- Page 1 OWER ROTECTION UPStation ® 1000 VA to 3000 VA...
-
Page 2: Important Safety Instructions
CONSERVER CES INSTRUCTIONS. CETTE NOTICE CONTIENT DES INSTRUCTIONS IMPORTANTES CONCERNANT LA SÉCURITÉ. Liebert Corporation neither recommends nor knowingly sells this product for use with life support or other U.S. FDA designated ”critical” devices. CAUTION: A BATTERY PRESENTS A RISK OF ELECTRICAL SHOCK OR BURN FROM HIGH SHORT CIRCUIT CURRENT. -
Page 3: Introduction & System Description
UPStation’ GX UPS is equipped with an RS-232 interface port. detailed operating information including voltages, currents, temperature, and alarm status to the host system when used with Liebert SiteNet soft- ware. In addition, this port allows remote programming of UPS operation and numerous internal operating parameters. -
Page 4: Before Installation
MAJOR INTERNAL UPS COMPONENTS Surge Suppression and EMI/RFI Filters These components provide surge protection and filter electromagnetic and radio frequency interference present in the utility line. These components enable the UPS to supply pure sinewave power to sensitive equipment. Power Factor Correction Circuit This circuit changes the utility AC input to DC for use by the inverter and ensures sinewave input current to the UPS. -
Page 5: General Installation Guidelines
Retain the screws from the two front feet to fasten securing flanges. Liebert offers kits for UPS rail or slide installation. Install the UPS on rackmount rails, slides or shelves. Use the installation instructions which came with your rackmount kit. -
Page 6: Tower Installation
TOWER INSTALLATION Turn the On/Off switch on the front of the unit OFF. With load equipment switched OFF, plug it into the UPS output receptacles. Plug UPS into a dedicated and grounded wall receptacle, properly protected by a circuit breaker or fuse. Use a 15 amp rated device for 1000 or 1500 VA units, and a 20 amp device for 2100 VA units. -
Page 7: Front Panel Controls And Indicators
Typically, the CAPACITY bar flashes following a power outage, when batteries have not fully recharged. If after 4 hours of recharge (or in the test mode) the 3 left most LEDs still flash, contact Liebert Technical Support at 1-800-222-5877 and ask about replacement batteries. - Page 8 REAR PORTS & SWITCHES Serial Communications Port This port allows remote monitoring of alarm conditions (See next page). Optional SNMP Ports The SNMP (Simple Network Management Protocol) option provides intelligent Ethernet or Token Ring network communications. With SNMP software, it provides comprehensive remote UPS control and monitoring.
- Page 9 Periodic tests of battery quality and replacement notification Timed and delayed shutdown of the UPS Logging of power disturbances and anomalies Consult your Liebert sales agent for more information about SiteNet® 2 software. SNMP Communications An optional internal SNMP card (and SiteNet’ SNMP software) allows communication through several network management systems.
-
Page 10: Troubleshooting
Alarms indicate faults, power outages, and UPS battery operation. The tone pattern varies according to the alarm: On-Battery / Utility Failure Alarm - one beep every 4 seconds (greater than 2 minutes battery time remaining). Silence this alarm by depressing the ”Alarm Reset” switch for a half-second. - Page 11 Check for UPS overload, blocked ventilation openings, and excessively high room temperature. Allow UPS to cool for 30 minutes, the restart. Reduce loads to UPS. Consult Liebert Technical Support. Requires service. Contact Liebert Technical Support. Remove cause of short-circuit, if obvious.
-
Page 12: Maintenance
Replace batteries after 5 years or sooner if exposed to adverse conditions. Refer battery replacement to qualified service personnel only. Heed cautions at the front of this manual at all times. Call Liebert Technical Support at 1-800-222-5877 for battery replacement instructions. Battery Safety Precautions WARNING: Battery maintenance procedures expose hazardous live parts. - Page 13 1000-2100 VA GX SPECIFICATIONS Model Rating (VA/Watts) INPUT Voltage Voltage Range Frequency Current Power Factor Voltage Transients Power Cord OUTPUT Voltage and Current Voltage Regulation Frequency Locked to Utility Output Distortion Waveform Overload Load Power Factor Range Transient Response Time Bypass Transfer Efficiency (AC to AC) Receptacles...
- Page 14 3000 VA GX SPECIFICATIONS Model Rating (VA/Watts) INPUT Voltage Voltage Range Frequency Current Power Factor Voltage Transients Power Cord OUTPUT Voltage and Current Voltage Regulation Frequency Locked to Utility Output Distortion Waveform Overload Load Power Factor Range Transient Response Time Bypass Transfer Efficiency (AC to AC) Receptacles...
-
Page 15: Limited Warranty
AC power to your sensitive electronic equipment. Liebert Corp. warrants to the original user that the UPStation® GX product is, and will remain, free of defects in materials and workmanship for a period of two years from date of purchase (proof of purchase will be required). -
Page 16: Technical Support
Web site ...… http://www.liebert.com Worldwide FAX tech support...…614-841-5471 The Company Behind The ProductsWith more than 500,000 installations around the globe, Liebert is the world leader in computer protection systems. Since its founding in 1965, Liebert has developed a complete range of support and protection systems for sensitive electronics: §...
