AMP HSF1 Quick Start Manual

Hide thumbs Also See for HSF1:

HSF1 Power Ampli er Quick Start Guide

STEP

Connect ampli er RF output SMA connector to antenna

STEP

Verify the connected transmitter's output power is less

than the maximum input power rating (noted on HSF1

chassis) of the HSF1 power ampli er, then connect the RF

output from transmitter to RF input SMA connector.

STEP

Connect power, RF power select (if applicable), and

enable inputs to the Hirose DF13 connector *see

reverse side

When setting up your system, the transmit and receive

Note

antennas should be greater than 25 feet apart to

prevent serious damage to or destruction of the

receiver's front end

For Technical Support, Contact AMP

at (775) 345-9933 (9 am - 5 pm PST)

or engineering@advmw.com
