Programming one Tag to Zone 1

Note:- Do not have Tags in your hand or close by when pressing keys.
Zone 1 has 1000 locations available from 000 to 999.
1. Enter programming mode
A Long bleep will be heard and the green power LED will turn orange.
2. Enter the location you want to programme the Tag to in a 3 digit
format (xxx).
The green programming LED (top left of keypad) will illuminate.
Note :- if this location already has a pin number or Tag programmed the
LED will turn red.
To delete this location press the star
green.
3. Pick up one Tag only and present it to the bottom of the reader
(
2 bleeps will be heard.
If further Tags are to be programmed select a the next available location
number (xxx)

Programming a group of Tags to Zone 1

Note:- Do not have Tags in your hand or close by when
pressing keys.
Zone 1 has 1000 locations available from 000 to 999.
1. Enter programming mode
All tags to be programed as a group must have consecutive numbers.
A Long bleep will be heard and the green power LED will turn orange.
2. Press the
*
3. Press the 0 key then the 1 key the unit will bleep once.
4. Enter the number of the first available location in the range of 000
to 999.
5. Now enter in a 3 digit format how many tags you want to
programme (xxx) into the system, present the lowest number tag
to the reader
(
of the lowest number Tag from the group to be programmed into
the keypad.
To confirm the programming has been successful 2 bleeps will be heard.
) and remove.
key then the 9 key the power LED will start to flash
) and remove. Alternatively enter the 8 digit number
*
key twice. The LED will now turn
7
