Liebert Process Fluid Chiller PS024A Specification Sheet

Keeping Business in Business
• Dedicated, equipment-matched cooling supplies the proper temperature and water flow year round.
• Factory-tested, piped, wired and charged for hassle-free startup and operation.
• Clean, non-ferrous cooling loop, required for sensitive medical equipment.
• Local service and parts for quick and knowledgeable maintenance and service.
• Optional switch-over to alternate water source provides redundant, continuous operation.
• Optional remote monitoring systems keep you informed of chiller operation.
• UL/CSA listing on standard models.
• ISO 9001 certified company.
CLINAC 4/100, 6/100 & 600C Specifications
Fluid Specified
Heat Dissipation—BTUH (kW)
Fluid Temperature Range—°F (°C)
Fluid Flow Rate—GPM (l/m)
Fluid Pressure Drop—PSI (kPa)
Note: Performance is based on 95°F condenser ambient.
Model Number
Fluid Circulated
Net Cooling Capacity—BTUH (kW)
Leaving Fluid Temperature—°F (°C)
Fluid Flow Rate—GPM (l/m)
CLINAC Pressure Drop—PSI (kPa)
Chiller Pressure Drop—PSI (kPa)
Pump Total Head—PSI (kPa)
Pump HP (kW)
*Data not available
For Varian CLINAC 4/100, 6/100 & 600C
Water
23,900 (7)
50-70 (10-25)
1 (3.8)
25-40 (172-276)
Process Fluid Chiller Specifications
PS024A
Water
24,300 (7.1)
61 (16.1)
1.3 (4.9)
* (*)
6.3 (43.4)
41 (282.7)
3/4 (.56)
Process Fluid Chiller Designed For Varian CLINAC 4/100, 6/100 & 600C
Process Fluid Chiller Designed
PS036A PS036A
Ethylene Glycol Propylene Glycol
24,400 (7.2) 23,900 (7.0)
47 (8.3) 50 (10)
1.5 (5.7) 1.6 (6.1)
* (*)
2.3 (15.9) 2.8 (19.3)
41 (282.7) 41 (282.7)
3/4 (.56) 3/4 (.56)
* (*)
