Copyright
Copyright © 2014 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
®
TYAN
is a trademark of MiTAC International Corporation.
®
Intel
is a trademark of Intel
AMI, AMI BIOS are trademarks of AMI Technologies.
®
Microsoft
, Windows
®
Winbond
is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

S7086

Version 1.0
®
Corporation.
®
are trademarks of Microsoft Corporation.
http://www.tyan.com
®
products including liability or
1

Advertisement

Table of Contents
loading

Related Manuals for TYAN S7086

Summary of Contents for TYAN S7086

  • Page 1: S7086

    Corporation and has been reviewed for accuracy and reliability prior to printing. MiTAC assumes no liability whatsoever, and disclaims any express or implied ® warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MiTAC retains the right to make changes to product descriptions and/or specifications at any time, without notice.

  • Page 2: Table Of Contents

    Contents S7086 ......................1 Before you begin… ..................3 Chapter 1: Instruction ................4 1.1 Congratulations ................. 4 1.2 Hardware Specifications ..............4 1.3 Software Specifications ..............9 Chapter 2: Board Installation ..............10 2.1 Board Image ..................11 2.2 Block Diagram ................. 12 2.3 Motherboard Mechanical Drawing ...........

  • Page 3: Before You Begin

    Check the box contents! The retail motherboard package should contain the following: 1 x S7086 Motherboard 2 x SATA Single Cable 1 x Rear IO shielding 1 x S7086 Quick Installation Guide ® 1 x TYAN Driver CD IMPORTANT NOTE: Sales samples may not come with any of the accessories listed above.

  • Page 4: Chapter 1: Instruction

    32 and 64-bit computing, high-bandwidth memory design, and lightning- fast PCI-E bus implementation. The S7086 not only empowers you in today‟s demanding IT environment but also offers a smooth path for future application upgradeability. All of these rich feature sets provide the S7086 with the power and flexibility to meet demanding requirements for today‟s IT environments.
  • Page 5 Gen3 x8, Intel 10GbE Mezz Card / M7076-3108-8I, PCI- Recommended E Gen3 x8, LSI SAS 12G Mezz Card / M7094-2308G-8I, TYAN OCP Card PCI-E Gen3 x8, LSI SAS 6G Mezz Card / M7076-3008- 8I, PCI-E Gen3 x8, LSI SAS 12G Mezz Card / M7076-...
  • Page 6 Temp. Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS 6/6 RoHS Compliant Motherboard (1) S7086 Motherboard Package Manual (1) Quick Installation Guide Contains Installation CD (1) TYAN installation CD TYAN S7086 (S7086GM3NRE) Supported CPU Intel Xeon Processor E5-2600 v3 series processors...
  • Page 7 Gen3 x8, Intel 10GbE Mezz Card / M7076-3108-8I, PCI- Recommended E Gen3 x8, LSI SAS 12G Mezz Card / M7094-2308G-8I, TYAN OCP Card PCI-E Gen3 x8, LSI SAS 6G Mezz Card / M7076-3008- 8I, PCI-E Gen3 x8, LSI SAS 12G Mezz Card / M7076-...
  • Page 8 - 40° C ~ 70° C (-40° F ~ 158° F) Temp. Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS 6/6 RoHS Compliant Motherboard (1) S7086 Motherboard Package Manual (1) Quick Installation Guide Contains Installation CD (1) TYAN installation CD http://www.tyan.com...

  • Page 9: Software Specifications

    1.3 Software Specifications For the latest OS (operation system) support, please visit the Tyan‟s Web site for information. Remember to visit our Web site at http://www.tyan.com for the latest AST2400 User‟s Guide. http://www.tyan.com...

  • Page 10: Chapter 2: Board Installation

    Caution! To avoid damaging the motherboard and associated components, do not use torque force greater than 7kgf/cm (6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 11: Board Image

    2.1 Board Image S7086 This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. NOTE: SAS HD1/SAS HD2 connectors are only in S7086GM3NRE SKU...

