- Page 1 INSTRUCTION MANUAL 5601 6 Channel Speaker Zone Selector 5121 12 Channel Speaker Zone Selector amperes ... the emerging preference www.ampereselectronics.com...
- Page 2 The LED shall lit if remote paging microphone is active and is overriding the local BGM zone selection. This is active if Amperes PM 1060 paging is used or any other paging microphone console with Priority output signal. 2. FRONT PANEL ZONE SWITCHES - ZONE 1 TO 6 Switching for zone 1 to 6.
- Page 3 PARTS IDENTIFICATION 3. FRONT PANEL ZONE SWITCHES - ZONE 7 TO 12 Switching for zone 7 - 12 for ZS5121 only. Refer to Application example for grouping. 4. ALL CALL SWITCH All zones will be activated by pressing this switch, regardless of any inactive zone.
- Page 4 POWER AMP 1 POWER AMP 2 24 DC The sample connections shown are using a single unit of either ZS5121 or ZS5601 in a small scale A M P 1 Z O N1 A M P 2 Z O N2...
- Page 5 Power Amplifiers Zone 25 to 36 TD6240 Data MX2222 Mixer decoder ZS5121 Zone Selectors P IN 1 -Z 1 New RJ45 Pin configurations P IN 2 -Z 2 Note that All Call and PR from remote mic shall not P IN 3 -Z 3...
- Page 6 CONNECTING EMERGENCY OVERRIDING PORT 24V DC (PS9400) to trigger volume controller overriding relay, etc. D C 24V R E LAY R E LAY T R IG C O NT TO VOLUME CONTROL OVERRIDING RELAY OR OTHER E/CY. INDICATOR OR EMERGENCY INTERFACE LOAD : 24V DC 2 AMPS EMER.
- Page 7 NOTE : Amperes Electronics Sdn Bhd has the policy of improving or reviewing its products in design, performance as well as quality from time to time. It is therefore, Amperes Electronics has the right to change the above specifications without prior notice.
- Page 8 It is recommended that all services and repairs on this product be carried out by AMPERES ELECTRONICS SDN BHD or its authorized service agents. AMPERES series must only be used for the purpose they were intended by the manufacturer and in conjunction with this operating manual.
