Liebert Process Fluid Chiller PS096A Specification Sheet

Keeping Business in Business
• Dedicated, equipment-matched cooling supplies the proper temperature and water flow year round.
• Factory-tested, piped, wired and charged for hassle-free startup and operation.
• Clean, non-ferrous cooling loop, required for sensitive medical equipment.
• Local service and parts for quick and knowledgeable maintenance and service.
• Optional switch-over to alternate water source provides redundant, continuous operation.
• Optional remote monitoring systems keep you informed of chiller operation.
• UL/CSA listing on standard models.
• ISO 9001 certified company.
PETNet Cyclotron Specifications
Fluid Specified
Heat Dissipation—BTUH (kW)
Fluid Temperature Range—°F (°C)
Fluid Flow Rate—GPM (l/m)
Fluid Pressure Drop—PSI (kPa)
Note: Performance is based on 95°F condenser ambient.
Model Number
Fluid Circulated
Net Cooling Capacity—BTUH (kW)
Leaving Fluid Temperature—°F (°C)
Fluid Flow Rate—GPM (l/m)
PETNet Cyclotron Pressure Drop—PSI (kPa)
Chiller Pressure Drop—PSI (kPa)
Pump Total Head—PSI (kPa)
Head Available for Piping Circuit—PSI (kPa)
Pump HP (kW)
Based on Siemens specification dated 07/97
Designed for CTI PETNet Cyclotron
Water
60,000 (17.6)
40-50 (4.4-10)
10 (38)
5 (34)
Process Fluid Chiller Specifications
Process Fluid Chiller
PS096A
Ethylene Glycol Propylene Glycol
72,400 (21.2) 68,200 (20)
45 (7.2)
10 (38)
5 (34)
6.6 (45)
65 (448)
53.4 (369)
3 (2.2)
Process Fluid Chiller Designed for CTI PETNet Cyclotron
PS096A
45 (7.2)
10 (38)
5 (34)
8.0 (54.5)
65 (448)
52.0 (360)
3 (2.2)
1
