Winnebago 2009 Spirit Operator's Manual
  1. Manuals
  2. Brands
  3. Winnebago Manuals
  4. Motorhomes
  5. 2009 Spirit
  6. Operator's manual
Winnebago 2009 Spirit Operator's Manual

Winnebago 2009 Spirit Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
About this Manual ............................................................................................................................ 1-1
Safety Messages Used in this Manual .............................................................................................. 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Front Axle Tire Alignment ............................................................................................................... 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Occupant and Cargo Carrying Capacity Label ................................................................................. 1-3
Vehicle Certification Label ............................................................................................................... 1-4
specifications and Capacitites ........................................................................................................... 1-5
Owner and Vehicle Information ....................................................................................................... 1-7
2009 New Vehicle Limited Warranty ............................................................................................... 1-8
General Warnings ............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and Propane Gas ....................................................................................................................... 2-1
LP Gas Leaks .................................................................................................................................... 2-2
Propane Gas Leak Detector .............................................................................................................. 2-2
Carbon Monoxide Warning .............................................................................................................. 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-3
Smoke Alarm .................................................................................................................................... 2-4
Fire Extinguisher ............................................................................................................................... 2-4
Electrical ........................................................................................................................................... 2-5
Loading ............................................................................................................................................. 2-5
Maintenance ...................................................................................................................................... 2-5
Emergency Exits ............................................................................................................................... 2-5
Formaldehyde Information ............................................................................................................... 2-6
Mold, Moisture, and Your Motor Home ........................................................................................... 2-7
Roadside Emergency ........................................................................................................................ 2-8
Jump Starting .................................................................................................................................... 2-9
Engine Overheat ............................................................................................................................... 2-9
Seats - Driver/Co-Pilot ..................................................................................................................... 3-1
Fold-Down Dinette Seat ................................................................................................................... 3-1
Seat Belts .......................................................................................................................................... 3-1
Child Restraints ................................................................................................................................. 3-2
Keys .................................................................................................................................................. 3-3
KeyOne™ Lock System ................................................................................................................... 3-3
Hazard Warning Flashers .................................................................................................................. 3-3
Rev. 0915090914

TABLE OF CONTENTS

Copyright 2008 Winnebago Industries, Inc. All rights reserved.
Part No. 161500-09-005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2009 Spirit and is the answer not in the manual?

Questions and answers

Related Manuals for Winnebago 2009 Spirit

Summary of Contents for Winnebago 2009 Spirit

  • Page 1: Table Of Contents

    Seats – Driver/Co-Pilot ........................3-1 Fold-Down Dinette Seat ........................3-1 Seat Belts ............................3-1 Child Restraints ..........................3-2 Keys ..............................3-3 KeyOne™ Lock System ........................3-3 Hazard Warning Flashers ........................3-3 Rev. 0915090914 Part No. 161500-09-005 Copyright 2008 Winnebago Industries, Inc. All rights reserved.
  • Page 2 Table Of Contents Mirrors – Power sideview Exterior ....................3-4 Rearview Monitor System ........................ 3-4 Battery Boost Switch ........................3-5 Air Conditioner/Heater – Automotive (Dash) .................. 3-5 Radio – In-Dash ..........................3-5 Sirius® Plug and Play Satellite Radio ....................3-6 Engine Access –...
  • Page 3 Table Of Contents Electrical System – House 12-Volt DC .................... 6-6 Auxiliary Battery Disconnect Switch ....................6-6 Battery Access ..........................6-6 Battery Care ............................6-7 Circuit Breakers and Fuses – House 12-Volt ..................6-8 7 – PLUMBING Fresh Water System .......................... 7-1 Water Pump ............................
  • Page 4 Table Of Contents Wood Furniture and Cabinetry ......................9-8 10 – SLIDEOUT ROOMS AND LEVELING Slideout Room Travel Lock ......................10-1 Slideout Room Operation – Electric ....................10-2 Slideout Room – Extreme Weather Precaution ................10-3 Slideout Room Troubleshooting – Electric ..................10-4 Slideout Emergency Retraction –...
  • Page 5 Tool Storage ............................ 12-8 Roof Ladder ............................ 12-8 Effects of Prolonged Occupancy ....................12-9...

  • Page 7: Introduction

    DANGER indicates a directly hazardous are intended as a guide, and in no way situation which, if not avoided, will result extend the responsibilities of Winnebago in death or serious personal injury. Industries beyond the standard written warranty as presented in this manual.

  • Page 8: Pre-Delivery Inspection

    National Highway Traffic Safety Administration a feature item. (NHTSA) in addition to notifying Winnebago Industries, Inc. PRE-DELIVERY INSPECTION If NHTSA receives similar complaints, it may...