  • Page 12: Block Diagram

    2.2 Block Diagram S7086 Block Diagram http://www.tyan.com...

  • Page 13: Motherboard Mechanical Drawing

    2.3 Motherboard Mechanical Drawing http://www.tyan.com...

  • Page 14: Board Parts, Jumpers And Connectors

    The board you receive may not look exactly like the above diagram. The DIMM slot numbers shown above can be used as a reference when reviewing the DIMM population guidelines shown later in the manual. For the latest board revision, please visit our web site at http://www.tyan.com. http://www.tyan.com...
  • Page 15 8. LAN Port#2(LAN2) 25.USB 2.0 Header(USB2_HD1) 9. ID LED 26.PSMI Connector(PSMI_HD1) 10. 4-pin Fan Connector(SYS_FAN5) 27. 24-pin Power Connector(PW1) 11. TYAN Module Header 28. USB 3.0 Header(USB3_HD1) 12. BMC LED 29. TYPE_A USB Header(TYPEA_USB3) 13. COM Port(COM2) 30. 4-in-1 Mini SAS Connector(SSATA0-3) 14.
  • Page 16 PSMI_HD1 SYS_FAN1 SGPIO1 CPU1_FAN SYS_FAN4 SYS_FAN2 SYS_FAN5 SYS_FAN3 CPU0_FAN LAN_LED_HD1 FP_HD1 http://www.tyan.com...
  • Page 17 INTRUSION# FPIO_TEMP_IN LAN2_ACTLED+ NMI_SW# LAN2_ACTLED- PSIMI_HD1: PSMI Connector Signal SMB_CLK SMB_DAT SMB_ALERT# V3P3 SGPIO1: SATA SGPIO Header Signal Signal SDATA OUT- SLOAD SCLOCK P3V3_AUX HD_ERROR_LED NOTE: SGPIO1 is responsible for SATA 0~5 LAN_LED_HD1: LAN2 LED Header Signal LAN2_LED_P LAN2_LED_N http://www.tyan.com...
  • Page 18 TYPEA_USB3 USB3_HD1 USB2_HD1 FAN_HD1 http://www.tyan.com...
  • Page 19 Vertical (Type_A) USB3.0 Connector Signal Signal USB2.0_DATA_N USB2.0_DATA_P USB3.0_RX_N USB3.0_RX_P USB3.0_TX_N USB3.0_TX_P FAN_HD1: Front Fan Connector (Reserved for Barebone) Signal Signal TACH1 TACH6 TACH2 TACH7 TACH3 TACH8 TACH4 TACH9 TACH5 TACH10 PWM2 PWM1 TACH11 SMB_DATA TACH12 SMB_CLK VCC3_AUX PWM3 http://www.tyan.com...
  • Page 20 SATA5 SATA4 DBG_HD1 COM2 IPMB_HD1 http://www.tyan.com...
  • Page 21 SATA4/SATA5: 7-pin vertical SATA3.0 Connector(Blue) Connects to the Serial ATA ready drives via the Serial ATA cable. DBG_HD1: TYAN Module Header Signal Signal P3V3 FRAME_N LAD0 LAD1 PLT_RST_N LAD2 LAD3 CLK_33M DBG_SERIRQ DBG_PRES_N VCC3_AUX ADDR_MB PCH_PP_EN COM2: COM Header Signal...
  • Page 22 3PHD_4/3PHD_6 3PHD_9 3PHD_3 4PHD_1 ID_LED_HD1 INTRUDER_HD1 Caution: The jumpers are only using for engineering debug. We don‟t suggest customers change the jumpers‟ position, which may cause unable to boot device. http://www.tyan.com...
  • Page 23 Pin 2-3 Closed: Intel MIC card 3PHD_4: BIOS Security Mode Jumper Signal FM_BIOS_RCVR_BOOT_N Pin 1-2 Closed: Normal Mode (Default) Pin 2-3 Closed: BIOS Recovery Mode 3PHD_6: ME Recovery Mode Jumper Signal FM_ME_RCVR_N Pin 1-2 Closed: Normal Mode (Default) Pin 2-3 Closed: ME Recovery Mode http://www.tyan.com...
  • Page 24 4PHD_1: BUZZER Disable Jumper Signal VCC5 BUZ_1 BUZ_2 Pin 3-4 Closed: Normal Mode (Default) Pin 2-3 Closed: Disable PC Beep Pin 1-4 Closed: Use the External Speaker http://www.tyan.com...
  • Page 25 http://www.tyan.com...
  • Page 26 2. Press the button (Clear CMOS). 3. Reconnect power & power on the system. NOTE: After flashing new BIOS, do the following steps: a. Clear CMOS b. Enter BIOS setup menu and load Default Settings. Then do a Save and Exit from setup. http://www.tyan.com...
  • Page 27 LED1 Blue System identified ID_LED System not identified NOTE: The ID LED can be activated remotely using IPMI. Please visit the TYAN Web Site at http://www.tyan.com download the latest IPMI Configuration Guide for more details. Signal +3V_AUX LED2 BMC_LED State...

