User Setup Data File

All of the set parameters in the table above can be saved in a date fi le to internal hard drive or to CF
card. By entering QUICK SETUP from the Setup Menu, selecting SAVE USER TO INHDD/CF the user
can save or restore parameters to and from this data fi le. This binary fi le is named 744T.SUP and is
saved in the SOUNDDEV directory on the medium selected in the setup menu.

Setup Menu

The Setup Menu controls a wide range of parameters for the 744T, including all audio routing,
recording settings, and time code options. The setup menu is a single, fl at architecture with no sub-
menus, easing navigation. Each setup controls a specifi c parameter with several selections. The chart
below shows the setup number, a description of the control, and the menu options available.
# Setup Name
1 Quick Setup
2 FireWire: Connection
3 Rec: Sample Rate
4 Rec: Bit Depth
5 Rec: File Type
Factory
Preset Preset
(Undefined) (Undefined)
Setup Description
Allows the user to quickly apply default menu set-
ups and save/retrieve user setups to disk or CF.
Activates FireWire drive mode.
Sets the audio sampling frequency of the 744T
Sets the bit depth of the 744T recordings.
Selects the file format (type) recorded to the
selected medium.
Film Reporter
Preset
(Undefined)
Setup Options
• Load Factory Settings
- restores the factory default settings
• Load Film Settings
- applies typical setups for film production
• Load Reporter Settings
- applies typical setups for voice recording
• Load Music Settings
- applies typical setups for music recording
• Load User from INHDD
- applies settings saved by user to hard disk
• Load User from CF
- applies settings saved by user to CF
• Save User to INHDD
- saves present state to file on hard drive
• Save User to CF
- saves present state to file on CF
• Computer/Connect (STOP+HDD buttons)
• External Drive
• 32 kHz
• 44.1 kHz
• 47.952 kHz
• 47.952k F
• 48 kHz
• 48.048 kHz
• 48.048k F
• 16 bit,
• 24 bit
• .wav poly
• .wav mono
• .flac
• .MP3 32 kb/s
• .MP3 64 kb/s
• .MP3 96 kb/s
• .MP3 128 kb/s
• .MP3 160 kb/s
• .MP3 192 kb/s
• .MP3 256 kb/s
Music
Preset
(Undefined)
• 88.2 kHz
• 96 kHz
• 96.096 kHz
• 96.096 k F
• 176.4 kHz
• 192 kHz
• .MP3 320 kb/s
• .MP2 64 kb/s
• .MP2 96 kb/s
• .MP2 128 kb/s
• .MP2 160 kb/s
• .MP2 192 kb/s
• .MP2 256 kb/s
• .MP2 320 kb/s
• .MP2 384 kb/s
