The EUROLITE DMX LED Operator 4 is suitable for the following devices:
EUROLITE LED PS-36/10 RGB Spot 30° ......................... No. 51913505
EUROLITE LED PS-86 RGB Spot 30° .............................. No. 51913510
EUROLITE LED PS-86 RGB Flood 120° .......................... No. 51913520
EUROLITE LED T-36 RGB spot,black, 10mm .................. No. 51913581
EUROLITE LED T-36 RGB Spot, alu, 10mm .................... No. 51913583
EUROLITE LED PAR-56 RGB spot,black, 10mm............. No. 51913624
EUROLITE LED PAR-56 RGB Spot, alu, 10mm ............... No. 51913628
EUROLITE LED PAR-64 RGB spot,black, 10mm............. No. 51913634
EUROLITE LED PAR-64 RGB Spot, alu, 10mm ............... No. 51913638
EUROLITE LED PAR-64 RGB spot,white, 10mm ............. No. 5191363B
EUROLITE LED ML-56 RGB 3W 25° spot,black .............. No. 51913660
EUROLITE LED ML-56 RGB 3W 25° spot,silver .............. No. 51913661
EUROLITE LED PAR-56 RGB floor, blk 10mm ................ No. 51913900
EUROLITE LED PAR-56 RGB Floor, alu, 10mm .............. No. 51913920
EUROLITE LED PAR-64 RGB floor, black 10mm............. No. 51913960
EUROLITE LED PAR-64 RGB floor,black 36x1W ............ No. 51913970
EUROLITE LED PAR-64 RGB Floor, alu, 10mm .............. No. 51913980
EUROLITE LED PAR-64 RGB Floor, alu, 36x1W ............. No. 51913990
EUROLITE LED X-PAR-64 Spot, alu, 24x1W ................... No. 51914000
EUROLITE LED X-PAR-64 spot,black, 24x1W ................. No. 51914020
EUROLITE LED PAR-56 RGB 36x3W alu ........................ No. 51914045
EUROLITE LED PAR-56 RGB 36x3W black .................... No. 51914065
EUROLITE LED SLS-183/10 RGB black .......................... No. 51915300
EUROLITE LED Floor SLS-183/10 RGB black ................. No. 51915310
EUROLITE LED Floor SLS-400 RGB DMX....................... No. 51915350
EUROLITE LED Bar RGB 252/10 schwarz 20° ................ No. 51930420
EUROLITE LED Bar RGB 252/10 20° weiß ...................... No. 51930421
EUROLITE LED Bar RGB 252/10 schwarz 40° ................ No. 51930422
EUROLITE LED Bar RGB 252/10 40° weiß ...................... No. 51930423
EUROLITE LED KLS-200 RGB DMX inkl. Case .............. No. 42109700

4.2 Overview

Overview of the control elements
12
1 2
13 14 15
3 4 5 6
16 17 18 19
12/15
7 8
20
00048173.DOC, Version 1.0
9
10
11
