Copyright
Copyright © 2013 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
®
TYAN
is a trademark of MiTAC International Corporation.
®
Intel
is a trademark of Intel
AMI, AMI BIOS are trademarks of AMI Technologies.
®
Microsoft
, Windows
®
Winbond
is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
S7067
Version 1.0
®
Corporation.
®
are trademarks of Microsoft Corporation.
http://www.tyan.com
®
products including liability or
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S7067 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TYAN S7067

Summary of Contents for TYAN S7067

  • Page 1 Corporation and has been reviewed for accuracy and reliability prior to printing. MiTAC assumes no liability whatsoever, and disclaims any express or implied ® warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MiTAC retains the right to make changes to product descriptions and/or specifications at any time, without notice.
  • Page 2 Appendix: Fan and Temp Sensors This section aims to help readers identify the locations of some specific Fan and Temp Sensors on the motherboard. A table of BIOS Temp sensor name explanation is also included for readers’ reference. http://www.tyan.com...

  • Page 3: Table Of Contents

    3.7 Server Management ................ 94 3.8 Event Logs..................97 3.9 Save & Exit ..................98 Chapter 4: Diagnostics................101 4.1 Flash Utility ..................101 4.2 AMIBIOS Post Code (Aptio) ............102 Appendix: Fan and Temp Sensors............109 Glossary....................113 Technical Support .................. 119 http://www.tyan.com...

  • Page 4: Before You Begin

    Check the box contents! The retail motherboard package should contain the following: 1 x S7067 Motherboard 2 x SATA Single Cable 1 x Mini-SAS to SATAx4 Cable 1 x S7067 Quick Installation Guide ® 1 x TYAN Driver CD IMPORTANT NOTE: Sales samples may not come with any of the accessories listed above.

  • Page 5: Chapter 1: Instruction

    S7067 is capable of offering scalable 32 and 64-bit computing, high- bandwidth memory design, and lightning-fast PCI-E bus implementation. The S7067 not only empowers you in today’s demanding IT environment but also offers a smooth path for future application upgradeability. All of these rich feature sets provide the S7067 with the power and flexibility to meet demanding requirements for today’s IT environments.
  • Page 6 /PXE boot / ACPI 2.0 power management /Power on Feature mode after power recovery / User-configurable H/W monitoring / Auto-configurable of hard disk types Form Factor Physical EATX Dimension Board Dimension 12"x13" (305x330mm) Operating OS supported list Please refer to our Intel OS supported list. http://www.tyan.com...
  • Page 7 Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Yes Motherboard (1) S7067 Motherboard Manual (1) Quick Installation Guide Package Installation CD (1) TYAN installation CD Contains (2) SATA signal cables / (1) Mini-SAS cable to 4 x...
  • Page 8 10° C ~ 35° C (50° F~ 95° F) Non-operating Operating - 40° C ~ 70° C (-40° F ~ 158° F) Temp. Environment In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant Yes Package Motherboard (1) S7067 Motherboard Contains Manual (1) Quick Installation Guide http://www.tyan.com...

  • Page 9: Software Specifications

    (2) SATA signal cables Cable SATA (1) Mini-SAS cable to 4 x SATA cables 1.3 Software Specifications For the latest OS (operation system) support and IPMI Configuration Guide, please visit our Web site for information. http://www.tyan.com...
  • Page 10 NOTE http://www.tyan.com...

  • Page 11: Chapter 2: Board Installation

    Caution! To avoid damaging the motherboard and associated components, do not use torque force greater than 7kgf/cm (6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 12: Board Image

    2.1 Board Image S7067 This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...
  • Page 13 NOTE: The Broadcom BMC57810S has two MAC addresses. One is for 10GbE LAN and the other is for iSCSI support. http://www.tyan.com...

