EMX-CDT User's Manual
Item
Enable ACPI Auto Configuration
Enable Hibernation
ACPI Sleep State
Lock Legacy Resources

3.6.2.2 RTC Wake Settings

Item
Wake system with Fixed Time
Wake system with Dynamic
Time
28 EMX-CDT User's Manual
Options
Disabled[Default],
Enabled
Disabled,
Enabled[Default]
Suspend Disabled
S1 (CPU Stop Clock),
S3 (Suspend to RAM) [Default]
Disabled[Default],
Enabled
Options
Disabled[Default],
Enabled
Disabled[Default],
Enabled
Data Modul AG - www.data-modul.com
Description
Enables or Disables BIOS ACPI
Auto Configuration.
Enables or Disables System ability
to Hibernate (OS/S4 Sleep State).
This option may be not effective with
some OS.
Select the highest ACPI sleep state
the system will enter when the
SUSPEND button is pressed.
Enables or Disables Lock of Legacy
Resources.
Description
Enables or Disables wake on alarm event.
When enabled, System will wake on the
hr::min::sec specified.
Enables or Disables wake on alarm event.
When enabled, System will wake on the
current time + Increase minutes (s)
