Titan XT250 Owner's Manual

High performance airless sprayer
Hide thumbs Also See for XT250:
Table of Contents

Advertisement

Quick Links

Owner's Manual
Read this manual for complete instructions
This pump is available in a stand model (XT250) and cart models (XT290
and XT330). All information given for the stand model applies to the cart
models except where indicated.
1-866-Titan XT
(1-866-848-2698)
Titan Technical Service
Visit us on the world wide web!
1770 Fernbrook Lane, Plymouth, MN 55447
Technical service hours:
• Form No. 0515831F
0408
www.titan-xt.com
Monday through Friday, 8:00 am to 7:00 pm Central Time
Saturday, 9:00 am to 3:30 Central Time
High Performance
Airless Sprayer
Models: XT250

Table of Contents

Safety ................................................................................2-3
Components and Description ........................................4-5
Assembly.............................................................................6
Before You Begin ...............................................................7
Locking the Spray Gun .................................................7
Pressure Relief Procedure ...........................................7
Grounding the Spray Gun ............................................7
Preparing the Sprayer ........................................................8
Preparing the Spray Hose..................................................9
Practice / Spraying Technique ........................................10
Spraying Troubleshooting ..........................................11-12
Unclogging the Spray Tip ...........................................11
Cleaning the Spray Gun Filter ....................................12
Cleaning the Inlet Filter ..............................................12
Cleanup ........................................................................13-17
Cleanup for Latex materials ..................................13-14
Cleanup for Oil-based materials .................................15
Cleaning the Suction Set ............................................16
Cleaning the Spray Gun Components ........................17
Short-Term Storage ..........................................................18
Long-Term Storage ..........................................................19
Cleaning the Inlet Valve ...................................................20
Fluid Section .....................................................................21
Troubleshooting / Maintenance ......................................22
Français .............................................................................23
Parts List ......................................................................45-47
Accessories ......................................................................47
Warranty ............................................................................48
Need Help? Call us first for answers
fast.
Call Titan toll-free if you have any comments or
problems with this product.
XT290
XT330
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Titan XT250

Summary of Contents for Titan XT250

  • Page 1: Table Of Contents

    Fluid Section ..............21 Troubleshooting / Maintenance ........22 Français ................23 Parts List ..............45-47 This pump is available in a stand model (XT250) and cart models (XT290 Accessories ..............47 and XT330). All information given for the stand model applies to the cart Warranty ................48 models except where indicated.
  • Page 2 · Important Safety Information Read all safety information before operating the equipment. SAVe THeSe InSTRuCTIOnS. To reduce the risks of fire or explosion, electrical shock and the injury to persons, read and understand all instructions included in this manual. Be familiar with the controls and proper usage of the equipment. HAZARD: eXPLOSIOn OR FIRe This symbol indicates a hazardous situation, which, if...

  • Page 3: Grounding Instructions

    · Important Safety Information Read all safety information before operating the equipment. SAVe THeSe InSTRuCTIOnS. nOTe - THe XT250 AnD XT290 SeRIeS unITS ARe PROVIDeD HAZARD: GeneRAL WITH A nOn-ReSeTABLe THeRMAL OVeRLOAD. THe XT330 Can cause severe injury or property damage.

  • Page 4: Safety

    PressureTrac™ ......The PressureTrac™ regulates the amount of force the pump uses to push the fluid. Quickflo™ valve......(XT250 only) The Quickflo™ valve is designed to keep the inlet valve open and from sticking to dried materials. The Quickflo™ valve is activated manually by the user.
  • Page 5 Components and Description This pump is available in a stand model (XT250) and cart models (XT290 shown below, and XT330). All information given for the stand model applies to the cart models except where indicated. nOTICe Some of the graphics in this manual may not exactly match your sprayer and spray gun. All information and instructions given in this manual applies to all models except where noted.

  • Page 6: Assembly

    If you have one of the cart models (XT290 or XT330) you will need to unfold the cart before using. Follow steps 1-3, below. If you have the model XT250 sprayer, skip to item 4, below. 1. Grab the pail bracket to lift up the sprayer. Lift the leg 2.

  • Page 7: Before You Begin

    Before you Begin - This section contains instructions that will be repeated throughout this manual. Locking / unlocking the Spray Gun Always lock the trigger off when attaching the spray tip or when the spray gun is not in use. Model XT-05 Model LX60 The gun is locked when the trigger lock is at a 90º...

  • Page 8: Preparing The Sprayer

    Follow the steps below. 1. Before priming, squirt a teaspoon of separating oil (P/N 2. If you have a model XT250, fully insert the Quickflo™ 0516444, sold separately) into the indicated area. Light valve to make sure the inlet ball is free.

  • Page 9: Preparing The Spray Hose

    Preparing the Spray Hose and Spray Gun The spray tip assembly should not be attached to the spray gun when purging the spray hose. Failure to comply could result in an injection injury. 1. Unlock the spray gun and turn the PRIME/SPRAY knob 3.

  • Page 10: Practice / Spraying Technique

    Practice / Spraying Technique IMPORTAnT: Be sure that the paint hose is free of kinks and clear of objects with sharp cutting edges. 1. Switch the pump ON (l). Turn the PRIME/SPRAY knob 2. When motor shuts off, unlock the spray gun and spray a to SPRAY.