  • Page 14: Block Diagram

    2.2 Block Diagram S7067 Block Diagram http://www.tyan.com...

  • Page 15: Mainboard Mechanical Drawing

    2.3 Mainboard Mechanical Drawing http://www.tyan.com...

  • Page 16: Board Parts, Jumpers And Connectors

    The board you receive may not look exactly like the above diagram. The DIMM slot numbers shown above can be used as a reference when reviewing the DIMM population guidelines shown later in the manual. For the latest board revision, please visit our web site at http://www.tyan.com. http://www.tyan.com...
  • Page 17 PCIE slot (x8) Flash Security Override Pin Header Jumpers (J68) ME Recovery Pin Header (J69) LSI 2308 Enable/Disable Jumper (J75) LAN1 LED Pin Header (J5012) Jumper Legend OPEN - Jumper OFF Without jumper cover CLOSED - Jumper ON With jumper cover http://www.tyan.com...
  • Page 18 http://www.tyan.com...
  • Page 19 J30: SATA SGPIO Header for BB HD Board Signal Signal SMBCLK SDATAOUT0 SMBDATA SDATAOUT1 SLOAD SCLOCK VCC3_AUX HDD_FAULT J39: Front Panel Header Signal Signal PWRLED+ V3P3_AUX IDLED+ PWRLED- IDLED- HDDLED+ SYS_FAULT1- HDDLED- SYS_FAULT2- PWR_SW# LAN1LED+ LAN1LED- RESET_SW# SMBDATA SMBCLK IDLED_SW# INTRUSION# LAN2LED+ NMI_SW# LAN2LED- http://www.tyan.com...
  • Page 20 J5012 http://www.tyan.com...
  • Page 21 J14: Front Fan Connector (Reserved for Barebone Fan Board) Signal Signal FAN TACH1 FAN TACH6 FAN TACH2 FAN TACH7 FAN TACH3 FAN TACH8 FAN TACH4 FAN TACH9 FAN TACH5 FAN TACH10 FAN PWM2 FAN PWM1 FAN TACH11 SMBDATA FAN TACH12 SMBCLK V3P3_AUX FAN PWM3 http://www.tyan.com...
  • Page 22 LED1 J31/J36 http://www.tyan.com...
  • Page 23 P3V3_AUX ID_SW_L State Color Description Blue System identified System not identified NOTE: The ID LED can be activated remotely using IPMI. http://www.tyan.com Please visit the TYAN Web Site at to download the latest IPMI Configuration Guide for more details. http://www.tyan.com...
  • Page 24 http://www.tyan.com...
  • Page 25 5. Reconnect power connectors to the motherboard and power on system. J38: SPI Write Protect Pin Header GPIO_WP# SPI_WP # Pin 1-2 Closed: Normal Mode (Default) Pin 2-3 Closed: SPI Write Protect Mode J75: LSI 2308 Enable/Disable Jumper RESET Pin 1-2 Closed: Enable (Default) Pin 2-3 Closed: Disable http://www.tyan.com...

  • Page 26: Installing The Processor And Heatsink

    2.5 Installing the Processor and Heatsink The types of processors supported by the S7067 are listed in the 1.2 Hardware http://www.tyan.com Specifications section on page 5. Check our website at ® the latest list of validated Intel processors for this specific motherboard.
  • Page 27 Install the processor and make sure the gold arrow is located in the right direction. Close the CPU socket cover. Close the socket lever. http://www.tyan.com...
  • Page 28 Intel . Please refer to the Intel website: http://www.intel.com ® The following diagram illustrates how to install the heatsink on the Intel H3 Socket: Apply the thermal grease. Install the CPU heatsink. http://www.tyan.com...
  • Page 29 Secure the heatsink screws. Connect the heatsink fan cable. http://www.tyan.com...

  • Page 30: Thermal Interface Material

    CPU lid (applying too much will actually reduce the cooling). NOTE: Always check with the manufacturer of the heat sink & processor to ensure that the thermal interface material is compatible with the processor and meets the manufacturer’s warranty requirements. http://www.tyan.com...

  • Page 31: Tips On Installing Motherboard In Chassis

    Note: Be especially careful to look for extra stand-offs. If there are any stand-offs present that are not aligned with a mounting hole on the motherboard, it will likely short components on the back of the motherboard when installed. This will cause malfunction and/or damage to your motherboard. http://www.tyan.com...
  • Page 32 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MiTAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. http://www.tyan.com...

