- Page 1 -Series Network Video Recorder Hardware Manual OE3-XRNVR08 model no. model no. OE3-XRNVR16 Please carefully read these instructions before using this product. 28126AC Save this manual for future use.
- Page 2 (including without limitation, damages for loss of business profits, business interruption or loss of business information), even if OPENEYE has been advised of the possibility of such damages and whether in an action or contract or tort, including negligence.
-
Page 3: Important Safeguards
This will prevent damage to the product due to lightning and power line surges. Object and Liquid Entry Points – Never insert foreign objects into the NVR, other than the media types approved by OpenEye, as they may touch dangerous voltage points or short-out parts that could result in a fire or electrical shock. Never spill liquid of any kind on the product. -
Page 4: Notes On Handling
IMPORTANT SAFEGUARDS, continued Damage Requiring Service – Unplug the NVR from the outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the NVR. If the NVR has been exposed to rain or water. -
Page 5: Notes On Maintenance
NOTES ON CLEANING Use a soft dry cloth for cleaning. For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzene, as they may damage the surface of the NVR. If using a chemical saturated cloth to clean the NVR, follow that product’s instructions. - Page 6 WARNING TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,...
-
Page 7: Fcc Statement
RACK MOUNT INSTRUCTIONS Elevated Operating Ambient – If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer. - Page 8 CE NOTICE This product is in conformity with the following European Directives: ELECTROMAGNETIC COMPATIBILITY DIRECTIVE, 89/336/EEC (as amended by 92/31/EECand by Article 5 of 93/68/EEC) per the provisions of: EN 55022:1994 EN 55024:1998 EN 61000-4-4:1995 EN 61000-3-2:1995 CISPR 24:1997 EN 61000-4-5:1995 EN 61000-3-3:1995 EN 61000-4-2:1995 EN 61000-4-6:1995...
-
Page 9: Standard Warranty
Standard Warranty Openeye warrants all new products to be free from defects in workmanship and material under normal use for a period of two years after the date of purchase. Any defective product that falls under this warranty will, at OpenEye's discretion, be repaired or replaced at no additional charge. - Page 10 28126AC...
-
Page 11: Table Of Contents
Table of Contents PREFACE ..................................1 ABOUT THIS GUIDE ..............................1 TECHNICIAN NOTES ............................... 1 INTRODUCTION ................................3 PRODUCT DESCRIPTION ............................3 FEATURES ................................4 CONTROLS AND CONNECTIONS ..........................5 SYSTEM SPECIFICATIONS ............................. 5 FRONT PANEL CONTROLS AND LEDS ......................... 6 REAR PANEL CONNECTORS .......................... - Page 12 NOTES: 28126AC...
-
Page 13: Preface
Only authorized personnel should attempt to repair the NVR. OpenEye reserves the right to make changes to the NVRs represented by this manual without notice. The following text and symbols mark special messages throughout this guide: NOTE: Text set off in this manner indicates topics of interests that can help the user understand the product better. - Page 14 28126AC...
-
Page 15: Introduction
PRODUCT DESCRIPTION The OpenEye Xr-Series NVR is a server that performs as a High Definition Digital Recorder. By utilizing the many features of a computer, including processing power, storage capacity, graphics compression, and security features, the NVR is more powerful than the analog recorders of the past. -
Page 16: Features
FEATURES OpenEye® NVRs include the following new features: Optimized and Designed for Microsoft® Windows XP Embedded® Remote System Operation & Configuration Supports Multiple Simultaneous Remote Connections Connect up to 16 Network Video Devices PAN / TILT / ZOOM Controls Simultaneous Video Search, Playback and Backup... -
Page 17: Controls And Connections
CONTROLS AND CONNECTIONS SYSTEM SPECIFICATIONS OpenEye® state-of-the-art Network Video Recorders are housed in a high performance and versatile 4U Rack-Mount case allowing easy storage of multiple NVRs for enterprise applications. Every OpenEye NVR comes equipped with the latest technology: Intel® Dual Core 3.4 GHz CPU Processor... -
Page 18: Front Panel Controls And Leds
FRONT PANEL CONTROLS AND LEDS The front panel of the NVR contains the devices that will be commonly used for data removal, retrieval, and backup replacement. The most common components and buttons are shown below: Hard Drive Power Buttons Reset Button Power Switch DVD±RW Drive USB Port... -
Page 19: Rear Panel Connectors
REAR PANEL CONNECTORS The rear panel of the NVR contains the connectors used to attach display monitors and network cables to the NVR. The following diagram outlines the location and description of each connector: SVGA Monitor Out S-Video Out Audio AC Power Secondary •... - Page 20 28126AC...
-
Page 21: Getting Started
IDENTIFYING INCLUDED COMPONENTS OpenEye® NVRs come with a mouse, keyboard and selected software and cables. Identify the following components to make sure everything has been properly included with the new NVR. If any of the following items are missing, contact the dealer to arrange a replacement. -
Page 22: Optional Components
OPTIONAL COMPONENTS To fully utilize the NVR’s potential, several optional OpenEye components are listed below. Contact the dealer for more information. USB External Hard Drive An easy way to extract large amounts of Video Data from the NVR is to use a USB External Hard Drive. This drive connects to the USB port on the NVR and can be attached to any computer with an USB port. -
Page 23: Keyboard Setup
KEYBOARD SETUP To attach the keyboard to the NVR, plug the end of the Keyboard into the keyboard PS/2 Port located on the back of the machine. The keyboard PS/2 Port can be identified by the purple color. Refer to the Rear Panel Connectors diagram for more information. MOUSE SETUP To attach the mouse to the NVR, plug the end of the mouse into the mouse PS/2 Port located on the back of the machine. -
Page 24: Monitor Setup
MONITOR SETUP The NVR may have one or both of the following connections available for monitors which can be used individually or in tandem. SVGA Output To VGA Monitor S-Video Output To TV/VCR. Attach the Monitor or Monitors to the Rear of the NVR using the cable supplied by the monitor manufacturer. Refer to the monitor manual for detailed information on how to setup and use it. -
Page 25: Hard Drive Array
HARD DRIVE ARRAY Hard drives in the X -Series NVR are arranged left to right in the HDD cage. A minimum of one and a maximum of five hard drives may be installed in the hard drive cage. The hard drive installed in bay one contains the operating system and if removed will render the NVR inoperable. -
Page 26: Turning On The Nvr
If asked to respond to the messages (adding a Printer, Monitor, etc for the first time) follow the instructions carefully. Startup is complete when OpenEye® NVR software is finished loading and displays the main menu screen. TURNING OFF THE NVR Click the Exit Button on the main menu screen of the NVR software. - Page 27 28126AC...
- Page 28 All rights reserved. No part of this publication may be reproduced by any means without written permission from OpenEye Inc. The information in this publication is believed to be accurate in all respects. However, OpenEye cannot assume responsibility for any consequences resulting from the use thereof.