  • Page 9: Occupant And Cargo Carrying Capacity Label

    SECTION 1 – INTRODUCTION OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to or near the Vehicle Certification Label. It contains vehicle occupant and cargo carrying capacity along with the number of seat belt positions in the vehicle.

  • Page 10: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 11: Specifications And Capacitites

    SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITITES Model Length 29' 9" 31' 2" Exterior Height w/AC 11' 5" 11' 5" Exterior Width 8' 5" 8' 5" Exterior Storage (cu. ft.) 59.6 33.9 Awning Length Interior Height 6' 8" 6' 8" Interior Width 8' 0"...
  • Page 12 SECTION 1 – INTRODUCTION Specifications and Capacities Notes: Ford® E450 Chassis, 6.8L SEFI V10 engine, 305-hp, automatic transmission, TorqShift™, 5-speed with auto overdrive, 4-wheel ABS, 115-amp. alternator, dual air bags, Trailer Hitch 5,000-lb. drawbar/350 lbs. maximum ve tongue weight & wiring w/7-pin connector. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of typically equipped unit.

  • Page 13: Owner And Vehicle Information

    Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 14: 2009 New Vehicle Limited Warranty

    ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
  • Page 15 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.

  • Page 17: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...

  • Page 18: Lp Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS • Never use an open flame to test for LP gas LP GAS LEAKS leaks. Replace all protective covers and caps on LP system after filling. Make sure valve is The following procedures are located in the closed and the door is latched securely.

  • Page 19: Carbon Monoxide Warning

    SECTION 2 – SAFETY AND PRECAUTIONS The best protection against carbon monoxide entry into the vehicle body is a properly WARNING maintained engine exhaust and ventilation system. It is recommended that the exhaust system and body be inspected by a qualified EXPLOSION HAZARD: DO NOT use an motor home service center: open flame to test for gas leaks.

  • Page 20: Smoke Alarm

    InfoCase for further instructions. may not be recommended for RV application. Replacement We recommend obtaining a replacement from ® your Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with a similar model. Other brands Further Information may not be recommended for RV application.

  • Page 21: Electrical

    We recommend obtaining a MAINTENANCE replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier. •...

  • Page 22: Using Slider Windows As Emergency Exits

    SECTION 2 – SAFETY AND PRECAUTIONS To open, pull on the red plastic strap at the bottom of the window to remove the rubber cord that holds the window in place. Pull on the rubber cord until it is completely removed. This allows the window to be pushed out.

  • Page 23: Mold, Moisture, And Your Motor Home

    If Mold Is Present, What Will natural for a motor home to be introduced into an ® Winnebago Industries environment with mold spores. If Winnebago Industries determines that mold Mold is a plant and requires its own special ® ® is present in the Winnebago...

  • Page 24: Roadside Emergency

    SECTION 2 – SAFETY AND PRECAUTIONS If Winnebago Industries determines that mold • When you have come to a stop, activate your is present due to conditions it determines is not a hazard flashers to warn other motorists, then result of a manufacturing defect found within the exit the vehicle carefully.

  • Page 25: Jump Starting

    SECTION 2 – SAFETY AND PRECAUTIONS ® Winnebago Industries does not assume ENGINE OVERHEAT responsibility for damage incurred while towing this vehicle. If you see or hear steam escaping from the engine compartment or have any other reason to NOTE: Consult the chassis manual for any...

  • Page 27: Driving Your Motor Home

    SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to features installed or adapted to the dash and driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.

  • Page 28: Child Restraints

    SECTION 3 – DRIVING YOUR MOTOR HOME Lap/Shoulder Belts one person use the same safety belt at any one time, and do not let the safety belts become See your chassis manual for instructions on damaged by pinching them in the doors or in the proper fastening, adjustment, and releasing of seat mechanism.

  • Page 29: Keys

    The key number for your coach is registered in our factory database, so if you ever lose your ® keys, any Winnebago Industries dealership can order a new key for you. The dinette table must be in the lowered position when a child seat is in use.

  • Page 30: Mirrors - Power Sideview Exterior

    SECTION 3 – DRIVING YOUR MOTOR HOME MIRRORS – POWER SIDEVIEW EXTERIOR –If Equipped Always adjust mirrors for maximum rear visibility before driving off. Make sure the seat is adjusted for proper vehicle control and that you are sitting back squarely into the seat. The mirrors may also contain heating elements to de-fog or de-ice the mirror glass during cold weather operation.

  • Page 31: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTOR HOME Further Information If your motor home is equipped with this optional system, refer to the InfoCase for further instructions provided by the manufacturer. BATTERY BOOST SWITCH This switch can be used to draw emergency starting power from the house batteries to start the engine if the chassis battery is discharged.