  • Page 33: Installing The Memory

    2.8 Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com details of the type of memory recommended for your motherboard.  Intel Xeon Processor E5-2600 Series processor supports 4 channels per CPU.
  • Page 34 4. Dual-rank DIMMs are recommended over single-rank DIMMs. 5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if populating only a single DIMM per channel. 6. Always install with CPU0 Socket and DIMM_0 Slot first, following the alphabetical order. http://www.tyan.com...
  • Page 35 CPU1_DIMM_A1 √ CPU1_DIMM_A2 √ √ √ √ √ √ √ √ CPU1_DIMM_B0 √ √ CPU1_DIMM_B1 √ CPU1_DIMM_B2 √ √ √ √ √ √ CPU1_DIMM_C0 √ √ CPU1_DIMM_C1 √ CPU1_DIMM_C2 √ √ √ √ CPU1_DIMM_D0 √ √ CPU1_DIMM_D1 √ CPU1_DIMM_D2 http://www.tyan.com...
  • Page 36 The speeds are estimated targets and will be verified through simulation.  For 3SPC/3DPC -Rank Multiplication (RM) >= 2.  DDP -Dual Die Package DRAM stacking. P –Planer monolithic DRAM Die.  Romley-EP/EX platform does not support 3DPC when using E5-2400 LRDIMMs. http://www.tyan.com...
  • Page 37 Command Address Timing is 1N.  QR RDIMM are supported but not validated by Intel/PMO in a homogenous environment. The coverage will have limited system level testing, no signal integrity testing, and no interoperability testing. The passing QR RDIMMs will be web posted. http://www.tyan.com...
  • Page 38 Memory Installation Procedure Follow these instructions to install memory modules into the S7067. Press the locking levers in the direction shown in the following illustration. Align the memory module with the socket. The memory module is keyed to fit only one way in the socket.

  • Page 39: Attaching Drive Cables

    SATA/SAS cables or power adapters please contact your local sales representative. Attaching SAS Cables The following illustrates how to make a SAS Cable connection. If you are in need of SATA/SAS cables or power adapters please contact your local sales representative. http://www.tyan.com...

  • Page 40: Installing Add-In Cards

    Doing so allows air to circulate within the chassis more easily, thus improving cooling for all installed devices. NOTE: You must always unplug the power connector from the motherboard before performing system hardware changes to avoid damaging the board or expansion device. http://www.tyan.com...

  • Page 41: Connecting External Devices

    No Link Link Solid Green Linked at 10 Mbps Active Blinking Green Link Solid Green Solid Green Linked at 100 Mbps Active Blinking Green Solid Green Link Solid Green Solid Yellow Linked at 1000 Mbps Active Blinking Green Solid Yellow http://www.tyan.com...
  • Page 42 Lower LED (LED2) Upper LED (LED1) Description Link/Activity Speed No Link Link Solid Green Solid Yellow Linked at 1 Gbps Active Blinking Green Solid Yellow Link Solid Yellow Solid Yellow Linked at 10 Gbps Active Blinking Yellow Solid Yellow http://www.tyan.com...

  • Page 43: Installing The Power Supply

    2.12 Installing the Power Supply three (3) There are power connectors on your S7067 motherboard. The S7067 supports EPS 12V power supply. PW1: ATX 24-Pin Power Connector Signal Signal V3P3 V3P3 V3P3 -12V PS_ON# PWROK Reserved 5VSB +12V +12V V3P3...

  • Page 44: Finishing Up

    In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. http://www.tyan.com...

  • Page 45: Chapter 3: Bios Setup

    The table below shows how to navigate in the setup program using the keyboard. Function Left/Right Arrow Keys Change from one menu to the next Up/Down Arrow Keys Move between selections Enter Open highlighted section PgUp/PgDn Keys Change pages Change options Exit http://www.tyan.com...
  • Page 46 The following pages provide the details of BIOS menu. Please be noticed that the BIOS menu are continually changing due to the BIOS updating. The BIOS menu provided are the most updated ones when this manual is written. Please visit TYAN’s website at http://www.tyan.com for the information of BIOS updating. http://www.tyan.com...

  • Page 47: Main Menu

    Set the Date. Use Tab to switch between Date elements. Day MM (Months): DD (Days): YYYY (Years) System Time Set the Time. Use Tab to switch between Date elements. HH (24 hours format): MM (Minutes): SS (Seconds) Access Level Read only. http://www.tyan.com...

