Universal Charge & Sync Cabinet for Tablets/iPads®
- 10 Slot Charging Station with Lock and Fan
ST10CSU2A
* This page is an addendum to the warning
label found on the product.
The Warning Label (250V/5A) is required to satisfy
a Regulatory Requirement for maximum input
power source availability, due to the internal,
replaceable, protection fuse implementation.
This version of product has been configured
to accommodate a standard North American
60Hz; 115V AC, 15A power source line cord.
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 04/24/2015
Advertisement
Table of Contents
Related Manuals for StarTech.com ST10CSU2A
Summary of Contents for StarTech.com ST10CSU2A
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 04/24/2015...
- Page 2 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 04/24/2015...
- Page 3 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 4: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Diagram ..................2 Front View ..............................2 Rear View ..............................2 LED Indicators............................. 3 Charge / Sync Toggle Button ........................ 3 Installation ....................3 Operation ....................5 Charge Mode .............................. 5 Sync Mode .............................. -
Page 5: Introduction
Introduction Packaging Contents • 1x Charge & Sync Cabinet • 1x USB A – B Cable (4ft) • 2x Keys • 1x Desk Mount Bracket (w/ Screws) • 4x Stacking Screws • 1x Power Cord - North American (6ft) • 1x Instruction Manual System Requirements •... -
Page 6: Product Diagram
Product Diagram Front View 1. Charge and Sync Toggle Button 2. USB A Ports 3. LED Status Lights x10 4. Slots for Tablets x10 5. Adjustable Trays with Cable Management grooves 6. Slide-In Door Rear View 1. Power Connector 2. Power Switch 3. -
Page 7: Led Indicators
2. Place the ST10CSU2A on a flat surface, and ensure the Power Switch is set to the “Off” position. - Page 8 6. Connect the provided USB A – B Cable from the USB Host Port on the rear of the ST10CSU2A, to a USB A Port on your host computer (for sync capabilities). 7. Switch the Power Switch on the rear of the unit to the “On” position.
-
Page 9: Operation
Power Cord from the ST10CSU2A. Security Bracket The ST10CSU2A features a slide-out Security Bracket on the rear upper-center position of the unit. This bracket can be used with cable locks to secure the ST10CSU2A as desired. Surface-Mounting Method 1: The ST10CSU2A features a slide-out Surface Mounting bracket on the rear lower-center position of the unit. -
Page 10: Surface-Mounting Method 2
1. Secure the Desk Mount Bracket to a surface as desired using the included screws. 2. Align the bottom of the ST10CSU2A over the secured bracket, and gently slide the bracket into the indent on the bottom of the ST10CSU2A. - Page 11 2. Align the 2x ST10CSU2A units either horizontally or vertically, top to bottom. 3. Align the 4 pilot holes on the top and bottom of the 2x ST10CSU2A. 4. Insert the 4 provided Stacking Screws through the bottom of one ST10CSU2A, and using a screwdriver, firmly secure the screws to the top of the 2nd ST10CSU2A.
-
Page 12: Specifications
Specifications Compatibility USB Battery Charging Specification Rev. 1.2 10/8/6 tablet devices (adjustable trays) - Storage Capacity Apple® iPad® or other tablets Dimensions (W x D x H) 400mm x 350mm x 430mm Weight Net Weight: 15.6 kg LED Indicators Input: 110/220V, 50/60Hz Voltage Output: DC 5V, 2.3A for each USB port Instruction Manual... -
Page 13: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 14 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
