Lightolier MJ2 Series Specification

MJ2132LH12W
Features
Illumination: High output
incandescent sealed beam
lamps provide glare-free light
distribution. 6 or 12 V, 12 W
bi-pin halogen has an expected
life of 100 hours.
Housing: Heavy duty steel
cabinet is finished in neutral
cream baked-on powder
paint providing scratch and
corrosion resistance. All
metal lamp housing and swivel
assemblies in neutral cream
color to match unit housing.
Lamp heads are fully adjustable
and feature lockable swivels.
MJ2 Series
C
HICAGO
Battery: Maintenance-free,
sealed, lead calcium battery
has an estimated service life
of 5 years, and an operating
temperature range of
68°F (20°C) to 86°F (30°C).
Nickel cadmium batteries are
optional.
Electronics: 120/277 VAC
dual voltage input with surge-
protected, solid-state circuitry.
Fully automatic, temperature
compensating, variable rate
float charging system is
complete with low voltage
disconnect, AC lockout,
brownout protection, AC
indicator lamp and test switch.
Job Information Type:
Job Name:
Cat. No.:
Notes:
S U
TEEL NIT
Page 1 of 2
Code Compliance
All models are UL 924 listed
and meet NFPA 101 Life Safety
Code, NEC, OSHA and City of
Chicago codes.
Warranty
Three year unit warranty
(excludes lamps). One year full
plus four year prorated battery
warranty (lead calcium). Five
year full plus five year prorated
battery warranty (nickel
cadmium).
