Southbend KECT-06 Specification Sheet

SPECIFICATIONS:
Shall be a Southbend Model __________________________,
self-generating, electric, tilting kettle. A double wall kettle interior
shall form a steam jacket around the lower 2/3 of the kettle. The
jacket enclosure shall contain distilled water which is factory
sealed. The bottom of the kettle shall be of hemispherical design
for superior heat circulation.
The mounting base shall include the kettle mounting lugs
concealed inside a rectangular enclosure and a stainless steel
mechanism housing.
A removable operating handle with heat proof knob shall be
mounted on the right.
Construction shall be of all welded satin finish stainless steel,
type 304. The interior cooking surface shall be of type 316
stainless steel for added resistance to corrosion. The kettle shall
be ASME constructed, National Board Registered, c-CSA-us
and NSF certified.
The controls shall be water resistant, integrally mounted and
shall include a power switch, solid state thermostat, pilot light,
vacuum/pressure gauge, safety valve, low water light, and low
water shut off.
The kettle shall operate in a temperature range of 165°F to
285°F (74°C to 140°C) at a maximum pressure of 50 psi (345
kPa). The kettle shall come standard with removable elements.
Form KECT Rev 1 (November/2010)
www.yatesgd.com www.yatesgraphicdesign.com
E
M
odel
kW
KECT-6 7.5
KECT-10 12
KECT-12 12
OPERATION SHALL BE BY:
Electrically, self-generating closed steam system equipped for
operation on:
The kettle shall be equipped for operation on:
 208 VAC, 1 or 3 phase, 50/60 Hz*
 240 VAC, 1 or 3 phase, 50/60 Hz*
* Phase is field convertible.
STANDARD FEATURES:
 Low water level cut-off and indicator
 Pressure gauge
 Temperature control
 Safety relief valve
 Type 316 stainless steel liner
 2/3 steam jacket
 50 PSI (345 kPa) high pressure operation for higher cooking
temperature
 Integrally mounted controls
 Removable elements
 "Clean lock" to hold kettle in cooking position or 105° for ease of
cleaning
 Stainless steel console and trunnion
 Water resistant construction
OPTIONAL ITEMS AT EXTRA COST:
 220 VAC, 1 or 3 phase, 50/60 Hz
 380 VAC, 3 phase, 50/60 Hz
 415 VAC, 3 phase, 50/60 Hz
 480 VAC, 3 phase, 50/60 Hz
 600 VAC, 3 phase, 50/60 Hz
 415/240 VAC, 3 phase, 4 wire, 50/60 Hz
 380/220 VAC, 3 phase, 4 wire, 50/60 Hz
 Etched gallon markings (GM-6/10/12)
 Etched liter markings (LM-23/38/45)
 Correctional Package
ACCESSORIES:
 One piece lift-off stainless steel cover (C-6/10/12)
 Stainless steel wire basket (SSB-6/10/12)
 18" high floor stand c/w sliding drain pan and stationary drain
 Graduated measuring strip (CMS-6/10/12)
 Single pantry faucet with swing spout (SF-12)
 Double pantry faucet with swing spout (DF-12)
 Pour lip strainer (TKS-6/10/12)
c
lEctric ountEr
t K
ilting EttlE
C
apaCities
US Gal. Liters
6 23
10 38
12 45
