Liebert Process Fluid Chiller PS120A Specification Sheet

Keeping Business in Business
• Dedicated, equipment-matched cooling supplies the proper temperature and water flow year round.
• Factory-tested, piped, wired and charged for hassle-free startup and operation.
• Clean, non-ferrous cooling loop, required for sensitive medical equipment.
• Local service and parts for quick and knowledgeable maintenance and service.
• Optional switch-over to alternate water source provides redundant, continuous operation.
• Optional remote monitoring systems keep you informed of chiller operation.
• UL/CSA certified.
• ISO 9001 certified company.
Infinion 1.5T Specifications
Fluid Specified
Max Heat Dissipation—BTUH (kW)
Fluid Temperature Range—°F (°C)
Fluid Flow Rate—GPM (l/m)
Fluid Pressure Drop—PSI (kPa)
Model Number
Fluid Circulated
Net Cooling Capacity—BTUH (kW)
Leaving Fluid Temperature—°F (°C)
Fluid Flow Rate—GPM (l/m)
Infinion 1.5T Pressure Drop—PSI (kPa)
Chiller Pressure Drop—PSI (kPa)
Pump Total Head—PSI (kPa)
Head Available for Piping Circuit—PSI (kPa)
Pump HP (kW)
Process Fluid Chiller Designed for Marconi Medical
Glycol
90,000 (26)
40-55 (4.4-12.7)
18.0 (68.0)
25.0 (172.0)
Process Fluid Chiller Specifications
PS120A
Water
94,300 (28)
45 (7.2)
15 (57)
25.0 (172)
7.6 (52.4)
60.6 (418)
28.0 (193)
3 (2.2)
Process Fluid Chiller Designed for Marconi Medical Infinion 1.5T, PD3000
Infinion 1.5T, PD3000
PS120A PS120A
Ethylene Glycol Propylene Glycol
94,900 (28) 90,100 (26)
50 (10) 50 (10)
18 (68) 18 (68)
25.0 (172) 25.0 (172)
10.2 (70.3) 12.0 (82.7)
60.6 (418) 60.6 (418)
25.4 (175) 23.6 (163)
3 (2.2) 3 (2.2)
1
