 S.COIL
L50 6200006980 S.COIL
L51 6200007000 S.COIL
L52 6200010230 S.COIL
L53 6200002330 S.COIL
L54 6200010230 S.COIL
L55 6200009240 S.COIL
L56 6200008530 S.COIL
L57 6200008400 S.COIL
L58 6200003710 S.COIL
L80 6200008450 S.COIL
L81 6200008450 S.COIL
L82 6200008400 S.COIL
L90 6200008150 S.COIL
L91 6200007760 S.COIL
L92 6200007760 S.COIL
L93 6200008190 S.COIL
L94 6200008190 S.COIL
L95 6200004720 S.COIL
L120 6200002430 S.COIL
L121 6200002410 S.COIL
L122 6200003550 S.COIL
L130 6200007760 S.COIL
L131 6200007760 S.COIL
L132 6200008190 S.COIL
L133 6200008190 S.COIL
L150 6200003680 S.COIL
R1 7510001160 S.THERMISTOR NTCCM1608 4LH 473KC
R2 7030003940 S.RESISTOR
R3 7030003560 S.RESISTOR
R4 7030003640 S.RESISTOR
R5 7030003380 S.RESISTOR
R6 7030003440 S.RESISTOR
R7 7030003640 S.RESISTOR
R8 7030003440 S.RESISTOR
R9 7030003200 S.RESISTOR
R10 7030003480 S.RESISTOR
R20 7030003320 S.RESISTOR
R22 7030003410 S.RESISTOR
R23 7030003440 S.RESISTOR
R24 7030003680 S.RESISTOR
R25 7030003680 S.RESISTOR
R26 7030003550 S.RESISTOR
R27 7030003550 S.RESISTOR
R28 7030003350 S.RESISTOR
R29 7030003390 S.RESISTOR
R30 7030003660 S.RESISTOR
R31 7030003420 S.RESISTOR
R32 7030003390 S.RESISTOR
R33 7030003630 S.RESISTOR
R34 7030003400 S.RESISTOR
R35 7030003660 S.RESISTOR
R36 7030003440 S.RESISTOR
R50 7030003440 S.RESISTOR
R52 7030003520 S.RESISTOR
R53 7030003320 S.RESISTOR
R54 7030003260 S.RESISTOR
R55 7030003500 S.RESISTOR
R56 7030003450 S.RESISTOR
R57 7030003310 S.RESISTOR
R58 7030003440 S.RESISTOR
R59 7030003580 S.RESISTOR
6 - 1
DESCRIPTION
CR-726 (21.250 MHz)
CR-610 (7.9872 MHz)
MLF1608E 6R8K 6.8U
ELJRE 82NG-F
NL 322522T-2R7J-3
0.25-1.9-8TL 80N
ELJRE R10G-F
ELJRE R10G-F
ELJRE R10G-F
ELJRE 47NG-F
ELJRE R10G-F
ELJRE 82NG-F
EXCCL3216U1
LQN 1A 15NJ04
EXCCL3216U1
0.20-1.0-7TL 31N
0.30-1.0-4TL 12N
0.35-1.6-6TL 36N
NL 252018T-2R7J
0.35-1.6-5TL 28N
0.35-1.6-5TL 28N
0.35-1.6-6TL 36N
0.35-1.6-7TL 44N
LQN21A 82NJ04
LQN21A 82NJ04
0.25-1.9-8TL 80N
0.25-1.9-8TL 80N
MLF1608D R10K-T
NL 252018T-082J
NL 252018T-056J
MLF1608A 4R7K-T
LQN21A 82NJ04
LQN21A 82NJ04
0.25-1.9-8TL 80N
0.25-1.9-8TL 80N
LQN 1N R82M
ERJ3GEYF 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 181 V (180 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
S.=Surface mount
