Liebert CSU3000 User Manual

Keeping Business in Business
• Dedicated cooling supplies the proper temperature and water flow year round.
• Factory-tested, piped, wired and charged for hassle-free startup and operation.
• Local service and parts for quick and knowledgeable maintenance and service.
• Optional switch-over to alternate water source provides redundant, continuous operation.
• Optional remote monitoring systems keep you informed of chiller operation.
• Standard product ETL/CSA certified.
• ISO 9001 certified company.
PETNet Cyclotron Specifications
Fluid Specified
Max Heat Dissipation—BTUH (kW)
Fluid Temperature Range—°F (°C)
Fluid Flow Rate—GPM (l/m)
Fluid Pressure Drop—PSI (kPa)
CSU Chiller Specifications
Model Number
Fluid Circulated
Net Cooling Capacity—BTUH (kW)
Leaving Fluid Temperature—°F (°C)
Fluid Flow Rate—GPM (l/m)
PETNet Cyclotron Pressure Drop—PSI (kPa)
Chiller Pressure Drop—PSI (kPa)
Pump Total Head—PSI (kPa)
Pump HP (kW)
For CTI PETNet Cyclotron w/o Redundancy
Water/Glycol
60,000 (17.6)
40-50 (4.4-10)
10 (38)
5 (34)
CS109A
Water
121,900 (35.7)
45 (7.2)
24 (91)
5 (34)
8.4 (58.1)
35.9 (247.7)
1.5 (1.1)
CSU3000 Chiller For CTI PETNet Cyclotron w/o Redundancy
CSU3000 Chiller
1