  • Page 32: Sirius Plug And Play Satellite Radio

    SECTION 3 – DRIVING YOUR MOTOR HOME See the manufacturer’s information in your InfoCase for operating instructions. Radio Remote Controls A steering wheel mounted remote control for the radio lets you change radio stations or CD selections without taking your eyes off the road or hands off the wheel.

  • Page 33: Engine Access - Interior

    SECTION 3 – DRIVING YOUR MOTOR HOME When your Sirius radio is connected via the SiriusConnect Docking Kit to your headunit, the buttons and controls of the Sirius radio will be disabled, and a SiriusConnect message or logo will be displayed. To remove the satellite unit from the docking station, press the release button while pulling the radio out of the docking station.

  • Page 34: Suspension Alignment And Tire Balance

    SECTION 3 – DRIVING YOUR MOTOR HOME AIR SPRINGS – REAR HELPER WARNING (AIR BAGS) –If Equipped Make sure all replacement tires are of the The rear air helper springs (air bags) are an same size and ply rating as those enhancement to the standard suspension system installed as original equipment.

  • Page 35: Lights

    SECTION 3 – DRIVING YOUR MOTOR HOME LIGHTS All exterior lights should be checked for proper operation each time the vehicle is prepared for a trip. Any bulbs which fail to light should be checked and replaced, when necessary, with a new bulb of the same size. A failure of more than one light, such as both taillights not operating, may indicate a burned out fuse.

  • Page 37: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. REFRIGERATOR The refrigerator in your coach can operate Bubble must be at least 1/2 inside circle from either of two energy sources available to the Normal vehicle leveling to provide comfort...

  • Page 38: Refrigerator Service Access Compartment

    SECTION 4 – APPLIANCES AND SYSTEMS running. If electricity is lost, it will automatically switch over to Gas operation if gas is available. • Temperature Setting - Start at the coldest setting to ensure coldest temperature in the freezer compartment, then adjust warmer as necessary after cold* food has been added.

  • Page 39: Range Hood

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information See the appliance manufacturer’s information provided in your InfoCase for instructions on replacement of light bulbs and replacement or cleaning of grease filter elements. Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, and proper ventilation when using the cooking Underside...

  • Page 40: Water Pump Switch

    SECTION 4 – APPLIANCES AND SYSTEMS The propane level is registered by a sending unit on the tank. The gauge mounted on the side of the tank will give a more accurate indication of actual tank level if needed. Battery Charge Meter Press and Hold the “Levels Test”...

  • Page 41: Water Heater - Gas

    SECTION 4 – APPLIANCES AND SYSTEMS NOTE: Some models may also have a pump WATER HEATER - GAS/ switch in the water system compartment ELECTRIC on the outside of the coach. –If Equipped WATER HEATER – GAS (with Motoraid water heating system) The gas/electric water heater has a dual power -If Equipped feature.

  • Page 42: Pressure-Temperature Relief Valve

    SECTION 4 – APPLIANCES AND SYSTEMS PRESSURE-TEMPERATURE RELIEF VALVE On occasion, water may be seen seeping from the water heater pressure temperature relief valve. This is no cause for repair or replacement of the valve. Gas Water Heater Switch (Located on Systems Monitor Panel) For Electric Operation Turn on the Water Heater electric element...

  • Page 43: Motoraid Water Heater

    SECTION 4 – APPLIANCES AND SYSTEMS CAUTION Any leak in the heat exchanger or its supply or return lines could cause loss of coolant and subsequent engine failure. We recommend that you periodically inspect these connecting lines and the heater to insure that no leaks have developed.
  • Page 44 SECTION 4 – APPLIANCES AND SYSTEMS NOTE: If heat does not come out of the heat ducts after a minute or so the burner is not lit. Turn thermostat off for 3-5 minutes, check to be sure propane gas tank valve is open and tank is not empty, then try steps 2-4 again.

  • Page 45: Furnace-A/C Thermostat Operation Chart

    SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...

  • Page 46: Ducted Roof Air Conditioning System

    SECTION 4 – APPLIANCES AND SYSTEMS temperatures begin to reduce the efficiency of the a specific area of the coach or to route heat pump. The heat pump will not operate when cool air away from a specific area. If too the outside temperature falls below 36 degrees F.

  • Page 47: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY WARNING The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and Do not alter or remove propane tank handled properly, this system is safe and gauge at any time.

  • Page 48: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN GE R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.

  • Page 49: Propane Gas Leaks

    SECTION 5 – PROPANE GAS • Exercise caution at all times. Be familiar with PROPANE GAS WARNINGS the distinctive odor of propane gas. If a leak is AND PRECAUTIONS suspected, turn off the supply valve immediately. Have the propane gas system It is illegal for vehicles equipped with propane checked by your dealer or other qualified tanks to travel on certain roadways or through...

