VARYSCAN 4 COMPACT PLUS 575 HMI
colour wheel rotation speed (fast)
channel 5
dimmer shutter closed --> blackout (BO)
dimmer
dimmer open
dimmer shutter immediatelly
shutter sequence 1,00 flashes/sec
shutter sequence 11,00 flashes/sec
shutter open
channel 6
iris closed / gobo first position
iris open / gobo first position
second gobo position
third gobo position
locked into position 180°
locked into position 360°
locked into position 540°
rotation left highest speed
rotation left lowest speed
rotation stop
rotation right lowest speed
rotation right highest speed

Occupation DMX-In / DMX-Out

Position of sockets see page 5
DMX-IN
Pin1: ground black
Pin2: DMX- beige
Pin3: DMX+ red
Pin4: frei
Pin5: + 5V green

Technical data

Measurements:
Weight:
Power consumption:
Mains Voltage:
Bulb :
Fuse:

Change of Eprom/ Software Update

To change the Eprom proceed as follows:
Remove the cover sheet for the electronic board below the mirror by taking out the 4 screws (see sketch page 4). By
comparing the electronic board with the plan of electronic parts you can see the Eprom at the right side (IC U2).
Carefully lever the used Eprom from the holder and exchange it for a new one.
DMX-OUT
Pin1:
Pin2:
Pin3:
Pin4:
Pin5:
hight 65 cm
width 27 cm
depth 29 cm
19 kg
1725 W
230V 50Hz 7A
Osram 575 HMI
8 ampere inert
DMX 255
dimmer / shutter
DMX 000
DMX 019 - 127
DMX 128 - 137
DMX 138 - 139
DMX 140 -
DMX 243
DMX 244 - 255
iris and gobo rotation
DMX 000
DMX - 064
DMX 065
DMX 066
DMX 106
DMX 148
DMX 191
DMX 192
DMX 222
DMX 223 - 224
DMX 225
DMX 255
ground
DMX-
DMX+
frei
frei
36
black
beige
red
