LED Indicators

LED Status
Green and Red Flashing

Charge / Sync Toggle Button

Installation

1. For each tablet to be connected to the ST10CSU2A, first connect your tablet
device(s) directly to your host computer to ensure the computer detects and installs
the device drivers to your host operating system.
2. Place the ST10CSU2A on a flat surface, and ensure the Power Switch is set to the
"Off" position.
3. Connect the provided Power Cord into the power connector on the rear of the
ST10CSU2A, then connect the Power Cord the to an available AC electrical outlet.
4. Connect your tablet device USB cable(s) (eg: Micro USB cable, Lightning cable, 30-
Pin dock connector, etc.) into the USB Ports on the ST10CSU2A as desired.
5. Insert your tablet devices into the slots on the ST10CSU2A, and then connect the
tablets connector to the USB cables from step #4. The provided trays have grooves
for cable management, and can be adjusted to different heights as desired.
Note: The 9 provided adjustable trays can positioned at different heights depending
on the size/thickness of your connected tablets. Adjust the trays to the desired height
prior to inserting your tablet devices into the ST10CSU2A.
Instruction Manual
Off
Red
Green
Indication
No device is connected to the
corresponding USB port
Connected device is charging
Connected device is charged - charging
Connected device is in sync mode – sync in
process with host computer
Charge Mode
position (sync disabled)
Sync Mode
- Button is in the "down"
3
complete
- Button is in the "up"
position