  • Page 48: Advanced Menu

    This section facilitates configuring advanced BIOS options for your system. PCI Subsystem Settings PCI, PCI-X and PCI Express Settings. ACPI Settings System ACPI Parameters. Trusted Computing Trusted Computing settings. CPU Configuration CPU Configuration Parameters. SATA Configuration SATA Devices Configuration. Onboard Device Configuration Onboard Device Configuration. http://www.tyan.com...
  • Page 49 USB Configuration USB Configuration Parameters. Hardware Health Configuration Hardware Health Configuration Parameters. Super IO Configuration System Super IO Chip Parameters. Serial Port Console Redirection Serial Port Console Redirection. http://www.tyan.com...
  • Page 50 Space (Only if System Supports 64 bit PCI Decoding). Disabled / Enabled Single Root I/O Virtualization Single Root I/O Virtualization (SR-IOV). SR-IOV is a specification that allows a PCIe device to enable/disable multiple separate physical PCIe devices. Enabled / Disabled http://www.tyan.com...
  • Page 51 Enable or disable System ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some OS. Disabled / Enabled ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Suspend Disabled / S1 only (CPU Stop Clock) http://www.tyan.com...
  • Page 52 Enabled / Disabled Pending Operation Schedule an operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device. None / Enable Take Ownership / Disable Take Ownership / TPM Clear http://www.tyan.com...
  • Page 53 When disabled only one thread per enabled core is enabled. Enabled / Disabled Active Processor Cores Number of cores to enable in each processor package. All / 1 / 2 / 3 Limit CPUID Maximum Disabled for Windows XP. Disabled / Enabled http://www.tyan.com...
  • Page 54 OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3). Enabled / Disabled Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. Enabled / Disabled http://www.tyan.com...
  • Page 55 3.3.4.1 Socket 0/1 CPU Information Read only. http://www.tyan.com...
  • Page 56 Enable/Disable Intel StepSpeed. Disabled / Enabled Turbo Mode Enable/Disable Turbo Mode. Enabled / Disabled P-STATE Coordination Change P-State coordination type. HW_ALL / SW_ALL / SW_ANY CPU C3 Report Enable/Disable CPU C3 (ACPI C2) report to OS. Disabled / Enabled http://www.tyan.com...
  • Page 57 Long duration power limit in Watts. Factory Long Duration Maintained Read only. Long Duration Maintained Time window which the long duration power is maintained. Recommended short duration power limit Read only. Short duration power limit Short duration power limit in Watts. http://www.tyan.com...
  • Page 58 3.3.5 Runtime Error Logging Runtime Error Logging Support Enable or disable Runtime Error Logging Support. Enabled / Disabled http://www.tyan.com...
  • Page 59 Read only. SATA Mode Selection Determines how SATA controller(s) operate. IDE / AHCI / RAID / Disabled Port 0/1/2/3/4/5 Hot Plug SATA Ports Hot Plug Support. Enabled / Disabled Port 0/1/2/3/4/5 Staggered Spin-up AHCI Supports Staggered Spin-up. Disabled / Enabled http://www.tyan.com...
  • Page 60 Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE / ISCSI NOTE: The ISCSI function is only supported in LAN1. LAN2 OPROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE LAN 82574 Enabled/Disabled the LAN in the Chipset. Enabled / Disabled http://www.tyan.com...
  • Page 61 LAN3 OPROM Enabled/Disabled the LAN Option ROM in the Chipset. Disabled / PXE LSI2308 OPROM Enable/disable LSI2308 OPROM in the Chipset. Enabled / Disabled http://www.tyan.com...
  • Page 62 3.3.8 PCIe Slot Configuration PCIe SLOT1 OPTROM Enabled/Disabled OPTROM for PCIe slot. Enabled / Disabled PCIe SLOT1 LINK SPEED Select target Link Speed Gen1, Gen2 or Gen3 GEN1 / GEN2 / GEN3 http://www.tyan.com...
  • Page 63 Maximum time the device will take before it properly reports itself to the Host Controller. AUTO uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Auto / Manual http://www.tyan.com...
  • Page 64 1 / 0 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / Until Press ESC Info Error Message Info Error Message Support Enabled/Disabled. Disabled / Enabled Summary Screen Summary Screen Support Enabled/Disabled. Disabled / Enabled http://www.tyan.com...
  • Page 65 BMC Alert Beep On/Off. On / Off 3.3.11.1 Sensor Data Register Monitoring When you enter the Sensor Data Register Monitoring submenu, you will see the following dialog window pop out. Please wait 8~10 seconds. NOTE: SDR can not be modified. Read only. http://www.tyan.com...
  • Page 66 http://www.tyan.com...
  • Page 67 http://www.tyan.com...
  • Page 68 3.3.12 Super IO Configuration Super IO Chip Read only. http://www.tyan.com...
  • Page 69 / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=3E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Change Settings SUART clock source. 24MHZ/13 / 24MHz http://www.tyan.com...
  • Page 70 Serial Port for Out-Of-Band Management/Windows Emergency Services (EMS) Console Redirection Console redirection enable or disable. Disabled / Enabled Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. http://www.tyan.com...
  • Page 71 1’s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
  • Page 72 Redirection after BIOS POST The settings specify if BootLoader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is Always Enable which means Legacy Console Redirection is enabled for Legacy OS. Always Enable / BootLoader http://www.tyan.com...
  • Page 73 VT-UTF8 / VT100 / VT100+ / ANSI Bits per Second Select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. 115200 / 9600 / 19200 / 38400 / 57600 http://www.tyan.com...
  • Page 74 ‘stop’ signal can be sent to stop the data flow. Once the buffers are empty, a ‘start’ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal. None / Hardware RTS/CTS Data Bits / Parity / Stop Bits Read only. http://www.tyan.com...