  • Page 28: Installing The Processor And Heatsink

    2.5 Installing the Processor and Heatsink The types of processors supported by the S7086 are listed in the 1.2 Hardware Specifications section on page 4. Check our website at http://www.tyan.com ® the latest list of validated Intel processors for this specific motherboard.
  • Page 29 Lift the socket cover to a fully open position. Place the CPU in the CPU socket and make sure that the gold arrow is located in the right direction with two notches properly aligned. Remove the socket protection cap. Close the CPU socket cover. http://www.tyan.com...
  • Page 30 Close the socket one side lever. Close the socket other side lever. http://www.tyan.com...
  • Page 31 . Please refer to the Intel website: http://www.intel.com ® The following diagram illustrates how to install the heatsink on the Intel Haswell EP Socket R3: Tear down the heatsink protective cover. Place the heat sink on top of the CPU. Secure the heatsink screws. http://www.tyan.com...

  • Page 32: Thermal Interface Material

    CPU lid (applying too much will actually reduce the cooling). NOTE: Always check with the manufacturer of the heat sink & processor to ensure that the thermal interface material is compatible with the processor and meets the manufacturer‟s warranty requirements. http://www.tyan.com...

  • Page 33: Tips On Installing Motherboard In Chassis

    Be especially careful to look for extra stand-offs. If there are any stand-offs present that are not aligned with a mounting hole on the motherboard, it will likely short components on the back of the motherboard when installed. This will cause malfunction and/or damage to your motherboard. http://www.tyan.com...
  • Page 34 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MiTAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. http://www.tyan.com...

  • Page 35: Installing The Memory

    2.8 Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com details of the type of memory recommended for your motherboard.  This platform supports eight (4+4) DDR4 sockets, Registered DDR4 up to 512GB,...
  • Page 36 1. √ indicates a populated DIMM slot. 2. Use paired memory installation for max performance. 3. Populate the same DIMM type in each channel, specifically - Use the same DIMM size - Use the same # of ranks per DIMM http://www.tyan.com...
  • Page 37 √ √ √ √ √ √ √ CPU1_DIMM_E0 √ √ √ CPU1_DIMM_E1 √ √ √ √ √ √ √ √ CPU1_DIMM_F0 √ CPU1_DIMM_F1 √ √ √ √ √ CPU1_DIMM_G0 √ √ CPU1_DIMM_G1 √ √ √ √ CPU1_DIMM_H0 √ CPU1_DIMM_H1 http://www.tyan.com...
  • Page 38 Intel Xeon processor E5-2600v3 product families Support NOTE 1: 1DPC => One dimm per channel NOTE 2: 2DPC => Two dimm per channel  Physical Ranks are used to calculate DIMM Capacity.  Supported DRAM Densities are 4Gb, 8Gb. http://www.tyan.com...
  • Page 39 Memory Installation Procedure Follow these instructions to install memory modules into the S7086. Unlock a DIMM socket by Press the retaining clip outwardly in the following illustration. Align the memory module with the socket，such that the DIMM NOTCH match the KEY SLOT on the socket.

  • Page 40: Attaching Drive Cables

    The following illustrates how to make a SAS Cable connection. If you are in need of SATA/SAS cables or power adapters please contact your local sales representative. P0 Mini-SAS motherboard connector P1, P2, P3, P4 SAS cable backplane connector P5 SAS SGPIO connector (reserved) http://www.tyan.com...