  • Page 50: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS WARNING WARNING Propane cylinders shall not be placed or Visually inspect the pressure regulator stored inside the vehicle. vent periodically for blockage by Propane cylinders are equipped with accumulated debris or insect nests, etc. safety devices that relieve pressure by Vent obstruction could result in excessive discharging propane to the atmosphere.

  • Page 51: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.

  • Page 53: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...

  • Page 54: Power Center

    SECTION 6 – ELECTRICAL POWER CENTER (Converter) The power converter is generally located in a lower cabinet face in the galley or living area, depending on the floorplan of your model. The converter power panel contains the house electrical system 120-volt circuit breakers and 30 Amp Receptacle 12-volt fuses.

  • Page 55: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL (lights or motors or both) should be turned off to reduce total load. Also, inspect the power CAUTION converter to make sure ventilation is not obstructed. Do not block the converter cover vents in CIRCUIT BREAKERS – HOUSE any way.

  • Page 56: Ground Fault Circuit Interrupter

    SECTION 6 – ELECTRICAL An exterior outlet is also located on the outside of the coach near the entrance door or in WARNING a storage compartment on the passenger side of the coach. The GFCI will not completely eliminate GROUND FAULT CIRCUIT the risk of electrical shock.

  • Page 57: Operation Warnings And Cautions

    SECTION 6 – ELECTRICAL Operation Warnings and Cautions WARNING The exhaust of all internal combustion engines contains carbon monoxide (CO). This poisonous gas is colorless, odorless, tasteless, and lighter than air. The exhaust systems of both your motor home engine and your generator engine have been installed with your safety in mind.

  • Page 58: Electrical System - House 12-Volt Dc

    SECTION 6 – ELECTRICAL ELECTRICAL SYSTEM – AUXILIARY BATTERY HOUSE 12-VOLT DC DISCONNECT SWITCH (AUX BATT) The DC voltage system consists of the chassis battery, the 12-volt house batteries, and the 12- The AUX BATT disconnect switch lets you volt power converter. disconnect the house batteries from the 12-volt system of your coach during storage periods to Converter...

  • Page 59: Battery Care

    SECTION 6 – ELECTRICAL If a battery sits unused for 30 days or more, especially during warm weather, it can develop a deposit of sulfate crystals on the metal plates inside the battery. This condition is called “sulfating” and prevents the battery from either releasing or accepting a charge.

  • Page 60: Circuit Breakers And Fuses - House 12-Volt

    SECTION 6 – ELECTRICAL • Check the state of charge periodically to avoid • Fluid level check may be omitted if equipped discharge or sulfating. with maintenance-free batteries. To ensure that the battery will always accept and hold a charge, follow these simple WARNING maintenance practices: •...

  • Page 61: Volt Fuse Panel

    SECTION 6 – ELECTRICAL A label on the panel states the amperage rating and circuit protected for each fuse or breaker. 12-Volt Fuse Panel The fuse panel is on the right-hand side of the power converter. 12-Volt House Fuses The fuse panel accepts only blade type plug-in fuses.

  • Page 63: Plumbing

    SECTION 7 – PLUMBING 2. Attach an RV city water hose from the FRESH WATER SYSTEM external water source to the city water connection typically located in the water The fresh water system provides water to the service compartment or on the left sidewall of galley sink, shower, bathroom lavatory, toilet and your vehicle.

  • Page 64: Water Pump

    SECTION 7 – PLUMBING Water pressure regulators are commonly available at any well stocked RV dealership and many large retail discount or home supply centers. WATER PUMP When your coach is not connected to a city water supply, water is supplied from the fresh water tank by a water system demand pump.

  • Page 65: Cold Water Filter

    SECTION 7 – PLUMBING 2. Turn water pump switch to “OFF” position. • Place a container beneath the filter to catch any water remaining in the waterlines during 3. Fill water tank. filter removal. 4. Open all faucets, hot and cold. •...

  • Page 66: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING chlorine solution. One gallon of this solution should be used for each 15 gallons of tank capacity. 2. Complete filling of tank with fresh water. 3. Open each faucet in the coach and run the water until a distinct odor of chlorine can be detected in the water discharged.

  • Page 67: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING tank, this will result in a 6.7 ppm level of chlorine, which should kill harmful bacteria and slime-forming organisms. • Chlorine may be removed from drinking water by the cold water filter at the galley faucet (if equipped) or by installing an activated carbon water purifier at the galley sink cold water line or a separate drinking water faucet with filter.

  • Page 68: Waste Water System

    SECTION 7 – PLUMBING See winterizing instructions at the end of this section to prepare the toilet for storage in freezing conditions. Further Information See the toilet manufacturer’s operation information in your InfoCase for complete operating, care, and maintenance information. WASTE WATER SYSTEM (Holding Tanks) Holding Tank Dump Valves...