  • Page 11: Spraying Troubleshooting

    Spraying Troubleshooting - unclogging the Spray Tip If the spray pattern becomes distorted or stops completely while the gun is triggered, follow these steps. Do not attempt to unclog or clean the tip with your finger. High pressure fluid can cause injection injury. IMPORTAnT: Do not use a needle or other sharp pointed instrument to clean the tip.

  • Page 12: Cleaning The Spray Gun Filter

    Spraying Troubleshooting - Cleaning the Spray Gun Filter The filter must be cleaned every time you use your sprayer. When using thicker spray materials, the filter might need to be cleaned more often. NOTE - the LX60 threads are left-handed. Turn the filter Spray gun clockwise to remove, and counterclockwise to replace.

  • Page 13: Cleanup

    • DO NOT use gasoline to clean your sprayer. Call 1-866-Titan XT if you have any problems or questions regarding the cleaning of your sprayer. Follow these steps if you used latex materials and if you have a garden hose available. If you do not have a garden hose available, follow the Cleanup - Oil-Based Materials instructions.

  • Page 14: Cleanup For Latex Materials

    Cleanup - Latex materials (continued) 5. Unclip the return tube from the suction tube and place it 6. Turn water supply on. Turn pump ON (l). Water will go into the waste container. Turn the PRIME/SPRAY knob into the suction tube and out through the return tube. to PRIME.

  • Page 15: Cleanup For Oil-Based Materials

    Cleanup - oil-based materials 1. Lock the gun and remove spray tip assembly. 2. Place a waste container next to the original material Submerge suction set into a bucket with appropriate container. Aim the spray gun into the side of the cleaning solution.

  • Page 16: Cleaning The Suction Set

    Cleaning the Suction Set 1. Lock the gun and turn the pump OFF (O). 2. Remove the suction hose and return tube and clean it using the appropriate cleaning solution. You should also wipe the threads of the inlet nut (a) and remove and clean the inlet filter.

  • Page 17: Cleaning The Spray Gun Components

    Cleaning the Spray Gun Components 1. Make sure the pump is switched OFF (O). Make sure 2. Remove spray gun from the paint hose using adjustable the PRIME/SPRAY knob is turned to PRIME. Unplug wrenches. the sprayer. 3. Remove filter from spray gun (refer to Cleaning the 4.

  • Page 18: Short-Term Storage

    Short-Term Storage (up to 16 hours) Title Follow these steps when using latex materials only. If using materials that are oil-based, follow the Cleanup and Long- Term Storage steps. Shutdown 1. Lock the spray gun off. LX60 XT-05 2. Turn the PRIME/SPRAY knob to PRIME. Switch the 3.

  • Page 19: Long-Term Storage

    ON (l). When the oil has been pumped from the cup, turn the pump OFF (O). Separating oil 3. If you have a model XT250, fully insert the Quickflo™ 4. Wipe the entire unit, hose and gun with a damp cloth to valve.

  • Page 20: Cleaning The Inlet Valve

    If you have a model XT290 or XT330, loosen the fitting cleaning solution. as shown (a) and remove the Sureflo™ valve solenoid. If you have a model XT250, skip to step 2. XT250 3. Replace inlet valve assembly by screwing it into the 4.

  • Page 21: Fluid Section

    4. Using a pliers, pull the dowel pin out. 7. Install the dowel pin to connect the yoke to the piston. 5a. For models XT250 and XT290, rotate the pump shaft The piston may have to be moved up or down to do this.

  • Page 22: Troubleshooting / Maintenance

    The only daily maintenance necessary is thorough cleaning and lubricating Kit Part # Description after usage. Follow the cleaning and lubricating procedures in this manual. 0516701 Fluid Section Seal Kit (XT250, XT290) extended Maintenance 0516700 Fluid Section Seal Kit (XT330) 0516735 Inlet Valve Kit (XT250) Some pump parts eventually wear out from use and must be replaced.

  • Page 23: Français

    Parts List • Liste de pièces Title english english Model XT-05 spray gun (XT250 and XT290) Model LX60 spray gun (XT330) Item Part # Description Quantity Item Part # Description Quantity 0516711 Guard Assembly ....... 1 0516711 Tip guard .......... 1 0516707 Tip, 415 ..........
  • Page 24 0516252 Chariot et ses composants (XT330) . 1 (modèles du chariot)......1 0516483 Verrou de pied ........1 0512371 Tube de retour (XT250) ....1 0516769 Trousse de Roue/capuchon (XT290) 1 0512389 Tube de retour (modèles du chariot) 1 0516770...
  • Page 25 N° de pièce Description 0516674 Separating oil 0516674 Huile séparatrice 0516701 Piston repair kit (XT250, XT290) 0516701 Trousse de réparation de piston (XT250, XT290) 0516700 Piston repair kit (XT330) 0516700 Trousse de réparation de piston (XT330) 0516735 Inlet valve kit (XT250) 0516735 Trousse de soupape d’entrée (XT250)

  • Page 26: Accessories

    This warranty does not cover damage resulting from improper use, accidents, user’s negligence or normal wear. This warranty does not cover any defects or damages caused by service or repair performed by anyone other than a Titan Authorized Service Center. This warranty does not apply to accessories.
