Single Door Undercounter Refrigeration Installation & Operation Manual
INTRODUCTION/PREPARING THE CABINET - SINGLE DOOR UNDERCOUNTER CABINETS

Table of Contents

Introduction ........................................... 2
Preparing the Cabinet for Use
Uncrating and Inspection ..................... 2
Plumbing/Electrical .............................. 2
Installing the Cabinet
Anti-Tip Brackets ................................. 3
Preparing the Space ............................ 3
Installing the Unit ................................. 4
Toe Plate/Shelving Installation ............. 5
Operation Instructions
Master Switch ...................................... 6
Interior Light......................................... 6
Controller Operation ............................ 6
Maintenance
Light Bulb Replacement ...................... 8
Stainless Steel Care Guide ................. 8
Cleaning Condenser ............................ 9
Troubleshooting ................................. 10
Contact Perlick ....................................11
Thank you for choosing Perlick
To register your product, visit our website at www.
perlick.com. Click on 'Bar & Beverage Equipment',
then 'Service & Support' and select the 'Warranty
Registration Form' option.You must complete and
submit this form or the installation date will revert
back to the ship date.
This manual has been prepared to assist you in the
installation of this cabinet and acquaint you with its
operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. If service is required, your dealer can
provide you with a list of qualified service agents.
For your own protection, never return merchandise
without our approval.
We thank you again for selecting a Perlick product
and assure you of our continuing interest in your
satisfaction.
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice.

Uncrating and Inspection

Remove all crating material. Carefully inspect cabinet
for hidden damage. If damage is discovered, file your
claim immediately with the transport company. Perlick
is not responsible for damage in transit.
Plumbing
No plumbing connections are required. Condensate
from the cooling coil automatically evaporated through
a condensate pan located in the condensing section
of the unit.
Electrical
A 115 volt, 60 Hz, 15 amp circuit breaker and electri-
cal supply are required. A separate circuit is required
for each Perlick unit installed.
Follow the National Electrical Code and any local
codes or ordinances when installing the receptacle.
All Perlick units come equipped with a NEMA 5-15P
90° plug with a 5' cord extending beyond the rear of
the cabinet. The electrical outlet must be flush with,
or recessed into, the wall surface for all HC and HB.
HD models have a recess at the rear of the cabinet
to accomodate the plug and keep a true 18" depth.
Serious
DANGER
ard! Electrical grounding is
required. This appliance is equipped with a
3-prong (grounding) polarized plug for your pro-
tection against possible shock hazards. Failure
to comply with these electrical guidelines may
result in possible death or serious injury, fire, or
loss of property.
► NEVER remove the round grounding prong from
the plug.
► NEVER use a 2-prong adapter.
► NEVER use an extension cord to connect power
to the unit.
Additional General Information
► All electrical instructions assume the outlet is
located 4" -10" above the floor surface.
► Floor must be level in the area of installation. Leg
levelers are used for fine-tune adjustment only
and should not be used to compensate for floor
differences exceeding 1/2".
2
electrocution haz-
