Southbend KSLG-20 Specification Sheet

SPECIFICATIONS:
Shall be a Southbend Model _____________________________,
gas fired, self-contained steam jacketed kettle, AGA and CGA
design certified, NSF approved. The unit comes standard with
electronic ignition and a hinged stainless steel cover. The 60
gallon kettle comes standard with a spring assisted cover.
The kettle shall be constructed with an exterior of type 304
stainless steel, #4 sanitary finish and 6" (152mm) stainless steel
adjustable legs. The interior kettle liner shall be a one piece
welded construction made with type 316 stainless steel for 20
and 40 gallon kettles and type 304 stainless for 60 gallon kettles
with #4 sanitary finish, 2/3 jacketed and shall be furnished with
a 2" (50 mm) tangent draw off valve as standard. The recessed
control panel shall be located on the front side of the unit in full
view of the operator and easy to use. Standard controls include
a direct immersion thermostat, water sight glass, cooking light,
pressure gauge and low water indicator light. Safety features
shall include a low water cut off, pressure relief valve, pressure
switch and a 100% safety gas shutoff valve.
Form KSLG Rev 1 (November/2010)
www.yatesgd.com www.yatesgraphicdesign.com
M
odel
KSLG-20 20 Gallon
KSLG-40 40 Gallon
KSLG-60 60 Gallon
OPERATION SHALL BE BY:
 Natural Gas
 L.P. Gas
For operation on 115 VAC, 1 phase 50/60 Hz, A.S.M.E.
code stamped for operation up to 50 psi (345kPa). The
steam kettle temperature ranges shall be between 165°F
to 275°F (74°C to 135°). Burners shall be serviceable,
high efficiency stainless steel with no shutter adjustment.
OPTIONAL ITEMS AT EXTRA COST:
 220 VAC, 1 phase, 50/60 Hz.
 316 stainless steel liner for interior (for KSLG-60)
 3" (76 mm) draw-off valve (TVT-3)
 2" (50 mm) dairy valve (DDO-2T)
 3" (76 mm) dairy valve (DDO-3T)
 Etched gallon markings (GM-)
 Etched liter markings (LM-)
 Spring assist for 20 + 40 gallon (SA-)
 Casters
 Correctional Package
ACCESSORIES:
 Stainless steel tri basket, (TBA-1)
 Graduated measuring strip (CMS-)
 Strainer hook (SH-)
 Perforated strainer for draw-off valve (TPS-)
 Solid disc for draw-off valve (TSS-)
 Single pantry faucet with swing spout, SF-12
 Double pantry faucet with swing spout, DF-12
G s
as tationary
s K
team ettle
C
apaCity
76 Liter
152 Liter
227 Liter
