W a r n i n g
as a precaution, always unplug your appliance
before cleaning it (risk of electrocution).
• MOTOR Unit
never immerse the motor unit in water. clean it
with a damp cloth or a sponge.
• CUTTER ATTACHMENT
Remove the lid and then the bowl from the motor unit
by making it rotate to the left. Pull up to disengage
and leave the knife in the bowl in order to prevent
any spillage (if you work with liquids).
If the food has a solid consistency, remove the knife
and empty the bowl.
Replace the bowl, place the knife on the shaft and
switch your machine on in order to remove any
mixture which may be stuck to the knife.
You may rinse the bowl by filling it with hot water and
by leaving the machine operate for a few minutes.

• VEGETABLE PREPARATION ATTACHMENT

Remove the lid by turning it on the left side. Pull out
the disc plate and the discharge plate by raising it
by its hub. Then pull out the bowl by turning in a
clockwise direction.
You may then clean all the parts.
Dishwashers are best avoided. Instead
recommend that you hand wash the parts of your
machine.
Removable parts can be easily rinsed under a
tap. The machine can be damaged if temperature of
water is too hot or if very strong detergents are being
used.
cLeaning

• BLADE

After cleaning the blade, always dry the blades well.
i M p O r t a n t
check that your detergent is suitable for
cleaning plastic parts. some washing agents
are too alkaline (e.g. high levels of caustic
soda or ammonia) and totally incompatible
with certain types of plastic, causing them to
deteriorate rapidly.
• BLADE
We strongly recommend that the blades which are
not serrated be sharpened regularly by using the
sharpening stone that is supplied with the machine.
The quality of the cut mainly depends on the
sharpness of your blades.
Blades progressively become dull and should be
replaced from time to time to ensure constant quality
of the final product.
If these plates wear out, the bowl will no longer be
securely attached to the motor unit.
This makes it awkward to use since the bowl can
we
come loose during processing.
There is no risk to the user however, because the
safety system will automatically stop the machine.
It is advisable therefore to change those plates when
needed in order to ensure maximum ease of use.

• WEIGHT

r 101 XL
R 201 XL
R 201 XL Ultra
R 211 XL
R 211 XL Ultra
• DIMENSIONS (in mm)
Maintenance
r 101 XL
R 201 • R 201 XL
r 101 XL
R 201
R 201 XL
R 211
R 211 XL
tecHnicaL
speciFicatiOns
Net Gross
7.0 kg 8.2 kg
10 kg 12 kg
9.5 kg 12 kg
R 211 • R 211 XL
a B c D e F
665 220 280
720 220 280
450 220 280 665 285 365
9
