Optal Clear 40 Installation & Operation Manual

40 series; 70 series; 80 series; 110 series; 120 series; 130 series; 150 series; 170 series; 200 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ORTAL Heating Solutions Ltd.
INSTALLATION & OPERATION MANUAL
The ORTAL direct vent (and ORTAL power vent with separate manual) gas appliances have
been tested and approved by CSA for safety and efficiency for use with either Natural Gas (NG)
or Propane (LPG).
Standard references:
ANSI Z21.88-2009 - Vented Gas Fireplace Heaters
CLASS 2901 84 – DOMESTIC HEATERS (GAS) Vented Fireplace – Certified to US Standard
CLASS 2901 04 – DOMESTIC HEATERS (GAS) Vented Fireplace
Pictured Above: ORTAL's Clear 110 TS
1