  • Page 75: Chipset Menu

    3.4 Chipset Menu North Bridge North Bridge Parameters. South Bridge South Bridge Parameters. WatchDog Timer Configuration WatchDog Timer Configuration. http://www.tyan.com...
  • Page 76 Enabled / Disabled MPST Support Enable or Disable MPST Support. Along with enabling MPST Support, it also requires NUMA to be enabled and Channel Interleaving to be set to 1-way for MPST tables to be published. Disabled / Enabled http://www.tyan.com...
  • Page 77 DDR Speed Force DDR Speed. Auto / Force DDR3 800 / Force DDR3 1066 / Force DDR3 1333 / Force DDR3 1600 http://www.tyan.com...
  • Page 78 With Manual option user can force the PCI resource allocation across multiple IOHs based on the ratios selected. Auto / Manual No Snoop Optimization This configuration requires that No Snoop in PCI Express Settings is enabled. It is recommended that this option is left at default (VC1). VC1 / VC0/VCP/VC1 http://www.tyan.com...
  • Page 79 MMIOH Size Select number of 1GB contiguous regions to be assigned MMIOH space per CPU. 64G / 1G / 2G / 4G / 8G / 16G / 32G / 128G MMCFG Base Select the MMCFG BASE Values. 80000000 0xA0000000 0xC0000000 http://www.tyan.com...
  • Page 80 3.4.1.1.1 Intel® VT for Directed I/O Configuration Submenu ® Intel VT-d ® Enable/Disable Intel Virtualization Technology Directed I/O. Enabled / Disabled Coherency Support Enable/Disable VT-d Engine Coherency Support. Disabled / Enabled ATS Support Enable/Disable VT-d Engine Address Translation Services support. Enabled / Disabled http://www.tyan.com...
  • Page 81 Read only. QPI Link Speed Mode Select the QPI link speed as either the Fast Mode or the Slow Mode. Fast / Slow QPI Link Frequency Select Select the QPI Link Frequency. Auto / 6.4GT/s / 7.2GT/s / 8.0GT/s http://www.tyan.com...
  • Page 82 3.4.1.3 DIMM Information Submenu Read only. http://www.tyan.com...
  • Page 83 Select a minimum assertion width of the SLP_S4# signal. 4-5 Seconds / 1-2 Seconds / 2-3 Seconds / 3-4 Seconds Chassis Intrusion Detection Enabled: When a chassis open event is detected, the BIOS will display the event. Disabled / Enabled http://www.tyan.com...
  • Page 84 Disabled / POST / OS / PowerON NOTE: Watch Dog Timer will not appear when Watch Dog Mode is set to [Disabled]. Watch Dog Timer Watch Dog Timer Help. 2 MINS / 4 MINS / 6 MINS / 8 MINS / 10 MINS http://www.tyan.com...

