Figure 1. The Evolution 5200 TIC
and Evolution 5200HD

INTRODUCTION

Congratulations on the purchase of your new MSA
Evolution 5200 Thermal Imaging System! This
hand-held unit provides advanced thermal imaging
technology backed by years of MSA quality,
dedication, and service.
The Evolution 5200 Series Thermal Imaging
Camera (TIC) is designed to assist firefighters to
see in low visibility conditions of smoke and
darkness. This high definition thermal imaging
camera provides the latest in available thermal
imaging technology for the fire service.

FEATURES AND BENEFITS

The Evolution 5200 Series Thermal Imaging
Camera (TIC) can be used to aid firefighting in
scenarios such as:
• Search and rescue missions
• Initial size-up/Scene assessment
• Locating the seat of the fire
• Locating fire extension
• Identifying potential flashover situations
• Determining entry and ventilation points
• Hazmat situations
• Response vehicle navigation (darkness or
heavy smoke)
• Preplanning/Fire code inspections
• Overhaul
• Assistance for law enforcement

BEFORE USE/DESCRIPTION

TIC
2

DESCRIPTION

The Evolution 5200 and Evolution 5200HD
are highly sophisticated pieces of electronic
equipment. The unit was designed to withstand the
firefighting conditions of heat, driving spray, and
frequent impact normally seen by a firefighter.
Extension beyond these demands may damage
the camera and render it inoperable. It is not
recommended that the camera run for extended
periods in high-heat conditions.
The Evolution 5200 Series TICs are intended as
an aid to fire and rescue operations in conditions
of poor visibility created by smoke and darkness,
and are not a replacement for standard firefighting
techniques and precautions. Users must ensure
that the fire department's standard operating
procedures are followed while using the cameras.

ABOUT THE CAMERA

The Evolution 5200 Series TICs are as follows:
• equipped with a state-of-the-art 160 x 120
(Evolution 5200) or a state-of-the-art
320 x 240 (Evolution 5200HD
microbolometer thermal detector to provide
the clearest high-definition images available
in fire and non-fire environments
• the Evolution 5200HD
zoom feature, providing the user with
magnified image information
• equipped with a large screen, high definition
display to allow for multiple firefighters to view
the action
• ergonomically designed for the firefighting
environment
• available with desk top and truck mounted
charging options
• designed with the most ergonomically correct
balance, with the center of gravity located in
the users hand
• dust and water-resistant to withstand short-
term immersion in up to three feet of water in
accordance with IP67 specifications
• available with multiple carrying and
attachment options to suit user preferences -
the Evolution 5200 TIC is a tool