  • Page 69: Holding Tank Heater

    SECTION 7 – PLUMBING Using On-Site Sewer Hook-Ups The drain hose may remain attached to the dump outlet and be routed out the bottom of the compartment while the motor home is parked and connected to an on-site sewage hook-up. The center outlet section may be swiveled downward for better hose alignment and drainage.

  • Page 70: Water Heater Bypass Valve

    SECTION 7 – PLUMBING D R A I N D R A I N C L O S E C L O S E L I N E - E N D V A L V E I N - L I N E V A L V E Waterline Drain Valves (Typical)

  • Page 71: Winterizing Procedures

    SECTION 7 – PLUMBING CAUTION Leave bypass valve handle in NORMAL FLOW position if draining water and blowing out waterlines. Place in BYPASS position ONLY when using antifreeze solution in water lines. WINTERIZING PROCEDURES Using exterior shower to drain waterline You can winterize the water and plumbing (Typical view- appearance on your coach may differ) system of your coach using one of the following...
  • Page 72 A “blow-out” plug can be (See “Winterizing Optional Appliances” ® ® purchased at any Winnebago or Itasca instructions at the end of this section.) dealer. If not, proceed to the next step. 9. Drain Water Heater. Turn off the water...
  • Page 73 SECTION 7 – PLUMBING 18. Empty the water pump strainer filter bowl to avoid water freezing and cracking the filter CAUTION bowl. See “Water Pump” previously in this section. Limit air pressure to 30 psi to avoid Dump and Clean Holding Tanks damage to pump or waterlines.
  • Page 74 SECTION 7 – PLUMBING water heater with antifreeze. This feature is located near the water pump in the water center or utility compartment. CAUTION Leave Bypass valve handle in “Normal Operation” position if draining water and blowing out waterlines. Place in “Bypass” position ONLY when using antifreeze solution in waterlines.
  • Page 75 SECTION 7 – PLUMBING See Water System Drain Valve chart at the end RV Antifreeze Siphon Tube of this section for location on your coach. in water center or near water pump (insert into container of RV water system antifreeze) 4.

  • Page 76: Winterizing Optional Appliances

    SECTION 7 – PLUMBING 15. Pour about one cup of RV antifreeze down each drain for the galley sink, lavatory sink, and shower/tub. This fills the drain trap pipes to prevent holding tank odors from entering the coach during storage. Dump and Clean Holding Tanks 16.
  • Page 77 SECTION 7 – PLUMBING 4. Press ON/OFF Button (OUT). Unplug the washer/dryer from the electrical outlet (or disconnect power). 5. Turn the water supply faucets OFF. Disconnect the inlet hoses from the faucets. Drain any remaining water from the hoses. 6.

  • Page 78: Water System Drain Valve Locations

    SECTION 7 – PLUMBING To use Washer/Dryer again: 3. Set the dishwasher controls to the start of the Flush antifreeze from the waterlines, then Rinse cycle and run briefly until antifreeze can be seen inside the dishwasher. 1. Reconnect the water inlet hoses to the 4.
  • Page 79 SECTION 7 – PLUMBING Waterlines: Two (2) valves beneath the removable bottom panel in the bathroom lavatory cabinet. Water Tank: One (1) valve beneath the bed. Lift head of mattress to expose access hole. Water Heater: Drain plug on outside of coach, behind service door. Use socket to remove drain plug.

  • Page 81: Entertainment

    SECTION 8 – ENTERTAINMENT VIDEO SELECTION SYSTEM –If Equipped The video selection system allows you to • The Video Selection System allows you to switch the antenna, cable TV, satellite TV watch DVD’s from either the lounge area system, or VCR/DVD signal to any TV set (main TV), bedroom, or the exterior location in the coach.

  • Page 82: Front Tv Ignition Switch Interlock

    SECTION 8 – ENTERTAINMENT Turn off the master power switch when not FRONT TV IGNITION SWITCH using the TV to conserve house battery charge. INTERLOCK –If Equipped If your coach is equipped with a front overhead TV, it is plugged into a special electrical outlet with a built-in ignition switch interlock.
  • Page 83 SECTION 8 – ENTERTAINMENT 4. Slide TV onto exterior sidewall mounting 2. Lift TV up and away from mounting bracket. bracket. NOTE: Be sure that TV is seated firmly onto Coax mounting bracket before releasing. Cable Power Plug 3. Disconnect power plug and coax cable from back of TV.
  • Page 84 SECTION 8 – ENTERTAINMENT 6. Your TV is now set up for your outdoor viewing pleasure. Coax Cable NOTE: The Aux Battery switch must be turned ON for the system to operate. Reinstalling TV to Interior Mounting Bracket 12-Volt Power Cable Install above two cable ends into the exterior electrical hook-up Coax Cable...

