5. Trouble-Shooting
- The device does not heat: Make sure that the installation circuit breakers are switched on, or that the load shedder (if you
have one) has not switched off the unit power supply. Check the air temperature in the room. For the device equipped,
check that the programmer is in Comfort mode.
- The unit is permanently heating: Make sure that it is not in a draft and that the temperature setting has not been
changed.
- The unit does not carry out programming orders (Device equipped): Make sure that the programming unit is being
correctly used (refer to its user's manual) or that the Chronocarte is properly inserted in its housing and that it is operating
normally (batteries). The device with electronic control is equipped with a microprocessor that can be distribued by some
severe mains voltage disturbances (outside EC standards defining the disturbance protection level). If there are any
problems (thermostat blocked, etc.) switch off the unit power supply (fuse, circuit breaker, etc.) for about 5 minutes to allow
the unit to start again. If this phenomenon occurs frequently, control the power supply by your energy supplier.
- The device is very hot on the surface: It is normal that the device when working, the maximum surface temperature is
limited in accordance with standards. However, if you believe that your radiator is still too hot, make sure the power is
adapted to the surface of your room (we recommend 100W / m2) and the unit is not placed in a stream of air that would
disrupt its regulation.
6. Technical specifications
Type
Atlantic F117D- 05
Atlantic F117D- 07
Atlantic F117D- 10
Atlantic F117D- 12
Atlantic F117D- 15
Atlantic F117D- 20
Atlantic F117D- 25
Wattage Voltage
Rating
(W) (V)
500
750
1000 1/N
1250 230V IP24
50Hz
1500
2000
2500
Dimensions (mm)
Length Height Depth
384
384
458
532 451 98
606
754
902
Weight
(kg)
2,85
2,85
3,2
3,75
4,4
5,15
6,34
