AMP HSP1 Quick Start Manual

Hide thumbs Also See for HSP1:

HSP1 Power Ampli er Quick Start Guide

STEP

Connect ampli er RF output SMA connector to antenna

STEP

Verify the connected transmitter's output power is less

than the maximum input power rating (noted on HSP1

chassis) of the HSP1 power ampli er, then connect the RF

output from transmitter to RF input SMA connector.

Wire power, enable, and high/low power control (if

STEP

applicable) *see reverse side

When setting up your system, the transmit and receive

Note

antennas should be greater than 25 feet apart to

prevent serious damage to or destruction of the

receiver's front end

For Technical Support, Contact AMP

at (775) 345-9933 (9 am - 5 pm PST)

or engineering@advmw.com

Table of Contents

Need help?

Do you have a question about the HSP1 and is the answer not in the manual?

Page 1 Verify the connected transmitter’s output power is less than the maximum input power rating (noted on HSP1 chassis) of the HSP1 power ampli er, then connect the RF output from transmitter to RF input SMA connector. Wire power, enable, and high/low power control (if...
Page 2 How to Con gure Your Ampli er The HSP1 power ampli er does not require any con guring unless it includes optional dual RF power output. If included, the power level is set using the yellow wire shown above. To set the ampli er to the higher output power level, leave the yellow wire open (unconnected).