  • Page 85: Boot

    INT 19 Trap Response BIOS reaction on INT19 trapping by option ROM: IMMEDIATE - execute the trap right away; POSTPONED - execute the trap during legacy boot. Immediate / Postponed Endless Boot Enable or disable Endless Boot. Disabled / Enabled http://www.tyan.com...
  • Page 86 Boot Option #1/Boot Option #2/Boot Option #3 Sets the system boot order. Device Name / Disabled USB Device BBS Priorities Sets the system boot order. Device Name / Disabled http://www.tyan.com...
  • Page 87 3.5.1 Add New Boot Option Add Boot Option Specify name for new boot option. Path for Boot Option Enter the path to the boot option In the format fsx: \path\filename.efi Boot Option File Path Read only. Create Create the newly formed boot option. http://www.tyan.com...
  • Page 88 3.5.2 Delete Boot Option Delete Boot Option Remove an EFI boot option from the boot order. Select one to delete / UEFI: Built-in EFI Shell http://www.tyan.com...

  • Page 89: Security

    Confirm New Password window will pop out to ask for confirmation. User Password Set user password in the Create New Password window. After you key in the password, the Confirm New Password window will pop out to ask for confirmation. http://www.tyan.com...
  • Page 90 (PK) is enrolled and Platform is operating in User mode and 2. CMS function is disabled in Setup. Enabled / Disabled Secure Boot Mode Secure Boot mode selector. “Custom” Mode allows for more flexibility changing Image Execution policy and Secure Boot Key management. Standard / Custom http://www.tyan.com...
  • Page 91 Deny Execute / Always Execute / Always Deny / Allow Execute / Defer Execute / Query User Fixed Media Image Execution Policy per device path on Security Violation. Deny Execute / Always Execute / Always Deny / Allow Execute / Defer Execute / Query User http://www.tyan.com...
  • Page 92 Save new PK Insert factory default key(s) or load a file formatted as 1. EFI Variable as Time- Based Authenticated Header or 2. Key Certificate list starting with EFI_SIGNATURE_LIST Header or Single Key Certificate in X509_DER, RSA2048_DER or SHA256_BIN format. http://www.tyan.com...
  • Page 93 Append Var to DBX Insert factory default key(s) or load a file formatted as 1. EFI Variable as Time- Based Authenticated Header or 2. Key Certificate list starting with EFI_SIGNATURE_LIST Header or Single Key Certificate in X509_DER, RSA2048_DER or SHA256_BIN format. http://www.tyan.com...

  • Page 94: Server Management

    3.7 Server Management Press <Enter> to change the SEL event log configuration. Enable/Disable interfaces to communicate with BMC. http://www.tyan.com...
  • Page 95 Choose options for reactions to a full SEL. Do Nothing / Erase Immediately Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both. Both / Disabled / Error Code / Progress Code http://www.tyan.com...
  • Page 96 3.7.2 BMC Network Configuration Configuration Address Source Select the configure LAN channel parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Do Nothing / Static / Dynamic-Obtained by BMC http://www.tyan.com...

  • Page 97: Event Logs

    3.8 Event Logs Read only. http://www.tyan.com...

  • Page 98: Save & Exit

    Discard Changes and Reset Reset system setup without saving any changes. Save Options Read only. Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. http://www.tyan.com...
  • Page 99 Restore Defaults Restore/Load Default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. http://www.tyan.com...
  • Page 100 NOTE http://www.tyan.com...

  • Page 101: Chapter 4: Diagnostics

    BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user.

  • Page 102: Amibios Post Code (Aptio)