  • Page 85: Audio-Video System Basic Operation

    SECTION 8 – ENTERTAINMENT 2. Lift TV straight up off of exterior sidewall 5. Press bottom half of TV straight back until it mount. “clicks” into locked position. NOTE: Confirm that TV is locked in place by lightly pulling on the bottom of the TV. 3.

  • Page 86: Dvd Home Theater System

    SECTION 8 – ENTERTAINMENT remote (or “ ” button on DVD player) to Play DVD HOME THEATER SYSTEM begin playing the feature. –If Equipped • Volume is adjusted with the DVD remote. TV Sound through Home Theater Speakers When watching TV programs alone, the TV The available DVD home theater system normally plays sound through its own built-in operates from 120-volt AC household current...

  • Page 87: Electrical Inverter

    SECTION 8 – ENTERTAINMENT Provide 12V Power • When the main menu screen appears, use the The TV and DVD player operate on 12-volt arrow buttons on the DC current. DVD remote to select • Turn on the 12-Volt master power the desired entry or (TV) switch, located on the video press the...

  • Page 88: Tv Antenna

    SECTION 8 – ENTERTAINMENT Rotating Antenna for Best Picture *NOTE: Running high-amperage appliances like the TV and DVD on inverter power Make sure antenna is in the “UP” position. can drain the house battery rapidly Pull down on directional handle using both hands unless the chassis engine is running so until it disengages ceiling plate and rotate for best the alternator can charge the batteries.

  • Page 89: Cable Tv Hook-Up

    SECTION 8 – ENTERTAINMENT TV DIGITAL SATELLITE SYSTEM – MANUAL –If Equipped The Digital Satellite Television System allows you to receive TV programs directly from satellite to your coach. The programs are transmitted in digital format so the quality is equal to laser disc or CD.

  • Page 90: Exterior Entertainment Center

    SECTION 8 – ENTERTAINMENT Further Information See the Digital Satellite System owner’s manual in your InfoCase for operation and antenna dish aiming instructions. EXTERIOR ENTERTAINMENT CENTER –If Equipped The exterior entertainment center contains a stereo radio/CD player, electrical outlets and a convenient TV hook-up for your outdoor listening or viewing pleasure.

  • Page 91: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS SLEEPING FACILITIES WARNING Do not exceed 225 lbs. maximum weight capacity. Misuse of ladder could result in death or serious injury. WARNING See Operators Manual before using ladder. • Maximum Capacity: 225 lbs. Do not use sleeping facilities while vehicle is moving.

  • Page 92: Sofa/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS DINETTE/BED CONVERSION –If Equipped (Typical view – your coach may differ) Dinette to Bed • Lower ladder to floor. • Make sure top of ladder ladder is properly engaged onto retainer brackets and ladder is resting firmly on floor before using.
  • Page 93 SECTION 9 – FURNITURE AND SOFTGOODS 3. Arrange dinette cushions to cover bed area. DINETTE/BED CONVERSION (Dream Dinette Table Mechanism) –If Equipped (Typical view – your coach may differ) Dinette to Bed Bed to Dinette 1. Reattach the table onto the wall support and lower the table leg.

  • Page 94: U-Shaped Dinette/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Lower the dinette cushions to hold the edges 2. Turn the lock rod counter-clockwise back into of the table down. locked position. U-SHAPED DINETTE/BED 4. Arrange dinette cushions to cover bed area. CONVERSION –If Equipped (Typical view –...
  • Page 95 SECTION 9 – FURNITURE AND SOFTGOODS 4. Arrange dinette cushions to cover bed area. NOTE: Reverse steps to reassemble to dinette configuration. 1. Release both latches on the table leg to unlock. Round Table Leaf Extension Lift the leaf extension upward then reach beneath the tabletop and slide the support arms outward to hold the extension.

  • Page 96: Sofa Air Bed

    SECTION 9 – FURNITURE AND SOFTGOODS SOFA AIR BED –If Equipped (Typical view – your coach may differ) NOTE: For better protection of the air bed, never inflate in temperatures below freezing and avoid extensive sun exposure. Sofa to Bed 3.

  • Page 97: Pleated Blinds

    SECTION 9 – FURNITURE AND SOFTGOODS 5. Once you have inflated the air bed to reach 3. Lift up end of air bed and fold in black bed your desired firmness, turn the control dial legs. back to the mid “Off” position. The air bed is NOTE: Before folding bed back into the sofa now ready for use.

