VARYSCAN 4 COMPACT PLUS 575 HMI
Back view and position of operating sections
Occupation of DMX-sockets
DMX-in
Pin No.
signal
1
Ground black
2
DMX -
3
DMX + red
4
free
5
free
DMX-out
1
white
2
3
4
green/black
5
Colour of wire Pin No.
Ground black
DMX -
DMX + red
not connected
not connected
25
Signal Colour of wire
white
