Device Hardware

Front Panel
Removable CF-Cap
Stylus
holder
Power
Top View- without Cap Bottom View
CompactFlash and SDIO slots
Some units do not have these slots
CF slot #1
Type I
NOTE: Be sure to read the warranty and safety information in this
manual prior to using your unit.
2
Notification
LED
CF slot #2
SDIO
Type I & II
slot
Back Panel
CF-Cap
USB Serial
host
port
Hand strap
PowerBoot
Module
PowerBoot
coin screws
USB External
client power