  • Page 98: Wood Furniture And Cabinetry

    People are drawn to the natural beauty of following photo. ® wood. At Winnebago Industries , our craftsmen work with the art found in each piece of wood to create cabinets of superior quality, backed by the Winnebago Industries warranty.
  • Page 99 SECTION 9 – FURNITURE AND SOFTGOODS change should be expected. As hardwood ages, it will darken when exposed to different types of light. Color differences or changes in wood can also be caused by exposure to harsh chemicals, extreme heat, or other contributing external conditions.

  • Page 101: Slideout Rooms And Leveling

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Secure Lock Rod SLIDEOUT ROOM TRAVEL • Place the flat plate end of the lock rod against LOCK the outer wall of the coach about 6” down –If Equipped from the top edge of the forward end of the retracted slideout room (behind the driver seat Some models are equipped with an in most cases).

  • Page 102: Slideout Room Operation - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOMS so the engine SLIDEOUT ROOM OPERATION alternator can provide maximum power – ELECTRIC for proper operation of the slideout mechanisms. WARNING WARNING Your motor home may have more than one slideout room. Understand which Keep all persons clear of the slideout switch operates which slideout room prior room and moving parts while extending or...

  • Page 103: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Insert the Safety Lock key and turn to activate by raising both right side jacks to let excess water slideout room control switch. flow away from the rooftop weather seal and toward the outside of the slideout roof. Retract •...

  • Page 104: Slideout Room Troubleshooting - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Green light will flash error code if system malfunctions* Slideout Cover-Awning Also, freezing rain and snow can prevent the slideout cover-awning (if equipped) from closing and may cause damage to the cover-awning, slideout room, weather seals, and mechanisms. Service “Reset”...
  • Page 105 SECTION 10 – SLIDEOUT ROOMS AND LEVELING While in the Manual Mode each of the two Green light will flash error code room slide arms are activated by pressing and if system malfunctions* holding the IN and OUT buttons. The “OUT” button will retract the front arm.

  • Page 106: Slideout Emergency Retraction - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT EMERGENCY RETRACTION – ELECTRIC (Front Slideout Room) Crank-In Mode If the room mechanism is malfunctioning and will not retract using the buttons, you will need to manually crank the room in to the travel position. (The room can also be cranked out into the extended position using this method if necessary.)

  • Page 107: Slideout Emergency Retraction - Bedroom

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Crank-In Procedure • Fasten slideout room travel latching device (if equipped) inside the coach before driving the vehicle. • See your dealer for service of the slideout mechanism before using again. Further Information See the Slideout Room operating guide included in your InfoCase for further instructions and troubleshooting information.

  • Page 108: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING GENERAL SLIDEOUT CARE • Wipe outer seals occasionally with talc or 303 brand protectant for smooth quiet operation. • Clean the floors inside before retracting the room to avoid vinyl flooring scratches or carpet pile snags.

  • Page 109: Leveling System

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM –If Equipped The hydraulic leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.

  • Page 110: Checking Hydraulic Oil Level

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING 4. See the Leveling System Operator’s Manual supplied in your InfoCase for troubleshooting instructions or operating the leveling system if jacks fail to retract or any other functions fail. CHECKING HYDRAULIC OIL LEVEL See the Leveling System Operators Manual in your InfoCase for complete maintenance instructions and information.
  • Page 111 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Hydraulic Oil Dipstick (Typical View) NOTE: Overfilling the hydraulic reservoir can cause leakage of oil through the breather cap. Hydraulic Fluid Recommendation ® ® specialty hydraulic fluid or Dexron III automatic transmission fluid is recommended for use in this system.

  • Page 113: Maintenance And Storage

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 114: Exterior Automotive Paint Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
  • Page 115 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.

  • Page 116: Care Of Appliques And Decals

    SECTION 11 – MAINTENANCE AND STORAGE is subjected to various twisting and flexing forces • Fuel or antifreeze spilled on appliques or caused by routine cornering and turning, and by decals should be rinsed off immediately with uneven road surfaces, such as bumps, potholes, water.

  • Page 117: Exterior Lights

    • Butyl alcohol home is parked for an extended period of time. EXTERIOR LIGHTS ® Most Winnebago Industries vehicles have WARNING polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical solvents and cleaners. When cleaning upholstery and fabric, do...
  • Page 118 SECTION 11 – MAINTENANCE AND STORAGE Care Instructions • Spot clean with mild soap and water. • Air dry or, if desired, dry quickly using a hair dryer on warm setting - not hot. • For stubborn stains, use cleaner-degreaser. UltraLeather Cleaning Chart Detergent/ Cleaner/...

  • Page 119: Ceiling Fabric Care

    SECTION 11 – MAINTENANCE AND STORAGE Most commercially available carpet and CEILING FABRIC CARE upholstery cleaners will do an excellent job removing stains. From time to time, additional While using your coach, your ceiling fabric cleaning methods may need to be used to remove may become soiled and require spot cleaning stubborn or difficult stains.