  • Page 41: Installing Add-In Cards

    Doing so allows air to circulate within the chassis more easily, thus improving cooling for all installed devices. NOTE: You must always unplug the power connector from the motherboard before performing system hardware changes to avoid damaging the board or expansion device. http://www.tyan.com...

  • Page 42: Connecting External Devices

    1Gbps LAN Link/Activity LED Scheme Left LED Right LED Description (Link/Activity) (Speed) No Link Link Green 10 Mbps Active Blinking Green Link Green Solid Green 100 Mbps Active Blinking Green Solid Green Link Green Solid Amber 1Gbps Active Blinking Green Solid Amber http://www.tyan.com...

  • Page 43: Installing The Power Supply

    2.12 Installing the Power Supply There are Three (3) power connectors on your S7086 motherboard. The S7086 supports EPS 12V power supply. PWR1: SSI 24-Pin Power Connector Signal Signal V3P3 V3P3 V3P3 -12V PS_ON# PWROK 5VSB +12V +12V V3P3 PWR2: SSI 8-Pin CPU/DIMM Power Connector...

  • Page 44: Finishing Up

    In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor‟s support line. http://www.tyan.com...

  • Page 45: Chapter 3: Bios Setup

    Select the previous value/setting of the field <+> Select the next value/setting of the field <F8> Load Fail Safe default configuration values of the menu <F3> Load the Optimal default configuration values of the menu <F4> Save and exit <Enter> Execute command or select submenu http://www.tyan.com...
  • Page 46 BIOS menus are continually changing due to continual BIOS updates over the product lifespan of the motherboard. The BIOS menus provided are current as of the date when this manual was written. Please visit TYAN‟s website at http://www.tyan.com for information on BIOS updates available for this specific motherboard.

  • Page 47: Main Menu

    It displays BIOS related information. Memory Information This displays the total memory size. System Date Adjust the system date. MM (Months): DD (Days): YYYY (Years) System Time Adjust the system clock. HH (24 hours format): MM (Minutes): SS (Seconds) Access Level Read only. http://www.tyan.com...

