ParaBody 889 User Manual

ParaBody 889 User Manual

Weight stack option
Hide thumbs Also See for 889:

Advertisement

Table of Contents

889 WEIGHT STACK OPTION
CLASS H
PART # 7192901
REV. A
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 889107
Revision: 09/26/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 889 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ParaBody 889

Summary of Contents for ParaBody 889

  • Page 1 889 WEIGHT STACK OPTION USER’S GUIDE CLASS H PART # 7192901 REV. A WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 889107 Revision: 09/26/01...

  • Page 2: Important Safety Information

    Use only the pin provided by the manufacturer. If unsure, call your authorized ParaBody dealer. NOTE: In a continual effort to improve our products, specifications are subject to change 2001 Life Fitness, a division of Brunswick Corporation. All rights reserved. © ParaBody is a trademark of Brunswick Corporation www.parabody.com...

  • Page 3: Tools Required For Assembly

    Please note: * Thank you for purchasing the ParaBody 889 Weight Stack Option. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.

  • Page 4: Parts List

    PART # DESCRIPTION 6814308 UPRIGHT 6800602 ADJ FOOT SUPPORT 6814008 STACK BASE 6813708 TOP BOOM 6801102 LAT BAR SUPPORT 6816501 76” GUIDE ROD 6274402 LOW ROW BAR 6725302 LAT BAR 3116201 3-1/2” PULLEY 3116101 4-1/2” PULLEY 6832801 124” CABLE 6671002 115-3/4”...
  • Page 5 FIGURE 2 STEP 2: • Insert two 2” END CAP (16) into the ends of the STACK BASE (3) as shown in FIGURE 2. • Attach four 3/4 X 1-1/2” GLIDES (24) to the inside of the tube on the STACK BASE (3) as shown in FIGURE 2 using the following steps: •...
  • Page 6 UPRIGHT FRAME FIGURE 4 STEP 4: • NOTE: It may be necessary to loosen the 1/2 X 3-1/4” BOLTS of the LOWER CROSS SUPPORT connecting to the UPRIGHT FRAME before beginning STEP 4. • SECURELY assemble the STACK BASE (3) and the UPRIGHT (1) to the LOWER CROSS SUPPORT using two 3/8 X 4” BOLTS (38), four 3/8”...
  • Page 7 HEAD PLATE ASSEMBLY STEP 6: • Insert two GUIDE RODS (6) into the STACK • Slide two WEIGHT STACK CUSHIONS (26) • Using EXTREME CARE slide twenty WEIGHT • Carefully Slide the HEAD PLATE ASSEMBLY (39 & 40) down over the GUIDE RODS (6) onto the weight stack as shown in FIGURE 6.
  • Page 8 FIGURE 7 UPRIGHT STEP 7: • NOTE: It may be necessary to loosen the 1/2 X 3-1/4” BOLTS of the UPPER CROSS SUPPORT connecting the UPRIGHT FRAME before beginning STEP 7. • Insert two GUIDE ROD BUSHINGS (27) into the TOP BOOM (4) as shown in FIGURE 7. •...
  • Page 9 FIGURE 8 3/8” LOW HEIGHT 29 STEP 8: • SECURELY assemble the LAT BAR SUPPORT (5) to the TOP BOOM (4) using one 3/8 X 2-3/4” (32) and one 3/8” LOW HEIGHT LOCK NUT (29). See FIGURE 8. • Slide two VINYL CAPS (22) over the LAT BAR SUPPORT (5) as shown in FIGURE 8. FIGURE 9 STEP 9: •...
  • Page 10 FIGURE 10 STEP 10: • Slide ring of WEIGHT STACK SELECTOR PIN (17) over top of 20 HOLE SELECTOR SHAFT (39) • Screw the threaded end of the CABLE (12) approximately 3/4” into the end of the 20 HOLE SELECTOR SHAFT (39) and tighten jam nut securely.
  • Page 11 FIGURE 11 STEP 11: • Route the threaded end of the 124” CABLE (11) through the slot of the UPRIGHT (1) then SECURELY assemble one 4-1/2” PULLEY (10) to the UPRIGHT (1) using two 3/8 X 2-3/4” BOLTS (32), two 3/8” FLANGE SPACERS (33), two 3/8” WASHERS (30), and two 3/8” LOCK NUTS (31).
  • Page 12 FIGURE 12 STEP 12: • Loop the 124” CABLE (11) around one 3-1/2” PULLEY (9) as shown in FIGURE 12. • LOOSELY assemble the 3-1/2” PULLEY (9) to the 3/16 X 1-3/4 X 5-1/4” PLATES (23) using one 3/8 X 2” BOLT (35), two 3/8” WASHERS (30), and one 3/8”...
  • Page 13 CABLE accordingly and retighten the jam nut. Thank you for purchasing the Parabody 889 WEIGHT STACK OPTION. If unsure of proper use of equip- ment, call your local Parabody distributor or call the Parabody customer service department at (800) 328-9714.

  • Page 14: Maintenance

    YOU MAY NEED SERVICE YOU WILL BE ASKED FOR THIS INFORMATION. REMEMBER TO FILL OUT YOUR WARRANTY REGISTRATION CARD AND MAIL BACK. MODEL #________________________ SERIAL #_________________________ DATE OF PURCHASE: _____________ DEALERS NAME: _________________ DEALERS PHONE #_______________ Thank you for purchasing the ParaBody 889 Weight Stack Option. MAINTENANCE...

  • Page 15: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 16 Life Fitness Italia S.R.L. Via Elvas 92 39042 Bressanone Italy Phone: 39 (472) 835-470 Fax: 39 (472) 833-150 Life Fitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LIFE FITNESS www.parabody.com...
