VARYSCAN 4 COMPACT PLUS 575 HMI

? initialisation mode

? test mode

? infinitely variable colour changing
? optional channels of Varyscan
? reset on DMX
? DMX-address
Initialisation Mode
This mode serves for adjustment and basic initialisation of the Varyscan
out by producer).
Test Mode
To see the variety of functions of your Varyscan
turning switch 3 off and switch 2 on at DIP-switch No.2. Now plug in your scanner
and you will largely see it's functions.
Adjustments at DIP-Switch No.2
Before adjusting DMX-addresses, you have to choose a certain drive mode and then make the right choice of
addresses.
At DIP-switch No.2 you find 4 switches for choosing the following functions.
Infinitely Variable Colour Changing
DIP-switch No.2 switch 1
i.e. the moment this function is turned on, every DMX-factor between 0 and 128
corresponds to an adjustment of the colour wheel. You can produce not only half
colours but 1/3- 2/3 colours or 1/4- 3/4 colours etc. To choose this function, turn
switch 1 at DIP-switch No.2 on.
Is switch 1 on position off, you get only full colours, respectively half colours
Optional Drive Modes
DIP-switch No.2 switch 2 and 3
You have 3 DMX-channel formats to your disposal, which are explained precisely in the following text.
1. JB lighting 8 channel drive mode
channel 1
channel 2
channel 3
channel 4
channel 5
channel 6
channel 7
channel 8
DIP-switch position: DIP-switch No.2 switch 2 and 3 off

2. 6 channel drive mode (Clay Paky - Goldenscan 3 compatible)

channel 1
channel 2
channel 3
®
®
:
x-axis
y-axis
gobo
colour
shutter/dimmer
iris
rotating gobos; positioning and rotation
effect wheel
iris and gobo rotation
colour
gobo and effect wheel
®
easily, start the test mode by
:
27
(carrying-
.
