INSTRUCTION MANUAL
TD6080
8 Channel Decoder / Zone Selector
Thank you
for choosing another quality product from Amperes Electronics.
TD6080 is an integration of mic data decoder and zone selector in a box, which simplifies the interconnection works during rack
setup. Apart from simplification, a substantial cost reduction can be achieved due to lower unit count and space requirement as
compared to setup using zone decoder and zone selector.
We appreciate that you read through the manual to avoid any mishandling as well as to explore the full potential this unit can
offer. Keep this manual for future reference and we believe that you are getting an optimum product in its class.
VER 3 / 2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the TD6080 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amperes TD6080

Summary of Contents for Amperes TD6080

  • Page 1 Amperes Electronics. TD6080 is an integration of mic data decoder and zone selector in a box, which simplifies the interconnection works during rack setup. Apart from simplification, a substantial cost reduction can be achieved due to lower unit count and space requirement as compared to setup using zone decoder and zone selector.

  • Page 2: Parts Identification

    24V DC supply is required to operate this unit. Ensure polarity is correctly terminated to the port. It is recommeded that supply with 1A rating of regulated source is used. Amperes PS9400 is recommended as a DC supply source to your installation.
  • Page 3 The user has the flexibility to configure the zoning system as each zone comes with single amplifier output connection. Please observe polarity when terminating the amplifier / speaker zones and ensure that each zone is not over overloaded ( max load 500W l00V line ). TD6080 | 8 CH DECODER / ZONE SELECTOR PAGE 3...
  • Page 4 Zone 8 Zone 1 DOWN SPEAKERS 500W 100V LINE POWER AMPLIFIER POWER AMPLIFIER QP2000S Note: All PD Series of Amperes paging microphones can be used with TD6080. PAGE 4 TD6080 | 8 CH DECODER / ZONE SELECTOR...
  • Page 5 - - - - - - - - 100V Output QP2500 Zone 1 Zone 8 SPEAKERS Note: Also refer to page 10, in using EP1200A to trigger emergency overriding at volume controllers. TD6080 | 8 CH DECODER / ZONE SELECTOR PAGE 5...
  • Page 6 1) Use EX1103A if more than one PD2400 / 2800 are available in the system. The single output (RJ45) can be directly connected to TD6080 mic input port. 2) A higher priority mic shall override any lower priority unit in active.
  • Page 7 3) This setup would normally be used together with matrix controller. 4) Use of DA2208 at paging mic audio output is required if more than 6 amplifiers are installed in the system. TD6080 | 8 CH DECODER / ZONE SELECTOR PAGE 7...
  • Page 8 PAGING CLIENT PD2800 24V DC EX2800 INPUT Network Switch iPX5151 PAGING CLIENT TIME OUT 5 MIN LINE / MIC OUTPUT MASTER / SLAVE DC 24V TD6080 Line Out 100V SPEAKERS QP2500 PAGE 8 TD6080 | 8 CH DECODER / ZONE SELECTOR...
  • Page 9 : 10000 0000 - Zone 1 to 8 (DIP Switch 8 ON) 01000 0000 - Zone 9 to 16 (DIP Switch 8 OFF) 11000 0000 - Zone 17 to 24 (DIP Switch 8 OFF) TD6080 | 8 CH DECODER / ZONE SELECTOR PAGE 9...
  • Page 10 - ve Note: Trigger of ‘ALL CALL’ button at TD6080 front panel shall ON all zones but would not be able to override volume controllers. This is to avoid unnecessary announcement or BGM to be broadcasted to the selected zones.

  • Page 11: Technical Data

    482 x 44 x 180 mm Weight 2 kg Note: The above specifications are correct at time of printing but subjected to changes without prior notice due to product improvements. TD6080 | 8 CH DECODER / ZONE SELECTOR PAGE 11...

  • Page 12: Warranty Conditions

    Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized master distributor, TNT Links Sdn Bhd / MyPA Systems Sdn Bhd.
