StarTech.com USB2PACWH Quick Start Manual

2 Port White USB Wall Charger High Power 17 Watt / 3.4 Amp
Product Diagram (USB2PACWH)
1
3
Component
1 USB-A Port (1A)
2 USB-A Port (2.4A)
3
LED
4
Power Plug
Requirements
For the latest requirements, please visit
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
2
4
Function
Used to charge USB Devices up to a maximum of
•
1A (cell phone, etc.).
Both USB-A Ports have a max Amp = 3.4A
•
Used to charge USB Devices up to a maximum of
•
2.4A (tablet, etc.).
Both USB-A Ports have a max Amp = 3.4A
•
Indicates when a connected USB Device is
•
charged.
Used to connect the USB Wall Charger to an AC
•
Electrical Outlet.
The Power Plug is retractable.
•
The Power Plug can be switched to accomidate
•
different regional outlets (NA/UK/EU/AUS).
www.startech.com/USB2PACWH
Installing the USB Wall Charger
Note: Some mobile devices use proprietary power connections which are
not compatible with aftermarket chargers. Please consult the manufacturer's
documentation to ensure compatibility with the USB Wall Charger.
Make sure that the Prongs on the Retractable Plug are pointing outward.
1.
Plug the Retractable Plug in an AC Electrical Wall Outlet.
2.
Connect USB Device(s) to either or both the USB-A (1A) or the USB-A (2.4A) Ports
3.
on the USB Wall Charger.
Changing the Power Adapter Clip
Warning: The North American Power Plug does not have to be removed from the
USB Wall Charger to install a regional Power Adapter Clip.
Select the appropriate regional Power Adapter Clip (UK/EU/AUS).
1.
Fold in the North American Power Plug.
2.
Slide the Power Adapter Clip over the North American Power Plug until you hear
3.
an audible click.
Quick-Start Guide
Manual Revision: March 20, 2020 9:15 AM