    South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06 Microcode loading 0x07 AP initialization after microcode loading 0x08 North Bridge initialization after microcode loading 0x09 South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com...
  • Page 103 CPU post-memory initialization is started 0x33 CPU post-memory initialization. Cache initialization 0x34 CPU post-memory initialization. Application Processor(s) (AP) initialization 0x35 CPU post-memory initialization. Boot Strap Processor (BSP) selection 0x36 CPU post-memory initialization. System Management Mode(SMM) initialization 0x37 Post-Memory North Bridge initialization is started http://www.tyan.com...
  • Page 104 Reserved for future AMI progress codes S3 Resume Error Codes 0xE8 S3 Resume Failed 0xE9 S3 Resume PPI not Found 0xEA S3 Resume Boot Script Error 0xEB S3 OS Wake Error 0xEC – 0xEF Reserved for future AMI error codes http://www.tyan.com...
  • Page 105 CPU DXE initialization (CPU module specific) 0x67 CPU DXE initialization (CPU module specific) 0x68 PCI host bridge initialization 0x69 North Bridge DXE initialization is started 0x6A North Bridge DXE SMM initialization is started 0x6B North Bridge DXE initialization (North Bridge module specific) http://www.tyan.com...
  • Page 106 USB initialization is started 0x9B USB Reset 0x9C USB Detect 0x9D USB Enable 0x9E -0x9F Reserved for future AMI codes 0xA0 IDE initialization is started 0xA1 IDE Reset 0xA2 IDE Detect 0xA3 IDE Enable 0xA4 SCSI initialization is started http://www.tyan.com...
  • Page 107 No Console Output Devices are found 0xD7 No Console Input Devices are found 0xD8 Invalid password 0xD9 Error loading Boot Option (LoadImage returned error) 0xDA Boot Option is failed (StartImage returned error) 0xDB Flash update is failed 0xDC Reset protocol is not available http://www.tyan.com...
  • Page 108 System is waking up from the S3 sleep state 0x40 System is waking up from the S4 sleep state 0xAC System has transitioned into ACPI mode. Interrupt controller is in PIC mode. 0xAA System has transitioned into ACPI mode. Interrupt controller is in APIC mode. http://www.tyan.com...

  • Page 109: Appendix: Fan And Temp Sensors

    (rpm) Temp Sensor: PCH_Area_Temp, SAS_Area_Temp and M/B_Inlet_Temp. They detect the system temperature around. NOTE: The system temperature is measured in a scale defined by Intel, not in Fahrenheit or Celsius. http://www.tyan.com...
  • Page 110 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 111 Temperature of CPU0_DIMM_C0 Slot CPU0_DIMM_C1 Temperature of CPU0_DIMM_C1 Slot CPU0_DIMM_D0 Temperature of CPU0_DIMM_D0 Slot CPU0_DIMM_D1 Temperature of CPU0_DIMM_D1 Slot CPU1_DIMM_A0 Temperature of CPU1_DIMM_A0 Slot CPU1_DIMM_A1 Temperature of CPU1_DIMM_A1 Slot CPU1_DIMM_B0 Temperature of CPU1_DIMM_B0 Slot CPU1_DIMM_B1 Temperature of CPU1_DIMM_B1 Slot http://www.tyan.com...
  • Page 112 Fan speed of SYS_FAN_5 SYS_FAN_6 Fan speed of SYS_FAN_6 SYS_FAN_7 Fan speed of SYS_FAN_7 SYS_FAN_8 Fan speed of SYS_FAN_8 SYS_FAN_9 Fan speed of SYS_FAN_9 SYS_FAN_10 Fan speed of SYS_FAN_10 SYS_FAN_11 Fan speed of SYS_FAN_11 SYS_FAN_12 Fan speed of SYS_FAN_12 http://www.tyan.com...

  • Page 113: Glossary

    (reading to or writing from a disk drive a single time is much faster than doing so repeatedly) there is the possibility of losing your data should the system crash. Information in a buffer is temporarily stored, not permanently saved. http://www.tyan.com...
  • Page 114 (like soundcards or keyboards) to access the main memory without involving the CPU. This frees up CPU resources for other tasks. As with IRQs, it is vital that you do not double up devices on a single line. Plug-n-Play devices will take care of this for you. http://www.tyan.com...
  • Page 115 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep ® up with changes in the BIOS programs without having to buy a new chip. TYAN ’s BIOS updates can be found at http://www.tyan.com...
  • Page 116 PXE (Preboot Execution Environment): one of four components that together make up the Wired for Management 2.0 baseline specification. PXE was designed to define a standard set of preboot protocol services within a client with the goal of allowing networked-based booting to boot using industry standard protocols. http://www.tyan.com...
  • Page 117 NVIDIA s (graphics communications processing units) and NVIDIA MCPs (media and processors). application Depending on the , NVIDIA SLI can deliver as much as two times the performance of a single GPU configuration. http://www.tyan.com...
  • Page 118 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...

  • Page 119: Technical Support

    "TYAN's tech support is some of the most impressive we've seen, with great response time and exceptional organization in general" - Anandtech.com Help Resources: 1. See the beep codes section of this manual.
  • Page 120 (RMA) number. The RMA number Should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. ® TYAN will pay to have the board shipped back to you. Notice for the USA Compliance Information Statement (Declaration of...
