OWNER'S MANUAL
TABLE STEAM KETTLE
TILTING — ELECTRIC
SELF CONTAINED
These instructions should be read thoroughly before attempting installation. Set up, installation
and Performance Check should be performed by a qualified service technician. The
Manufacturer, Southbend (1100 Old Honeycutt Rd., Fuquay-Varina, North Carolina 27526),
informs you that unless the installation instructions for the above described Southbend product
are followed and performed by a qualified service technician, (a person experienced in and
knowledgeable concerning the installation of commercial gas and/or electrical cooking
equipment) then the terms and conditions of the Manufacturer's Limited Warranty will be
rendered void and no warranty of any kind shall apply.
If the equipment has been changed, altered, modified or repaired by other than a qualified
service technician during or after the 12-month limited warranty period, then the manufacturer
shall not be liable for any incidental or consequential damages to any person or to any property
which may result from the use of the equipment thereafter. Some States do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion thereto may not apply to you.
In the event you have any question concerning the installation, use, care, or service of the
product, write Customer Service Department, Southbend Corporation, 1100 Old Honeycutt Rd.,
Fuquay-Varina, North Carolina 27526.
southbend
INSTALLATION
USER'S GUIDE
SERVICE
PARTS
MODELS:
KTPE-05
KTPE-10
TABLE STEAM KETTLE
TILTING — ELECTRIC SELF CONTAINED
(Manual Section SK)
