7 day, Single Channel Digital Wireless Programmer and Room Thermostat –
The digital wireless programmer and room thermostat is a 7 day radio frequency (RF) wireless
thermostat / timer, which communicates with a receiver designed to fit in the clock aperture of the
boiler control panel. The unit can be pre-programmed to provide maximum and minimum room
temperature control. Each day can be programmed with the same – or different – time periods. The
programme can be temporarily or permanently overridden to increase or decrease the desired
temperature setting.
The batteries should operate the unit for approximately 18 months to 2 years depending on the
number of switching operations etc. Only good quality alkaline batteries should be used. When the
batteries need replacing, a low battery
programmes and temperature settings remain stored and no resetting is required.
Note: If the batteries are not replaced and no valid signal is received from the Transmitter, the
Receiver's neon light will flash every 0.5 seconds. After 1 hr the boiler will operate in 'Emergency
mode' (heating on for 4 min. and off for 9 min.) until the batteries are replaced.
Note; always press the reset button after removing or replacing the batteries.
This timer is suitable for installation as a time controller for:
ATAG iC 24 Combi
ATAG iC 28 Combi
ATAG iC 36 Combi
ATAG iC 40 Combi
ATAG Economiser 27
ATAG Economiser 35
ATAG Economiser 39
WARNING. This unit must be installed by a skilled electrician
in accordance with the current I.E.E. Wiring Regulations.
ALWAYS switch off and disconnect the electricity supply to the appliance before installing the
programmer. Merely switching the boiler ON/OFF switch to 'OFF' will still leave a live feed to
the boiler.
Part No. CT200001
symbol will be displayed. After replacement, all the
Rev: 02/15/004
Advertisement
Table of Contents
Related Manuals for Atag CT200001
Summary of Contents for Atag CT200001
- Page 1 7 day, Single Channel Digital Wireless Programmer and Room Thermostat – Part No. CT200001 The digital wireless programmer and room thermostat is a 7 day radio frequency (RF) wireless thermostat / timer, which communicates with a receiver designed to fit in the clock aperture of the boiler control panel.
- Page 2 To install the receiver Turn the power off to the boiler Remove the boiler front panel and swing the control panel into the service position. Refer to boiler Installation & Servicing Manual. With a sharp knife, cut out the small plastic cutaway (fig 1) to allow the wires to go through and the wires grommet to secure into position.
- Page 3 Transmitter Position Remove wall Secure rear panel Re-assemble Slide the front cover to wall. Note: There Transmitter to rear up, open the battery mounting rear panel must be a top panel compartment and fit from Transmitter clearance of at least the batteries.
- Page 4 Press upper + button (– button disables the RF signal) to enable a continuous RF signal. The receiver LED will go out as soon as a signal from the transmitter is received. Then press the OK-button, the radio link between transmitter and receiver is now established. Press the ESC-button to return to Auto mode.
- Page 5 Function Keys +/– buttons used to increase/decrease temperatures. OK-button to confirm settings and go to the next step. MODE-button to select from the available operating modes. ESC-button used for ON/OFF, go one step back in menu or return to main menu by pressing the button more than 3 seconds. SET-button for settings following commissioning.
- Page 6 5. The time is set in the same way as the date. Programming Sequence for specifying programs during initial start-up To specify programs after initial start-up press the SET-button, then choose the Prog menu with the upper +/– buttons and confirm with OK. Rev: 02/15/004...
- Page 7 Choose between: 7 days – one programme 5-2 days – one program per day block 1-7 days – each day an individual program free block formation – one program per day block Select program Each weekday or day block must be allocated a program P1, P2, P3, P4 (pre-defined) or Pd (user defined).
- Page 8 If you wish you can modify the pre-defined programs. Use the upper +/– buttons to increase/decrease the temperature of each segment by 0.5° C. Use the lower +/– buttons to go forward/backward 30 minutes each time and copy the selected temperature value. Settings After commissioning you can change the date, time, temperature and time programming.
- Page 9 With the lower +/– buttons you can choose days or day blocks for programming and confirm with OK. Go to operation number 6. By pressing the OK-button you can choose between the pre-defined programs P1 – P4 or the user- defined program Pd.
- Page 10 Operating modes Set operating modes Follow the sequence for selecting the desired operating mode. The operating modes in the device appear in the same order as described here. Press and hold the ESC-button for 3 seconds to return to Auto mode. Auto Symbol: After each programming session, the device automatically returns to the Auto mode.
- Page 11 Manual-ECO-Fix Symbol: Manual-ECO-Fix mode calculates an average temperature of the actual program. This temperature is is kept for the whole day until any user‘s intervention is made. To return to Auto mode, press OK. The average temperature is the starting point for increasing or decreasing the desired temperature, pressing upper +/–...
- Page 12 Countdown mode Symbol: This function runs into a desired set temperature during certain period of time. Adjustable period of time is 1 – 23 hours. After the time is elapsed, the device returns into OFF mode (Anti-freeze temperature is kept). During the Countdown mode, remaining countdown time is indicated. Example: The device shall be run into OFF mode after 4 hours.
- Page 13 Holiday mode Symbol: This function runs into a desired set temperature during certain period of time. Adjustable period of time is 1 – 90 days. After the time is elapsed, the device returns into the mode before the Holiday mode was activated. During the Holiday mode, the rest of the days is indicated. Example: The temperature shall be set for 16 days on 13°...
- Page 14 OFF mode Symbol: This mode switch off the device completely. To activate this mode press and hold ON/OFF/ESC- button for more than 5 seconds. To leave this mode press and hold the ON/OFF/ESC-button again for more than 5 seconds. The anti-freeze protection is granted. Low battery Symbol: A low battery level is indicated with the battery icon in the...
- Page 15 This control is guaranteed against manufacturing defect for a period of 12 months from the date of installation. This Guarantee does not cover replacement of batteries or cosmetic damage to the controller. ATAG Heating Technology Ltd 47 Castle St, Reading, Berkshire, RG1 7SR Tel: 0800 254 5061 www.atagheating.co.uk...
