- Page 1 HDMI Extender Series User Manual...
- Page 2 Model : HE01F-4K Compact 4K HDMI Fiber Extender...
- Page 3 Introduction HE01F-4K is an HDMI extender that uses a single fiber optic cable with LC connections to transmit uncompressed 4K 30Hz HDMI signals, with EDID and HDCP signals supported for both multi-mode and single-mode fibers. This small compact size allows you to easily finish installation for any audiovisual applications.
- Page 4 Micro USB Connector To input 5V 2A power Installation Guide Connect HE01FT-4K (The transmitter) to an HDMI source. 2. Connect the optical fiber cable to HE01FT-4K. 3. Power on HE01FT-4K from the micro-USB port. 4. Connect HE01FR-4K (The receiver) to an HDMI device.
- Page 5 Powered, but no data transferred from transmitter Purple Powered and data received from transmitter...
- Page 6 Please contact us for further repair if above conditions happen What’s In the Package Item HE01FT-4K HE01FR-4K 5V 2A Power Adapter Micro USB to USB cable 1M...
- Page 7 Specification Model HE01FT-4K HE01FR-4K Compliance Standard HDCP 1.4, 3D, DDC Video Resolution 4K@30Hz 4:4:4 Data Rate 10Gbps 1 KM over single-mode fiber Transmission Distance 300M over multi-mode fiber Wavelength 1310nm 1550nm Ports & Interfaces Video Input 1 x HDMI Type-A...
