Upper pad height

P
adjustment
1
Step 2:
Lower the
pad until the upper
bolt holes on the
pad line up with
the holes on the
bracket
Note: This adjustment is only to be used with very small children in prone
standing. The pad must be in the upper position for supine standing
2
3
Note: If the headrest bolts have been left
in the top holes of the upper pad, they will
need to be removed prior to adjusting the
height of the upper pad.
Step 1:
Undo and remove bolts and
washers as shown opposite. Ensure
that you keep hold of the pad whilst
doing this.
Step 3: Insert the bolts back
through the bracket and into the
holes in the back of the pad. Ensure
the washer stays in place on the
bolt. Tighten both using the allen
key provided.
Multistander
jenx.com
41
