Summary of Contents for AMP HSF1
-
Page 2: Table Of Contents
HSP1 List of Items Required HSF1 Power Amplifier 4.1. HSF1 Specifications 4.2. HSF1 Mechanical Drawing and Connector Pin-Outs 4.3. HSF1 List of Items Furnished 4.4. HSF1 Optional Accessories ... -
Page 3: Introduction
H Series Power Amplifiers are developed and manufactured by Advanced Microwave Products (AMP). H Series Power Amplifiers are best operated with AMP’s V, P, E, or F series transmitters (as noted by the specific amplifier) but are compatible with many other analog FM transmitters on the market. -
Page 4: Hha1 High Power Amplifier
HHA1 HIGH POWER AMPLIFIER 2.1. HHA1 Specifications AMN-H-D... -
Page 5: Hha1 Mechanical Drawing And Connector Pin-Outs
2.2. HHA1 Mechanical Drawing and Connector Pin-Outs 2.3. HHA1 List of Items Furnished (1) HHA1 High Power Amplifier (configured as ordered) • (1) CBLRF50-SSS20 - 2" SMA/SMA Coax (for use with EST1 or PMT1) or CBLRF50-SSS30 - 3" • SMA/SMA Coax (for use with VST1, PST1, or FMT1) 2.4. -
Page 6: Hsp1 Power Amplifier
HSP1 POWER AMPLIFIER 3.1. HSP1 Specifications AMN-H-D... -
Page 7: Hsp1 Mechanical Drawing And Connector Pin-Outs
3.2. HSP1 Mechanical Drawing and Connector Pin-Outs 3.3. HSP1 List of Items Furnished (1) HSP1 Power Amplifier (configured as ordered) • (1) CBLRF50-SSS10 - 1" SMA/SMA Coax • 3.4. HSP1 Optional Accessories SNK3520-S05B0 - Heatsink • 3.5. HSP1 List of Items Required Antenna, Type SMA Plug (Male) Connector •... -
Page 8: Hsf1 Power Amplifier
HSF1 Power Amplifier 4.1. HSF1 Specifications AMN-H-D... -
Page 9: Hsf1 Mechanical Drawing And Connector Pin-Outs
4.2. HSF1 Mechanical Drawing and Connector Pin-Outs 4.3. HSF1 List of Items Furnished (1) HSF1 Power Amplifier (configured as ordered) • (1) WHSHSF1-S08S0 - Power Mating Connector • (1) CBLRF50-SSS10 - 1" SMA/SMA Coax • 4.4. HSF1 Optional Accessories SNK3520-S05B0 – Heatsink •... -
Page 10: Safety Precautions
SAFETY PRECAUTIONS Power Amplifiers should be handled with caution like any electrical or electronic device. Do not handle the units or associated cabling with wet hands or materials. Connections should be made only to previously-tested, active power sources (outlets or batteries) of the correct voltage, and each connector should be inserted only into its designated port. -
Page 11: Preparation For Use
25 feet apart to prevent serious damage to or destruction of the receiver’s front end. Verify DC power supplies are between +11 and +16 Vdc. For the HHA1 and HSF1, with the DC Power Cable DISCONNECTED from the power amplifier, connect DC power supply to DC Power Cable (Pin1 = positive DC input, Pin2 = negative DC input (ground)). -
Page 12: Setting Power Output Level
(or driven to 3.3 Vdc by an external device) or grounded (or driven to below 0.6 Vdc by an external device) to command the unit to the desired output level. If the HSF1 power amplifier is commanded to a power level with which the unit is not equipped, the unit will default to standby (disabled) until a valid power level command is applied. -
Page 13: Use Of Heat Sink
7.4. Use of Heat Sink HHA1, HSP1, and HSF1 Power Amplifiers operating at or above 500 mW require the use of a heat sink or must be securely fastened to an adequate heat sinking object or surface. Advanced Microwave Products recommends the appropriate heatsink as noted in the Optional Accessories section for each product. -
Page 14: Maintenance Instructions
Power Amplifier configuration. If these efforts fail, do not attempt to repair the unit. Please contact AMP with a detailed description of the problem. Depending on the nature of the problem, AMP may provide further troubleshooting assistance or advise the entire system be returned for repair and retest. -
Page 15: Warranty Statement
BUYER shall pay all shipping charges, duties, and fees for the return of products to AMP. All warranty services will be carried out at AMP’s facility. AMP will pay for the return of products to the BUYER.
