HSD1 Power Amplifier Quick Start Guide
STEP
Connect ampli er RF output SMA connector to antenna
Connect the RF output from the CDT1 video transmitter to
STEP
RF input SMA connector.
Connect power, Communications (if required), and
STEP
enable inputs to the MDM-9P connector *see reverse side
When setting up your system, the transmit and receive
Note
antennas should be greater than 25 feet apart to
prevent serious damage to or destruction of the
receiver's front end
For Technical Support, Contact AMP
at (775) 345-9933 (9 am - 5 pm PST)
or engineering@advmw.com
Advertisement
Table of Contents
Related Manuals for AMP HSD1
Summary of Contents for AMP HSD1
- Page 1 All manuals and user guides at all-guides.com HSD1 Power Amplifier Quick Start Guide STEP Connect ampli er RF output SMA connector to antenna Connect the RF output from the CDT1 video transmitter to STEP RF input SMA connector. Connect power, Communications (if required), and...
- Page 2 The HSD1 power ampli er does not require any con guring unless it includes optional variable output level. If included, the power level is set via commands using the Comm port. See the HSD1 Interface Control Document (ICD) for more details.