  • Page 48: Advanced Menu

    ACPI Settings System ACPI Parameters. Hardware Health Configuration Hardware health Configuration Parameters. Onboard Device Configuration Onboard Device Configuration. PCIe Slot Configuration Onboard PCIe Slot Configuration WatchDog Timer Configuration WatchDog Configuration ASPEED Super IO Configuration System Super IO Chip parameters http://www.tyan.com...
  • Page 49 PCI, PCI-X and PCI Express Settings CSM Configuration CSM Configuration, Enable/Disable Option ROM execution setting,etc Trusted Computing (optional function) Trusted Computing (TPM) settings. NOTE: If no TPM chipset is on, the Trusted Computing submenu will not appear. USB Configuration USB Configuration Parameters. http://www.tyan.com...
  • Page 50 3.3.1 ACPI Settings Enable ACPI Auto Configuration Enable or disable BIOS ACPI Auto Configuration. Disabled / Enabled Enable Hibernation Enables or disables System ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some OS. Disabled / Enabled http://www.tyan.com...
  • Page 51 PWM Minimal Duty Cycle Duty Cycle control range 30% Duty Cycle / 45% Duty Cycle / 60% Duty Cycle BMC Alert Beep BMC Alert Beep On/Off. On / Off PSU Status Monitor PMBus support Disabled / Enabled http://www.tyan.com...
  • Page 52 3.3.2.1 Sensor Data Register Monitoring When you enter the Sensor Data Register Monitoring submenu, you will see the following dialog window pop out. Please wait 8~10 seconds. NOTE 1: SDR can not be modified. Read only. http://www.tyan.com...
  • Page 53 http://www.tyan.com...
  • Page 54 http://www.tyan.com...
  • Page 55 Enabled/Disabled Load Option ROM for LAN Devices. Enabled with PXE / Disabled Onboard LAN #2 Enable or disable the Onboard Network Controller. Enabled / Disabled Load Onboard LAN #2 Option ROM Enabled/Disabled the LAN Option ROM in the Chipset. Enabled with PXE / Disabled http://www.tyan.com...
  • Page 56 Chassis Intrusion detect Enabled: When a chassis open event is detected, the BIOS will record the event. Disabled / PXE NMI Button Enable or disable NMI button. Enabled / Disabled http://www.tyan.com...
  • Page 57 Enable/Disable Load OPTROM for PCIe Slot devices Enabled / Disabled Left Riser Middle PCIe Slot OPTIROM Enable/Disable Load OPTROM for PCIe Slot devices Enabled / Disabled Left Riser Down PCIe Slot OPTIROM Enable/Disable Load OPTROM for PCIe Slot devices Enabled / Disabled http://www.tyan.com...
  • Page 58 Onboard PCLe Slot Link Speed Configuration Auto / Gen1(2.5 GT/s) / Gen2(5 GT/s) / Gen3(8 GT/s) Right Riser Down PCIe Slot Link Speed OPTIROM Onboard PCLe Slot Link Speed Configuration Auto / Gen1(2.5 GT/s) / Gen2(5 GT/s) / Gen3(8 GT/s) http://www.tyan.com...
  • Page 59 3.3.5 Watchdog Timer Configuration Watch Dog Mode Watch Dog Mode Help. Disabled / POST / OS / PowerON NOTE: Watch Dog Timer will appear when Watch Dog Mode is not set to [Disabled]. Watch Dog Timer Watch Dog Timer Help. http://www.tyan.com...
  • Page 60 3.3.6 ASPEED Super IO Configuration Super IO Chip Read only. http://www.tyan.com...
  • Page 61 / IO=3F8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=3E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; http://www.tyan.com...
  • Page 62 Wake system from S5 Enable or disable system wake on alarm event. Select Fixed time, system will wake on the hr::min::sec specified. Select dynamic time, system will wake on the current time+ increase minute(s) Disabled / Fixed time / Dynamic time http://www.tyan.com...
  • Page 63 Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. NOTE: Console Redirection Settings menu only appear when Console Redirection was set to [Enabled]. http://www.tyan.com...
  • Page 64 1‟s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
  • Page 65 VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400 Redirection After BIOS POST The settings specify if bootloader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is always enable means Legacy. Always Enabled / Bootloader http://www.tyan.com...
  • Page 66 1‟s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
  • Page 67 VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400 Redirection After BIOS POST The settings specify if bootloader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is always enable means Legacy. Always Enabled / Bootloader http://www.tyan.com...
  • Page 68 115200 / 9600 / 19200 / 38400 / 57600 Flow Control Flow Control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a „stop‟ signal can be sent to stop the data flow. Once the http://www.tyan.com...
  • Page 69 „start‟ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal. None / Hardware RTS/CTS Data Bits / Parity / Stop Bits Read only. http://www.tyan.com...
  • Page 70 Enables or Disables 64bit capable Devices to be decoded in Above 4G Address Space(Only if System supports 64 bit PCI decoding). Enable / Disabled SR-IOV Supporting If system has SR-IOV capable PCIe devices, this option Enable or Disable Single root IO virtualization Support Enable / Disabled http://www.tyan.com...
  • Page 71 3.3.9.1 PCI Express settings Maximum Payload Set maximum payload of PCI express device or allow system BIOS to select the value. Auto / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes /2048 Bytes / 4096 Bytes http://www.tyan.com...
  • Page 72 Do not launch / UEFI / legacy / Video Controls the execution of UEFI and legacy PXE OpROM Do not launch / UEFI / legacy Other PCI devices Determines OpRom execution policy for devices other than network, storage, or video legacy / UEFI http://www.tyan.com...
  • Page 73 The following BIOS items are available only when Security Device Support is set to [Enable]. TPM State Enable/Disable security Device. NOTE: Your computer will reboot during restart in order to change State of the device. Enabled / Disabled Current Status Information Read only. http://www.tyan.com...
  • Page 74 Disabled EHCI Hand-off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. Enabled / Disabled USB Mass Storage Driver Support Enable/Disable USB Mass Storage Driver Support Enabled Disabled http://www.tyan.com...
  • Page 75 Maximum time the device will take before it properly reports itself to the Host Controller. AUTO uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Auto / Manual http://www.tyan.com...

