HSN1 Power Ampli er Quick Start Guide
STEP
Connect ampli er RF output SMA connector to antenna
STEP
Connect the RF output from the CNT1 video transmitter to
RF input SMA connector.
STEP
Connect power, Communications (if required), and
enable inputs to the MDM-9P connector *see reverse side
When setting up your system, the transmit and receive
Note
antennas should be greater than 25 feet apart to
prevent serious damage to or destruction of the
receiver's front end
For Technical Support, Contact AMP
at (775) 345-9933 (9 am - 5 pm PST)
or engineering@advmw.com
