- Page 1 Ethernet Extender User Manual Model：IP01F Ethernet to Fiber Media Converter/Extender...
-
Page 2: Transmission Distance
Introduction IP01F is a networking device capable of transmitting data communication protocol including Ethernet, Fast Ethernet, and Gigabit Ethernet over fiber optics. The transmission distance can reach up to 20km over a single-mode fiber module and single-core fiber cable. The plug and play media converter is an ideal solution for CCTV network, AVoIP system, and IT infrastructure. -
Page 3: Panel View
Panel View Interface Description Power Input To input a DC5V power RJ45 To connect a network cable SC Fiber Connector To connect a single fiber cable LED Indicators To indicate the status of power and connection LED Indication LED Status Description FX/ACT Blink... -
Page 4: Package Includes
Package Includes Item Quantity IP01FA IP01FB DV5V 2A Power Adapter Accessory Set... -
Page 5: Specification
Specification Item No IP01F Support IEEE802.3 10BASE-T IEEE802.3u 100BASE-T Compliance IEEE802.3ab 1000BASE-T IEEE802.3z 1000BASE-SX/1000BASE-LX IEEE802.3az Ethernet: 100M over a network cable Max. Transmission Distance Fiber: 20㎞ over single mode single fiber Data Bandwidth 10/100/1000Mbps Jumbo Frame Flow Control Half/ Full Duplex... - Page 7 Installation Guide Accessory Machine Screw Self-drilling Screw Screw Plug Angle Bracket DIN-rail Mounting Plat 1U Rack...
- Page 8 Installed on a Platform Step 1 Use machine screws to fix angle brackets on both sides of your product Step 2 Use self-drilling screws to fix the product on a platform...
- Page 9 Step 3 Move the product to get fixed and then lock the screws...
- Page 10 Installed on Wall Step 1 Same way as “Installed on a Platform”, but need to put screw plugs into the pilot hole before inserting the screws (leave 2mm space from the platform) Installed on a DIN-rail Step 1 Use machine screws to fix a DIN-rail mounting plat on the side of your product...
- Page 11 Step 2 Install your product on a DIN-rail as following instruction Installed on a Rack Step 1 Lock machine screws in the rack Step 2 Put your products on the rack...
- Page 12 Step 3 Push the products to the other side of the rack Step 4 Install the rack in a cabinet...