  • Page 76: Intel Rcsetup Menu

    3.4 Intel RCSetup Menu Processor Configuration Processor Parameters. Advanced Power Management Configuration Advanced power management Parameters. Common RefCode Configuration Common RefCode Configuration. QPI Configuration QPI Configuration Memory Configuration Memory Configuration I/O Configuration (I/O Configuration) PCH Configuration (PCH Configuration) Miscellaneous Configuration (Miscellaneous Configuration) http://www.tyan.com...
  • Page 77 OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3). Enabled Disabled Enables the vanderpool technology, take effect after reboot Enabled Disabled Enable SMX Enables Safer Mode Extensions. Enabled Disabled http://www.tyan.com...
  • Page 78 3.4.1.1 CPU Socket 0/1 Configuration Read only http://www.tyan.com...
  • Page 79 http://www.tyan.com...
  • Page 80 3.4.2 Advanced Power Management Configuration Power Technology Enable the power management features. Custom / Disabled / Energy Efficient NOTE: The following BIOS items are available only when Power Technology is set to [Custom]. http://www.tyan.com...
  • Page 81 When enabled,OS sets CPU frequency according load. When disabled, CPU frequency is set at max non-turbo. Enabled Disabled Turbo Mode Turbo mode allows a CPU logical processor to execute a higher frequency when Enough power is available not exceed CPU defined limits. Enabled Disabled http://www.tyan.com...
  • Page 82 Enable/Disable CPU C3 (ACPI C2) report to OS. Recommended to be disabled Enabled / Disabled CPU C6 Report Enable/Disable CPU C6 (ACPI C3) report to OS. Enabled / Disabled Enhanced Halt State Enables the Enhanced C1E state of the CPU, takes effect after reboot Enabled / Disabled http://www.tyan.com...
  • Page 83 MMIOH Base [63:32]; must be between 4032 - 4078 56T / 48T / 24T /16T / 4T MMIO High Size Select MMIO High Size 256G /128G / 512G /1024G Numa Enable or Disable none uniform Memory Access. (NUMA) Enabled / Disabled http://www.tyan.com...
  • Page 84 Select the QPI Link Frequency. Auto / 6.4GT/s / 9.6GT/s / 8.0GT/s / Auto Limited Link L0p Enable Link L0p Enable: Disable, Enable, Auto (default) Enabled / Disabled Link L1 Enable Link L1 Enable: Disable, Enable, Auto (default) Enabled / Disabled http://www.tyan.com...
  • Page 85 3.4.3.1 QPI Status Submenu Read only http://www.tyan.com...
  • Page 86 Auto / 1333 / 1400 / 1600 / 1800 /1867 / 2000 / 2133 / 2200 / 2400 / 2600 /2667 / Reserved / Reserved / Reserved / Reserved Memory Type Select memory type supported by this platform RDIMMs only / UDIMMs only / UDIMMs and RDIMMs Data Scrambling Enables Data Scrambling Auto / Disabled / Enabled http://www.tyan.com...
  • Page 87 3.4.4.1 Memory Topology Configuration Read only http://www.tyan.com...
  • Page 88 3.4.4.2 Memory Thermal Configuration Set Throttling Mode Configure Thermal throttling mode. Select OLTT or CLTT mode. Disabled / CLTT / OLTT http://www.tyan.com...
  • Page 89 3.4.4.3 Memory Map Configuration Channel Interleaving Select Channel Interleaving setting Auto / 1-way Interleave / 2-way Interleave / 3-way Interleave / 4-way Interleave Rank Interleaving Select rank Interleaving setting Auto / 1-way Interleave / 2-way Interleave / 4-way Interleave / 8-way Interleave http://www.tyan.com...
  • Page 90 Disabled / Mirror / Lockstep Mode Lockstep x4 DIMMs Enable / Disable Lockstep for x4 DIMMs Auto / Disabled / Enabled Memory Rank Sparing Enable / Disable Memory Rank Sparing Disabled / Enabled Device Tagging Enable / Disable Device Tagging Disabled / Enabled http://www.tyan.com...
  • Page 91 3.4.5 I/O Configuration Submenu Read only http://www.tyan.com...
  • Page 92 3.4.5.1 IOAT Configuration Submenu Enable IOAT Control to enable / disable IOAT devices Disabled / Enabled http://www.tyan.com...
  • Page 93 ® 3.4.5.2 Intel VT for Directed I/O Configuration Submenu ® Intel VT for directed I/O (VT-d) ® Enable/Disable Intel I/O Acceleration Technology (I/OAT). Disabled / Enabled http://www.tyan.com...
  • Page 94 3.4.6 PCH Configuration http://www.tyan.com...
  • Page 95 3.4.6.1 PCH Devices Configuration PCH State after G3 Select S0/S5 for ACPI state after a G3. S0 / S5 / Last State http://www.tyan.com...
  • Page 96 3.4.6.2 PCH sSATA Configuration http://www.tyan.com...
  • Page 97 Enable/Disable SATA Ports Hot Plug Support. Disabled / Enabled Spin Up Device AHCI Supports Staggered Spin-up Disabled / Enabled sSATA Device Type Indentify the SATA port is connected to Solid State Drive or Hard Disk Drive Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 98 3.4.6.3 PCH SATA Configuration http://www.tyan.com...
  • Page 99 Enable/Disable SATA Ports Hot Plug Support. Disabled / Enabled Spin Up Device AHCI Supports Staggered Spin-up Disabled / Enabled SATA Device Type Indentify the SATA port is connected to Solid State Drive or Hard Disk Drive Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 100 3.4.6.4 USB Configuration xHCI Mode Mode of operation of xHCI controller. Auto / Smart Auto / Enabled / Disabled / Manual http://www.tyan.com...
  • Page 101 3.4.7 Miscellaneous Configuration Active Video Select active video type Onboard Device / Offboard Device http://www.tyan.com...

