For Vigor2860N-Plus - Draytek Vigor2860 Series Quick Start Quide

1 . 1 . 3 F o r V i g
1 . 1 . 3 F o r V i g
LED
ACT (Activity)
USB
2.4G/5G
WAN2
DSL
QoS
WCF
DoS
LED on Connector
Left
WAN2
LED
(Giga)
Right
LED
Vigor2860 Series Quick Start Guide
o r 2 8 6 0 n - p l u s
o r 2 8 6 0 n - p l u s
Status
Blinking
Off
On
Blinking
On
Blinking
On
Off
Blinking
On
Blinking
On
On
On
Blinking
On
Off
Blinking
On
Off
Explanation
The router is powered on and running
normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
Wireless access point with bandwidth of
2.4GHz/5GHz is ready.
It will blink slowly while wireless traffic
goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and
will return to normal condition after two
minutes. (You need to setup WPS within 2
minutes.)
Internet connection is ready.
Internet connection is not ready.
The data is transmitting.
The router is ready to access Internet
through DSL link.
Slowly: The DSL connection is ready.
Quickly: The connection is training.
The QoS function is active.
The Web Content Filter is active. (It is
enabled from Firewall >> General
Setup).
The DoS/DDoS function is active.
It will blink while detecting an attack.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
6
