SoundPoint IP 430
Quick User Guide
Basic Phone Features
and Customizing Your Phone
Applies to phones running SIP 2.0 or later
controlled by SIP@Net.
For detailed information please consult the
comprehensive SoundPoint IP 430 User
Guide available at : www.nec-philips.com.
© NEC Philips Unified Solutions Nederland B.V. 2007.
All rights are reserved. Reproduction in whole or in part is prohibited
without the written consent of the copyright owner.
All brand names and product names in this document are trademarks or
registered trademarks of their respective companies
Issue : April 2007
PLACING A CALL
Using the Handset :
Pick up the handset and enter the number or
enter the number first, and then pick up the
handset.
Using the hands-free Speakerphone :
1. With the handset on-hook, press :
- any assigned line key, or
- the NewCall soft key.
2. Dial the number.
Or dial the number, and then press the Dial
soft key.
Using the optional Headset :
1. With the headset connected, press :
- any assigned line key, or
- the NewCall soft key.
2. Press .
3. Dial the number.
Or dial the number, and then press .
During a call, you can alternate between
hands-free, headset, handset or modes
by pressing the or keys, or
picking up the handset.
ANSWERING A CALL
Using the Handset :
Pick up the handset.
Using the Speakerphone :
Press :
- button, or
- the line key, or
- the Answer soft key.
Using the optional Headset :
Press .
Incoming calls may be ignored by
pressing the Reject soft key or
Invoking Do Not Disturb during ringing.
ENDING A CALL
Using the Handset :
Hang up or press the EndCall soft key.
Using the Speakerphone :
Press or the EndCall soft key.
Using the optional Headset :
Press or the EndCall soft key.
SoundPoint IP 430 Quick User Guide
MICROPHONE MUTE
During a call, press . Mute applies to all
modes : handset, headset, and hands-free.
You can hear all other parties while Mute is
enabled.
To turn off Mute, press again.
CALL HOLD AND RESUME
1. During a call, press or the Hold soft
key.
2. Press again, the Resume soft key, or
the line key to resume the call.
LOCAL CONFERENCE CALLS
Conferencing is an optional feature that must
be configured on the call server. Particulars
and menu options may vary.
To create a three-way local conference
call :
1. Call the first party.
2. Press the Cnfrnc soft key to create a new
call (the active call is placed on hold).
3. Place a call to the second party.
4. When the second party answers, press the
Cnfrnc soft key again to join all parties in the
conference.
When a conference has been established,
pressing the Split soft key will split the
conference into two calls on hold.
Placing the call on hold on the conference
originator's phone will place the other
parties in the conference on hold.
A conference may be created at any time
between an active call and a call which is
on hold (on the same line or another line)
by pressing the Join soft key.
Ending the call on the conference
originator's phone will allow the other
parties to continue the conference.
CALL TRANSFER
1. During a call, press the Trnsfr soft key
(the active call is placed on hold).
2. Place a call to the party to which you want
to transfer the call.
3. After speaking with the second party,
press the Trnsfr soft key to complete the
transfer.
Press the Blind soft key to transfer the
call without speaking to the second party.
Transfer may be cancelled during
establishment by pressing the Cancel
soft key. The original call is resumed.
REDIAL
Press the Redial soft key or button
to redial the most recently dialed number.
FUNCTION PROGRAMMED UNDER
SECOND SPEED DIAL KEY
The second speed dial key can be pre-
programmed with a dedicated function or a
(colleague's) internal telephone number of
which the status can be monitored by means
of the LEDs (ask your system administrator
for more details).
Function
Pressing this key activates the function : the
corresponding LED is switched ON.
Pressing the key once more de-activates the
function : the LED is switched OFF.
Telephone Number
When the LED is :
- OFF : the telephone is idle
- Flashing : the telephone is ringing : you
can answer this call.
- ON : the telephone is the busy
CALL FORWARDING
To activate Call Forwarding :
- Press the second speed dial key, when
programmed with the Call Forwarding
function (LED is ON), or
- Dial the "activate prefix" possibly followed
by the alternative destination number.