  • Page 102: Server Management

    3.5 Server Management Press <Enter> to change the SEL configuration. Enable/Disable interfaces to communicate with BMC. http://www.tyan.com...
  • Page 103 Choose options for reactions to a full SEL. Do Nothing / Erase Immediately Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both. Both / Disabled / Error Code / Progress Code http://www.tyan.com...
  • Page 104 3.5.2 BMC Network Configuration Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Current Setting / Static / Dynamic-Obtained by BMC http://www.tyan.com...

  • Page 105: Security

    3.6 Security Password Description Read only. Administrator Password Install or change the password. User Password Install or change the password. http://www.tyan.com...

  • Page 106: Boot

    Enable or disable wait „ESC‟ key Function. When chassis intrusion CMOS clear or BMC not Response. Disabled / Enabled Endless Boot Enable or disable Endless Boot. Disabled / Enabled Boot Option #1/Boot Option #2 Select the first boot device. Device Name / Disabled http://www.tyan.com...
  • Page 107 3.7.1 Delete Boot Option Configuration Delete Boot Option #1 Sets the system boot order. Device Name / Select one to Delete http://www.tyan.com...

  • Page 108: Save & Exit

    Discard Changes and Reset Reset system setup without saving any changes. Save Options Read only. Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. http://www.tyan.com...
  • Page 109 Restore Defaults Restore/Load Default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. http://www.tyan.com...

  • Page 110: Chapter 4: Diagnostics

    BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user.