  • Page 120: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE You may have to repeat this procedure more To keep this product looking its best, we than once to achieve desired results. Finish up recommend that you take a few easy precautions. with clean water, using the same method, and General Cleaning blot dry.

  • Page 121: Doors And Windows

    SECTION 11 – MAINTENANCE AND STORAGE Tub and Shower Walls Use care when removing ice or frost from the windows. Always use a plastic ice scraper, never The tub and shower walls in the bathroom one made of metal. Use care when removing ice should be cleaned with mild soap and warm from the mirrors to protect the reflective surfaces.

  • Page 122: Vehicle Storage - Removal

    SECTION 11 – MAINTENANCE AND STORAGE maintenance especially in cold weather. 5. Close all faucets and drain valves that are See “Battery Care” in the Electrical open. section. 6. Add a few gallons of water to the fresh water tank and turn on the water pump to check for 6.
  • Page 123 SECTION 11 – MAINTENANCE AND STORAGE compounds are available from your dealer. See Sealants – Recommended Application page at the end of this section. Also inspect weather seals around doors, etc., and if necessary, have a dealer replace immediately. Ice Maker Start-Up –If Equipped 1.

  • Page 124: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks.
  • Page 125 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items Headlights, Taillights and Marker Lights Turn Signals...
  • Page 126 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...

  • Page 127: Sealants - Recommended Application

    SECTION 11 – MAINTENANCE AND STORAGE SEALANTS – RECOMMENDED APPLICATION 11-15...

  • Page 129: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available CAUTION space when loading your motor home.
  • Page 130 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motor home is to weigh each “corner”...

  • Page 131: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual unacceptable overall vehicle performance. set (left rear duals or right rear duals) should not Maximum safety and satisfaction when towing exceed 6,000 lbs. depends on proper use of correct equipment. Tires must be filled to the recommended air When towing a vehicle behind your motor pressure for the highest loaded tire set on that...

  • Page 132: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS The following diagram shows proper connection of trailer or tow vehicle wiring to the coach light system. The “pigtail” assembly with the (car/trailer end) connector plug should be wired by a qualified technician. Provision for an electric brake controller is located near the steering column.

  • Page 133: Entry Step - Manual

    SECTION 12 – MISCELLANEOUS transmission, drive line, drive axle, and others. equipped with a Class IV hitch have a The tow vehicle brakes may be rated for label limiting vertical tongue load to 500 operation at GVWR, not GCWR. lbs. On a 228" wheelbase, a 500-lb. load on a hitch 11' from the rear axle will NOTE: State or provincial laws/regulations may apply about 800 lbs.

  • Page 134: Entry Step - Electric

    SECTION 12 – MISCELLANEOUS ENTRY STEP – ELECTRIC –If Equipped WARNING Do not use step unless fully extended. Do NOT stand on step when vehicle ignition switch is turned to either the “On” or “Start” position. The step will automatically retract, which may cause personal injury.

  • Page 135: Windows

    SECTION 12 – MISCELLANEOUS Vertical Slider Windows WINDOWS Vertical windows have spring-loaded catches on both sides of the window that pop out to hold Crank-Out Windows the window in its fully raised position. Press the Turn the crank-out knob clockwise to open catches outward toward the frames while window, counterclockwise to close.

  • Page 136: Manual Awning

    SECTION 12 – MISCELLANEOUS To Operate Ceiling Ventilator Sometimes this seal firmness can inhibit complete latching of the compartment doors if 1. Turn the Dome Crank Knob to raise the dome they are simply “dropped shut” or closing force is about 3"...

  • Page 137: Humidity And Condensation

    SECTION 12 – MISCELLANEOUS The ladder on your motor home is provided EFFECTS OF PROLONGED for limited access to the roof. OCCUPANCY Walking or working on the roof should be left to qualified service personnel using proper safety Your motor home was designed primarily for equipment in a safe environment.
  • Page 139 INDEX 2009 New Vehicle Limited Warranty ..1-8 Engine Access – Interior ......3-7 About this Manual ........1-1 Engine Cooling System ....... 3-7 Air Conditioner Filter ........ 4-10 Engine Overheat .......... 2-9 Air Conditioner/Heater – Entry Step – Electric ........12-6 Automotive (Dash) ........
  • Page 140 Index Occupant and Cargo Carrying Capacity Sofa Air Bed ..........9-6 Label ............1-3 Sofa/Bed Conversion ........9-2 Owner and Vehicle Information ....1-7 specifications and Capacitites ...... 1-5 Plastic Parts – Cleaning ......11-4 Storage Compartment Doors ..... 12-8 Pleated Blinds ..........

This manual is also suitable for:

2008 outlook

Table of Contents
