60' x 60' x 9' Office
3' 9' 15' 21'
44 46 43 44
57'
51' 43 44 43 43
45' 53 54 50 51
39' 44 45 44 45
33' 49 51 49 49
27' 49 51 49 49
44 45 45 45
21'
15' 53 54 50 51
9' 43 44 43 43
3' 45 46 44 44
60' x 60' x 9' Office
3' 9' 15' 21'
57'
42 43 42 42
54 55 53 54
51'
45'
60 61 59 58
39'
61 62 59 59
33'
57 59 57 57
27'
57 59 57 57
21'
61 62 59 59
15'
60 61 58 58
9'
54 55 53 54
3'
42 44 42 43
5/04
Lighting Layouts
27' 33' 39' 45' 51'
46 46 44 43 46
45 45 43 43 44
54 54 51 50 53
46 46 45 44 45
51 51 49 48 50
51 51 49 48 50
46 46 45 44 45
54 54 51 50 53
45 45 43 43 44
47 47 44 44 46
60'
27' 33' 39' 45' 51'
44 44 42 42 43
56 56 54 53 55
62 62 58 58 61
63 63 59 59 62
60 60 57 57 59
60 60 57 57 59
63 63 59 59 62
62 62 58 58 61
56 56 54 53 55
44 44 43 42 43
60'
Mini-Beam Luminaires
57'
Fixture: MBS2GPW154120PG (2'x4')
Quantity: 8 Rows of 6 Fixtures
44
Efficiency: 78%
Room Size: 60'x60'x9'
42
Reflectance: 80 Ceiling
52
Light Loss Factor: 0.93*
Lumens T5 Lamp: 4400**
44
Ballast Factor: 1.02
Average Maint. fc: 47
49

Watts/Square Foot: .83

60'
49
Average Maintained fc:
30" High Work Surface
44
*Light Loss Factor
52
Typical T8 Fixture 0.89
1 Lite T5 Fixture
43
** Lumens At 25˚c
44
Fixture: MBS2GPW154120PG (2'x4')
57'
Quantity: 8 Rows of 7 Fixtures
41
Efficiency: 78%
Room Size: 60'x60'x9'
54
Reflectance: 80 Ceiling
59
Light Loss Factor: 0.93*
Lumens T5 Lamp: 4400**
60
Ballast Factor: 1.02
Average Maint. fc: 55.1
57
Watts/Square Foot: .96
57
60'
Average Maintained fc:
30" High Work Surface
60
*Light Loss Factor
60
Typical T8 Fixture 0.89
1 Lite T5 Fixture
54
** Lumens At 25˚c
42
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
Copyright 2004 Lightolier
50 Wall
20 Floor
Ballast Maintenance Light Loss
x 0.92 = 0.82
1.02 x 0.92 + 0.93
50 Wall
20 Floor
Ballast Maintenance Light Loss
x 0.92 = 0.82
1.02 x 0.92 + 0.93
www.lightolier.com
Section 5/Folio M30-10
