* For all 4 in 1 cribs, please contact a retailer to order your full size adult wooden bed rails for
Congratulations on purchasing a MDB Family product. This product will provide many years of service if you adhere to the
following guidelines for assembly, maintenance and operation. This product is for residential use only.
Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assembling the product in addition
to the Allen wrench included in the hardware box. Do not use power screwdrivers. All of our products are made from natural woods.
Please understand that natural woods have color variations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARDWARE. YOUR MODEL
MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC VARIATIONS.
C. 3/4" Flat head
screw (10)
D. 3/4" Allen
head bolt (4)
STEP 1.
Remove the crib sides, spring frame and
post brackets.
STEP 2.
Use the Allen head bolts (D) to attach the
Left (E) and Right (F) brackets to the foot
board posts. Right post and bracket are shown.
STEP 3.
Attach the rails to the brackets with the screws
(C) and tighten securely with a Phillips head
Screwdriver.
Conversion Rails (5789 - Sold Separately) - Assembly Instructions
your full size bed convers
HARDWARE
E. Left bracket F. Right bracket
STEP 4.
Attach the rails to the headboard with the
barrel nuts and bolts you removed in step 1.
Tools Needed
(not included)
Phillips
screwdriver
