Page 1: Operation Manual
Globalmediapro SOF-101 & SOF-102 SDI over Optical Fiber Extender Operation Manual Operation Manual... -
Page 2: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package contents ......... 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Transmitter Front and Rear Panels ..3 6.2 Receiver Front and Rear Panels ..4 7. -
Page 3: Introduction
1. INTRODUCTION The SDI to Optical Fiber Extender set is designed to extend your SDI signals over Optical Fiber for long distance transmission up to 10km. Signals from 50 Mb/s to 3 Gb/s bandwidth can be sent without loss or compression with thinner, lighter cables for easy installations. -
Page 4: Features
5. FEATURES • SMPTE 287-2006 compliant • Robust error-free transmission of signals from 50Mb/s to 3Gb/s up to 10 km over single-mode fiber (distance is dependent on the fiber module used). • Supports video pathological patterns for SD-SDI, HD-SDI and 3G-SDI •... -
Page 5: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels OPTICAL OUT DC 5V SDI IN 3G SDI to Optical Fiber Transmitter DC 5V Plug the 5 V DC power supply into the Transmitter unit and connect the adaptor to an AC outlet. SDI Signal Status LEDs These LEDs will light according to the SDI input signal format (3G, HD or SD). -
Page 6: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels OPTICAL IN DC 5V SDI OUT Optical Fiber to 3G SDI Receiver SDI OUT Connect to a SDI monitor or display for SDI video and audio output. SDI Signal Status LEDs These LEDs will light according to the SDI output signal format (3G, HD or SD). -
Page 7: Connection Diagram
7. CONNECTION DIAGRAM SDI Camcorder Power Supply DC 5V SDI IN OPTICAL OUT 3G SDI to Optical Fiber Transmitter Fibre Optical Cable (Up to 10 km) Power Supply OPTICAL IN Optical Fiber to 3G SDI Receiver DC 5V SDI OUT Display... -
Page 8: Specifications
8. SPECIFICATIONS Transmitter Input Ports 1×BNC (SD/HD/3G-SDI) Output Ports 1×Single-Mode Fiber Optical (LC connector) Receiver Input Ports 1×Single-Mode Fiber Optical (LC connector) Output Ports 1×BNC (SD/HD/3G-SDI) SDI Timging Support SD-SDI: SMPTE 259M-C, at bitrates of 270 Mbit/s HD-SDI: SMPTE 292M, at bitrates of 1.485 Gbit/s and 1.485/1.001 Gbit/s 3G-SDI: SMPTE 424M/425M-AB, at bitrates of... -
Page 9: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Bandwidth 2.97Gbps ≈ 3G Light-Emitting Diode Serial Digital Interface Satellite News Gathering...
