c
Heating and Instantaneous Domestic Hot Water
Dimensions
2
3
1
0
4
bar
2
1
3
0
4
bar
The boiler is suitable for the flue types:
• type C 12
• type C 32 xx or C 32 xy
• type C 52
Technical data
Heat input C/H & DHW
Gross
Heat output C/H & DHW Combi 80 :
Gross
Max. operating pressure C/H circuit
Expansion vessel net capacity
Expansion vessel initial pressure
Electrical consumption
Voltage
Electrical protection index
Fuses
Nominal gas flow rate at 15°C and 1013 mbar
- Natural gas ( G 20) at 20 mbar
- Butane gas ( G 30) at 28 mbar
- Propane gas ( G 31) at 37 mbar
Injectors and gas valves seat diameter
- Solenoid restrictor diameter
- Gas valve restrictor diameter
- Manifold injectors (16)
MAINTENANCE AND
SERVICE GUIDE
Fanned Flue Combination Boiler
Fig. 1
Combi 80 :
11.73 to 28.70 kW
Combi 100 :
15.43 to 34.5 kW
9.5 to 24 kW
Combi 100 :
12.5 to 28 kW
:
2.5 bar
:
5.44 l
:
0.7 bar
:
150 w Max 3,4 w Min
:
230 v
:
IP44
:
2 A and 1.25 A
Maximum
power 24 kW
2.74 m
2.04 kg/h
2.00 kg/h
Natural gas
2.60 mm
6.70 mm
1.23 mm
These Instructions Must Be Left With The Appliance.
212
721
850
380
Outer case dimensions :
- Height : 850
- Width : 440 (minimum space required 450)
- Depth : 380
DHW flow rate at @ 30°C Combi 80 :
DHW flow rate at @ 35°C Combi 80 :
Minimum DHW operating flow rate
Minimum DHW working pressure
Maximum DHW working pressure
Gas category
BRITONY Combi SE 80
Minimum
power 9.5 kW
3
/h
1.22 m
0.91 kg/h
0.89 kg/h
BRITONY Combi SE 80
Butane or Propane
1.75 mm
4.90 mm
0.70 mm
360
50
67
235
232
54 54 54 54
88
I
J K L M N
J Heating flow
K D.H.W. flow
L Gas supply
M Cold water inlet
N Heating return
Combi 100 :
Combi 100 :
BRITONY Combi SE 100
Maximum
power 28 kW
3
/h
3.34 m
3
/h
2.45 kg/h
2.42 kg/h
BRITONY Combi SE 100
Natural gas
2.90 mm
no resrictor required
1.26 mm
All dimensions in mm
L
J K
M N
32
I
Safety valve outlet
11.4 l/min
13.4 l/min
9.85 l/min
11.48 l/min
:
2 l/min
:
0.5 bar
:
10 bar
:
II 2H 3+
Minimum
power 12.5 kW
1.57 m
3
/h
1.17 kg/h
1.15 kg/h
Butane or Propane
2.00 mm
6.70 mm
0.76 mm