  • Page 111: Amibios Post Code (Aptio)

    South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06 Microcode loading 0x07 AP initialization after microcode loading 0x08 North Bridge initialization after microcode loading 0x09 South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com...
  • Page 112 Memory initialization. Configuring memory 0x2F Memory initialization (other) 0x30 Reserved for ASL (see ASL Status Codes section below) 0x31 Memory Installed 0x32 CPU post-memory initialization is started. 0x33 CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) (AP) 0x34 initialization http://www.tyan.com...
  • Page 113 S3 Resume Progress Codes 0xE0 S3 Resume is started (S3 Resume PPI is called by the DXE IPL). 0xE1 S3 Boot Script execution 0xE2 Video repost 0xE3 OS S3 wake vector call 0xE4 – 0xE7 Reserved for future AMI progress codes http://www.tyan.com...
  • Page 114 DXEIPL was not found. DXE Core Firmware Volume was not found. Recovery failed S3 Resume failed Reset PPI is not available. DXE Phase Status Code Description 0x60 DXE Core is started. 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services http://www.tyan.com...
  • Page 115 PCI Bus Hot Plug Controller initialization 0x94 PCI Bus Enumeration 0x95 PCI BUS Request Resources 0x96 PCI Bus Assign Resources 0x97 Console output devices connect 0x98 Console Input devices connect 0x99 Super IO initialization 0x9A USB initialization is started. http://www.tyan.com...
  • Page 116 0xC0 – 0xCF OEM BDS initialization codes DXE Error Codes 0xD0 CPU initialization error 0xD1 North Bridge initialization error 0xD2 South Bridge initialization error 0xD3 Some of the Architectural Protocols are not available 0xD4 PCI resource allocation error. Out of Resources http://www.tyan.com...
  • Page 117 System is waking up from the S3 sleep state. 0x40 System is waking up from the S4 sleep state. System has transitioned into ACPI mode. Interrupt controller is in 0xAC APIC mode. System has transitioned into ACPI mode. Interrupt controller is in 0xAA APIC mode. http://www.tyan.com...

  • Page 118: Appendix I: Fan And Temp Sensors

    (rpm) Temp Sensor: SAS_Air_Outlet (RT22),and MB_Air_Inlet(RT23). They detect the system temperature around. NOTE: The system temperature is measured in a scale defined by Intel, not in Fahrenheit or Celsius. http://www.tyan.com...
  • Page 119 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 120 http://www.tyan.com...
  • Page 121 Fan speed of SYS_FAN_5 SYS_FAN_6 Fan speed of SYS_FAN_6 SYS_FAN_7 Fan speed of SYS_FAN_7 SYS_FAN_8 Fan speed of SYS_FAN_8 SYS_FAN_9 Fan speed of SYS_FAN_9 SYS_FAN_10 Fan speed of SYS_FAN_10 SYS_FAN_11 Fan speed of SYS_FAN_11 SYS_FAN_12 Fan speed of SYS_FAN_12 http://www.tyan.com...
  • Page 122 NOTE http://www.tyan.com...

  • Page 123: Glossary

    (reading to or writing from a disk drive a single time is much faster than doing so repeatedly) there is the possibility of losing your data should the system crash. Information in a buffer is temporarily stored, not permanently saved. http://www.tyan.com...
  • Page 124 (like soundcards or keyboards) to access the main memory without involving the CPU. This frees up CPU resources for other tasks. As with IRQs, it is vital that you do not double up devices on a single line. Plug-n-Play devices will take care of this for you. http://www.tyan.com...
  • Page 125 ROM chip which can, unlike normal ROM, be updated. This allows you to keep ® ‟s up with changes in the BIOS programs without having to buy a new chip. TYAN BIOS updates can be found at http://www.tyan.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n-Play devices in the system BIOS.
  • Page 126 PXE (Preboot Execution Environment): one of four components that together make up the Wired for Management 2.0 baseline specification. PXE was designed to define a standard set of preboot protocol services within a client with the goal of allowing networked-based booting to boot using industry standard protocols. http://www.tyan.com...
  • Page 127 NVIDIA s (graphics communications processing units) and NVIDIA MCPs (media and processors). application Depending on the , NVIDIA SLI can deliver as much as two times the performance of a single GPU configuration. http://www.tyan.com...
  • Page 128 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...

  • Page 129: Technical Support

    "TYAN's tech support is some of the most impressive we've seen, with great response time and exceptional organization in general" - Anandtech.com Help Resources: 1. See the beep codes section of this manual.
  • Page 130 (RMA) number. The RMA number Should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. ® TYAN will pay to have the board shipped back to you. Notice for the USA Compliance Information Statement (Declaration of...
